Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
WhatsApp : 008618264966991
Terex earthmoving equipment parts
| 001 001 15301128 VALVE-PILOT SUPPLY 002 001 15272119 .KIT-SEAL |
| 000 001 15227019 CYLINDER ASSEMBLY 001 001 09014653 .TUBE 002 001 15231390 .END ASSY A 003 001 09014649 ..BUSHING A 004 001 09014362 .RING-BACKUP A 005 001 09014593 .O RING A 006 001 09256608 .WIPER A 007 001 06944596 .RING-WEAR A 008 001 09270713 .SEAL 009 016 09354243 .LOCKNUT A 010 002 15232053 .SEAL-T 011 001 15232056 .TUBE 012 004 15227029 .SCREW-SET 013 001 15232597 .TUBE ASSY A 014 002 09014633 .RING-PISTON A 015 001 09014131 .RING-WEAR A 016 001 15227030 .WIPER A 017 002 15227031 .RING-WEAR A 018 001 15227032 .SEAL 019 001 15227146 .TUBE ASSY A 020 001 09018420 .RING-WEAR A 021 001 09014636 .O RING A 022 001 09014635 .RING-BACKUP 023 001 09014648 .BASE ASSEMBLY 024 001 09014649 ..BUSHING 025 016 00223442 .BOLT 026 001 09411010 FITTING-GREASE 027 004 09018418 PIN 028 004 09217321 WASHER 029 004 00103329 LOCKWASHER 030 004 00179883 BOLT 031 002 09256240 HOSE ASSY 032 002 00454096 ELBOW 033 002 00187394 COUPLING 034 002 09411019 NIPPLE-GREASE NOTES: A PARTS IN 15265278 OVERHAUL KIT |
| TRANSMISSION BREAKDOWN | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6777070 | FLANGE-INPUT |
| 2 | 15258084 | FLANGE-TRAMS OUTPUT |
| 3 | 6772182 | NUT |
| 4 | 6776246 | PLATE-RETAINER |
| CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6777974 | GASKET |
| 2 | 6835409 | PLATE-OIL TRANSFER |
| 3 | 6830003 | WASHER |
| 4 | 23018739 | BOLT |
| 5 | 9409030 | BOLT |
| 6 | 6839632 | GASKET |
| 7 | 23012877 | PLATE-SEPARATOR |
| 8 | 6839633 | GASKET |
| 9 | 103339 | WASHER |
| 10 | 9427847 | BOLT |
| 11 | 9433579 | BOLT |
| 12 | 29536510 | HARNESS ASSY |
| 13 | 12052410 | TERMINAL |
| 14 | 12059716 | CONNECTOR-BODY |
| 15 | 454813 | BOLT |
| 16 | 23019734 | SOLENOID-12V |
| 17 | 23046848 | SEAL |
| 18 | 29524652 | SCREW |
| 19 | 6779833 | GASKET |
| 20 | 6833223 | SPRING-OUTER |
| 21 | 6830243 | SPRING-INNER |
| 22 | 6880187 | BALL-CHECK |
| 23 | 29525044 | PLUG ASSY |
| 24 | 6759964 | SPRING |
| 25 | 6769825 | SPRING |
| 26 | 6778593 | SPRING |
| 27 | 6830014 | SPRING |
| 28 | 6830240 | SPRING |
| 29 | 6830237 | SPRING |
| 30 | 6779835 | GASKET |
| 31 | 103339 | WASHER |
| 32 | 9418964 | BOLT |
| 33 | 186284 | BOLT |
| 34 | 179851 | BOLT |
| 35 | 433114 | BOLT |
| 36 | 6838821 | GASKET |
| 37 | 23045751 | COVER ＆ PLATE |
| 38 | 6838904 | GASKET |
| 39 | 23019734 | SOLENOID-12V |
| 40 | 23046848 | SEAL |
| 41 | 6779852 | GASKET |
| 42 | 12059716 | CONNECTOR-BODY |
| 43 | 12052410 | TERMINAL |
| 44 | 6835526 | GASKET |
| 45 | 186290 | BOLT |
| SHIFT CONTROL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15231519 | RELAY |
| 2 | 15247614 | FUSE-5AMP |
| 3 | 15247612 | FUSE-10AMP |
| 4 | 109084 | NUT |
| 5 | 179820 | NUT |
| 6 | 103320 | LOCKWASHER |
| 7 | 103340 | WASHER |
| 8 | 9251501 | BRACKET |
| 9 | 179838 | BOLT |
| 10 | 108580 | LOCK WASHER |
| 11 | 102635 | NUT |
| 12 | 179795 | BOLT |
| 13 | 103339 | WASHER |
| 14 | 103319 | LOCKWASHER |
