Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
WhatsApp : 008618264966991
Terex earthmoving equipment parts
| 001 001 15022887 HOSE 002 002 15022880 HOSE 003 002 15244891 HOSE ASSY 004 001 15244837 PLATE 005 005 00127887 ELBOW 006 005 00443977 NIPPLE 007 005 00118748 CONNECTOR 008 002 00179837 BOLT 009 002 00108580 LOCKWASHER 010 003 00444688 PLUG 011 005 09411010 FITTING-GREASE |
NC NO. QTY PART NO. DESCRIPTION
001 001 20009515 GUARD ASSY-RADIATOR
005 002 00179881 BOLT
006 008 00274209 NUT
007 008 00179885 BOLT
008 001 15305470 GRILLE
009 002 00179887 BOLT
010 001 15252077 BRACKET
011 040 09270000 WASHER
012 002 00274209 LOCKNUT
013 001 15300546 PLATE
014 006 00179839 BOLT
015 006 09060202 WASHER
| OIL COOLER PIPING-DISC BRAKES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15236505 | TUBE ASSY |
| 2 | 15245374 | TUBE ASSY |
| 3 | 15236511 | TUBE ASSY |
| 4 | 9071313 | TUBE ASSY |
| 5 | 15236508 | TUBE ASSY |
| 6 | 15250497 | TUBE ASSY |
| 7 | 15236509 | TUBE ASSY |
| 8 | 15301594 | PIPE ASSEMBLY |
| 9 | 15258071 | HOSE ASSY |
| 10 | 15248180 | HOSE ASSY |
| 11 | 15250626 | HOSE ASSY |
| 12 | 15258073 | HOSE ASSY |
| 13 | 15300378 | HOSE ASSY |
| 14 | 15245140 | HOSE ASSY |
| 15 | 15245138 | HOSE ASSY |
| 16 | 15245139 | HOSE ASSY |
| 17 | 15245132 | HOSE ASSY |
| 18 | 15257628 | HOSE ASSY |
| 19 | 15245134 | HOSE ASSY |
| 20 | 15245135 | HOSE ASSY |
| 21 | 15245133 | HOSE ASSY |
| 22 | 15245136 | HOSE ASSY |
| 23 | 15300455 | BRACKET |
| 24 | 15300456 | CLAMP |
| 25 | 15250566 | BRACKET ASSY |
| 26 | 9067454 | CLAMP |
| 27 | 15300496 | CLAMP |
| 28 | 15024973 | CLAMP-TUBE |
| 29 | 9072826 | CLAMP |
| 30 | 15004713 | CLAMP |
| 31 | 15004712 | CLAMP |
| 32 | 15001429 | CLAMP |
| 33 | 15004744 | BUSHING-SPLIT |
| 34 | 15015251 | BUSHING-SPLIT |
| 35 | 15015249 | BUSHING-SPLIT |
| 36 | 15004748 | NUT-STACKING |
| 37 | 15001428 | NUT-STACKING |
| 38 | 179883 | BOLT |
| 39 | 179890 | BOLT |
| 40 | 179839 | BOLT |
| 41 | 179841 | BOLT |
| 42 | 9167602 | FLANGE-SPLIT |
| 43 | 9409985 | FLANGE-SPLIT |
| 44 | 9409984 | FLANGE-SPLIT |
| 45 | 15002672 | O RING |
| 46 | 15008262 | O RING |
| 47 | 15008261 | O RING |
| 48 | 179885 | BOLT |
| 49 | 179887 | BOLT |
| 50 | 103329 | LOCKWASHER |
| 51 | 15008260 | O RING |
| 52 | 102635 | NUT-STACKING |
| 53 | 103328 | LOCKWASHER |
| 54 | 179893 | BOLT |
| 55 | 187433 | BOLT |
| 56 | 108580 | LOCKWASHER |
| 57 | 9077325 | CLIP-P |
| 58 | 179833 | BOLT |
| 59 | 15258078 | BRACKET |
| 60 | 15001430 | CLAMP |
| 61 | 15258079 | HOSE ASSY |
| OIL COOLER AND PIPING-TRANS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15247679 | HOSE-SILICONE |
| 2 | 15308924 | CLAMP |
