Terex earthmoving equipment parts
2-1
TABLE NO.
2-2
FRONT BRAKE
NC NO. QTY PART NO. DESCRIPTION
001 002 09016367 DRUM-BRAKE
002 032 09011226 WASHER
003 032 00223457 BOLT
004 002 09016363 SPRING-RETURN
005 004 09380214 SHOE ASSY
006 004 15227297 ·ROLLER
007 004 09114428 ·PIN
008 064 09422277 ·NUT
A 009 064 15306850 ·PLUG
010 004 09250561 ·BUSHING
A 011 008 NSS ·SHOE
012 032 15306515 ·SCREW
013 002 09016361 WASHER
2-2
9-04-116
NC NO. QTY PART NO. DESCRIPTION
014 006 00274770 RING-SNAP
015 002 09158072 PLATE-CONNECTING
016 012 09016360 OIL SEAL
017 004 09016364 STEADY PIN
018 004 00456264 LOCKWASHER
019 004 00218407 NUT
020 004 09411010 NIPPLE
021 001 09016369 CAM SHAFT-LH
022 001 09016368 CAM SHAFT-RH
023 004 15012280 FENDER
024 020 00179883 BOLT
025 020 09270000 WASHER-HARDENED
026 020 15013577 WASHER
A NOTE 015231967 GASKET MUST BE CONSISTED BY PLUG AND
GASKET.
| 27 | 15272085 | BUTTON |
| 28 | 15270845 | SCREW |
| 29 | 7150815 | WASHER |
| 30 | 6430801 | NUT |
| CAB CENTRE CONSOLE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6441020 | BOLT |
| 2 | 15272074 | COVER |
| 3 | 15272076 | ROD |
| 4 | 15272077 | CLIP |
| 5 | 15270896 | HOSE-BULK PLASTIC |
| CAB MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15235693 | MOUNT-ENG ISOLATION |
| 2 | 454414 | BOLT |
| 3 | 9419493 | LOCKNUT |
| 4 | 15250143 | WASHER-HARDENED |
| 5 | 7160830 | LOCK WASHER |
| 6 | 15300236 | FLOOR MAT |
| 7 | 15303081 | MIRROR ARM |
| 8 | 9077400 | MIRROR |
| CAB DOOR-LEFT HAND | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272275 | DOOR ASSY-LH |
| 2 | 15272099 | SEAL-BULK |
| 3 | 15272280 | DOOR LOCK-LH |
| 4 | 15272105 | ADDITIVE-LOCK |
| 5 | 15270751 | HANDLE-DOOR |
| 6 | 15272102 | SCREW |
| 7 | 15272871 | ARM-SLIDING |
| 8 | 15272285 | CABLE |
| 9 | 9379264 | TIE-CABLE |
| 10 | 15272289 | SWITCH SUPPORT |
| 11 | 15272141 | SWITCH-WINDOW LH |
| 12 | 15272271 | HINGE |
| 13 | 15272113 | WASHER |
| 14 | 15272114 | NUT-SAFETY |
| 15 | 15272115 | CAP-NUT |
| 16 | 15272272 | PIN |
| 17 | 15272273 | SPLIT PIN |
| 18 | 15272274 | CLIP |
| 19 | 15270752 | HANDLE-PULL |
| 20 | 15272140 | MOTOR-DOOR LH |
| 21 | 15270781 | BOLT |
| 22 | 15272873 | THREADED BUSH |
| CAB DOOR-RIGHT HAND | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272096 | DOOR ASSY-COMPLETE |
| 2 | 15272099 | SEAL-BULK |
| 3 | 15270751 | HANDLE-DOOR |
| 4 | 15272102 | SCREW |
| 5 | 15272104 | LOCK |
| 6 | 15272105 | ADDITIVE-LOCK |
| 7 | 15272271 | HINGE |
| 8 | 15272272 | PIN |
| 9 | 15272273 | SPLIT PIN |
| 10 | 15272274 | CLIP |
| 11 | 15272113 | WASHER |
| 12 | 15272114 | NUT-SAFETY |
| 13 | 15272115 | CAP-NUT |
| SWITCHES AND INSTRUMENTS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15256433 | SPEEDOMETER |
| 2 | 15256026 | TACHOMETER |
| 3 | 15258289 | GAUGE ENG OIL PRESS |
| 4 | 15258291 | GAUGE ENG WATER TEMP E |
| 5 | 15258288 | GAUGE TRANS OIL TEMP E |
| 6 | 15300128 | GAUGE-TRANS OIL PRES |
| 7 | 15300413 | GAUGE-FUEL LEVEL |
| 8 | 15258795 | SWITCH-HAZARDS |
| 9 | 15258798 | SWITCH-LIGHTS |
| 10 | 15258796 | SWITCH-TEST |
| 11 | 15237165 | LENS-HAZARD LIGHTS |
| 12 | 15237163 | LENS-LIGHTS |
| 13 | 15229156 | LENS-TEST SWITCH |
| 14 | 15300563 | LENS；TRANSMISSION CHECK |
| 15 | 15237161 | SWITCH-COLUMN |
| 16 | 15300587 | MODULE,WARNING LIGHTS |
| 17 | 15271204 | BULB AND SOCKET-MODULE |
| 18 | 15300588 | MODULE,WARNING LIGHTS |
| 19 | 15300589 | MODULE,WARNING LIGHTS |
| 20 | 9079062 | DIODE-BLOCK |
| 21 | 15227360 | BUZZER |
| 22 | 15231519 | RELAY |
| 23 | 15244724 | FLASHER UNIT |
| 24 | 15247615 | FUSE-3 AMP |
| 25 | 15247614 | FUSE-5 AMP |
| 26 | 15247612 | FUSE-10 AMP |
| 27 | 15247611 | FUSE-15 AMP |
| 28 | 15248347 | FUSE-25 AMP |
| 29 | 15300658 | SWITCH,-PUSH/TWIST |
| 30 | 15257770 | KEY SWITCH |
| 31 | 15271326 | KEY-IGNITION |
| SEAT-DRIVER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15269020 | KIT-HT RISER SPRING |
| 2 | 15269028 | KIT-24V COMP/VALVE |
| 3 | 103340 | WASHER |
| 4 | 103320 | LOCK WASHER |
| 5 | 102634 | NUT |
| 6 | 7161230 | LOCK WASHER |
| 7 | 179818 | BOLT |
