Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
WhatsApp : 008618264966991
Terex earthmoving equipment parts
| A 001 002 15257983 PLATE-FLOOR A 002 002 15257984 PLATE A 003 002 15257985 PLATE-BENT A 004 002 15257986 PLATE A 005 002 15257987 PLATE A 006 002 15257988 PLATE A 007 002 15257989 PLATE-SIDE A 008 001 15257990 PLATE-FRONT NOTES: A WEAR PLATES - HALF ROCK 0PTION |
| 001 002 15331137 PLATE-EXTENSION 002 001 15331139 STIFFENER LH 003 001 15331140 STIFFENER RH 004 002 15331143 PLATE-END COVER 005 002 15312462 LIFTING LUG |
| 001 003 15343914 DECAL-STRIPE CHEVRON 002 002 15343915 DECAL-’KEEP CLEAR’ 003 002 15343912 DECAL-STRIPE CHEVRON 004 003 15344156 DECAL-STRIPE CHEVRON |
| 12 | 9354243 | NUT |
| 13 | 9066008 | RING |
| 14 | 186646 | BOLT |
| 15 | 9268885 | LOCK |
| 16 | 114981 | OIL DRAIN PLUG |
| 17 | 15311229 | DAMPING WASHER |
| 18 | 9008198 | DAMPING GASKET |
| 19 | 179795 | BOLT |
| 20 | 103319 | SPRING WASHER |
| 21 | 109084 | NUT |
| TRANSMISSION BREAKDOWN | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 29510838 | BOLT |
| 2 | 6755269 | STRIP |
| 3 | 6768711 | FENDER |
| 4 | 6722141 | SHIM-0.05 |
| 5 | 6772182 | NUT |
| 6 | 15300857 | YOKE |
| 7 | 15300858 | YOKE |
| SHIFT CONTROL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 29536931 | TRANS SHIFT SELECTOR |
| 2 | 29537718 | HARNESS |
| 3 | 29537724 | HARNESS |
| 4 | 15310346 | HARNESS-SHIFT |
| 5 | 6350812 | BOLT |
| 6 | 7150815 | WASHER |
| 7 | 103319 | LOCKWASHER |
| 8 | 103339 | WASHER |
| 9 | 20019296 | CONNECTION BOX |
| 10 | 15256444 | RELAY |
| 11 | 15247612 | FUSE-10AMP |
| FILTER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23049374 | ELEMENT |
| 2 | 23018958 | SEAL |
| 3 | 23018846 | SWITCH |
| TRANSMISSION OIL CIRCUIT | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15258034 | HOSE ASSY |
| 2 | 15258035 | HOSE ASSY |
| 3 | 103329 | SPRING WASHER |
| 4 | 179885 | BOLT |
| 5 | 102635 | NUT |
| 6 | 179839 | BOLT |
| 7 | 9131881 | CLAMP |
| 8 | 9409985 | FLANGE-SPLIT |
| 9 | 9264303 | O RING |
| 10 | 179885 | BOLT |
| 11 | 103329 | SPRING WASHER |
| 12 | 15260133 | HOSE ASSY |
| 13 | 15260134 | HOSE ASSY |
| RETARDER CONTROL LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 108580 | LOCKWASHER |
| 2 | 103341 | GASKET |
| 3 | 103385 | PIN |
| 4 | 20019321 | ELECTRIC CYLINDER |
| 5 | 15036229 | BOLT |
| HYDRAULIC CONVERTER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6773186 | SEAL RING |
| 2 | 181415 | BOLT |
| 3 | 6768689 | COVER |
| 4 | 5181902 | SEAL GASKET |
| 5 | 23041458 | BEARING |
| 6 | 29519116 | HOUSING ASSY |
| 7 | 455366 | DOWEL |
| 8 | 6832138 | FRICTION DISK |
| 9 | 23016058 | PRESS PLATE |
| 10 | 23041452 | BEARING |
| 11 | 6838403 | SNAP RING |
| 12 | 6774703 | SNAP RING |
| 13 | 23019639 | TURBINE |
| 14 | 6774708 | NUT |
| 15 | 6758485 | WASHER |
| 16 | 23045335 | GUIDING WHEEL |
| 17 | 6774710 | PRESS PLATE |
| 18 | 23041915 | BEARING |
| 19 | 6830003 | WASHER |
| 20 | 9420572 | BOLT |
| 21 | 29503632 | ACE INPUT DRIVE GEAR |
| 22 | 103322 | LOCKWASHER |
| 23 | 271505 | NUT |
| 24 | 6752849 | SEAL RING |
| 25 | 6752848 | SEAL RING |
| CONVERTER HOUSING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179891 | BOLT |
| 2 | 103323 | LOCKWASHER |
| 3 | 6774735 | PUMP IDLER |
| 4 | 23048022 | BEARING |
| 5 | 23047992 | BEARING |
| 6 | 6755986 | PUMP DRIVELINE |
| 7 | 444688 | PLUG |
| 8 | 23019731 | SEAL RING |
| 9 | 6775834 | SLEEVE |
| 10 | 179838 | BOLT |
| 11 | 103321 | WASHER |
| 12 | 6882702 | SEAL GASKET |
| 13 | 23047992 | BEARING |
| 14 | 29509637 | SPEED SENSOR ASSY |
| 15 | 29503843 | THRUST PLATE |
| 16 | 179812 | BOLT |
| 17 | 29503803 | SEAL GASKET |
| 18 | 179837 | BOLT |
| 19 | 179860 | BOLT |
| 20 | 103322 | LOCKWASHER |
| 21 | 6779125 | FLANGE |
| 22 | 23046148 | HOSE ASSY |
| 23 | 6774735 | OIL PUMP IDLER |
| 24 | 23048022 | ROLLER BEARING |
| 25 | 6768990 | PTO COVER |
| 26 | 179857 | BOLT |
| 27 | 6755403 | PIN |
| 28 | 6779451 | SEAL GASKET |
| 29 | 6830021 | SEAL RING |
| OIL PUMP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179845 | BOLT |
| 2 | 103321 | LOCKWASHER |
| 3 | 6758218 | GASKET |
| 4 | 9418964 | BOLT |
| 5 | 179839 | BOLT |
| 6 | 6880125 | PUMP ASSY |
| 7 | 148415 | BEARING |
| 8 | 6769413 | GASKET |
| 9 | 6769722 | GEAR-DRIVE |
| 10 | 6756124 | GASKET |
| 11 | 6776451 | SCREEN-FILTER |
| 12 | 6756002 | GASKET |
| MAIN PRESSURE REGULATOR VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6880860 | GASKET |
| 2 | 6771005 | RING |
| 3 | 6758543 | PLUG |
