Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
Tel / WhatsApp : 008618264966991
Terex earthmoving equipment parts
SPACE ADJUSTER
NC NO. QTY PART NO. DESCRIPTION
001 001 15014970 ADJUSTER-LEFT
002 005 09039926 ·RIVET
003 001 09058954 ·WASHER
004 002 09039910 ·COVER
005 001 09039912 ·WORMGEAR
006 001 09024901 ·WORM
007 001 09033031 ·SHAFT
008 001 09054078 ·BUSHING
009 001 00114861 ·BALL
010 001 09033032 ·SPRING
011 001 09033033 ·LOCKSCREW
012 001 02483397 ·PLUG
013 001 09411010 ·NIPPLE
| 28 | 15000838 | PIN-RIDE CYLINDER |
| 29 | 15019238 | BOLT |
| 30 | 15000991 | WASHER-HARDENED |
| 31 | 273852 | LOCKNUT |
| 32 | 9015398 | PIN ASSEMBLY |
| 33 | 103329 | LOCK WASHER |
| CABLES/HARNESSES-CAB | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15259091 | HARNESS,DASH |
| 2 | 15259105 | HARNESS,CAB |
| 3 | 15302853 | HARNESS,CONSOLE |
| 4 | 15302870 | TIMER RELAY |
| BATTERY AND CABLES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15305862 | MAGNETIC SWT-START SOL |
| 2 | 15253875 | CLAMP-PIPE |
| 3 | 15302350 | CABLE ASSEMBLY |
| 4 | 15302353 | CABLE ASSEMBLY |
| 5 | 15256097 | CABLE ASSY |
| 6 | 15232468 | CABLE |
| 7 | 15302354 | CABLE ASSEMBLY |
| 8 | 15302355 | CABLE ASSEMBLY |
| 9 | 15256096 | CABLE ASSY |
| 10 | 15256094 | CABLE ASSY |
| 11 | 15258745 | COVER ASSEMBLY |
| 12 | 6350612 | SCREW |
| 13 | 102635 | NUT T50 |
| 14 | 103320 | LOCKWASHER |
| 15 | 179845 | BOLT |
| 16 | 7160630 | WASHER |
| 17 | 108580 | LOCKWASHER |
| 18 | 103319 | LOCKWASHER |
| 19 | 15304322 | CABLE ASSEMBLY |
| 20 | 15258443 | ISOLATOR RELAY |
| 21 | 15310266 | PLATE-MTG |
| 22 | 103340 | WASHER |
| 23 | 103320 | WASHER-LOCK |
| 24 | 179795 | BOLT |
| 25 | 103319 | WASHER |
| BATTERY MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179890 | BOLT |
| 2 | 9270000 | WASHER-HARDENED |
| 3 | 9263815 | CLAMP-BATTERY |
| 4 | 15236524 | BOLT |
| 5 | 9060202 | WASHER-HARDENED |
| ELECTRICAL LIGHTING SYSTEM | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15230426 | HEADLAMP |
| 2 | 15271433 | BULB-H4 |
| 3 | 15258783 | LAMP-SIDE INDICATOR |
| 4 | 15258873 | BULB-H4 |
| 5 | 15258872 | BULB-24V 21W H/DUTY |
| 6 | 15273641 | LAMP-REVERSE |
| 7 | 15273642 | BULB-24V 70W HALOGEN |
| 8 | 15273643 | LAMP-RETARDER |
| 9 | 15273644 | LAMP-DIR/STOP/TAIL |
| 10 | 15273718 | HARNESS-REAR LIGHTS |
| 11 | 102634 | NUT |
| 12 | 103320 | LOCKWASHER |
| 13 | 108580 | LOCKWASHER |
| 14 | 106263 | WASHER |
| 15 | 117966 | GROMMET |
| 16 | 102635 | NUT |
| ALTERNATOR AND MOUTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15273449 | ALTERNATOR-24V/65A |
| STARTER MOTOR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15273450 | STARTER |
| REVER ALARM | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15001878 | ALARM-REVERSE |
| 2 | 455537 | BOLT |
| 3 | 274208 | LOCKNUT |
| SWITCHES AND SENSORS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15300082 | SWITCH-PRESSURE |
| 2 | 15300083 | SWITCH-PRESSURE |
| 3 | 15300084 | SWITCH-PRESSURE |
| 4 | 15300085 | SWITCH-PRESSURE |
| 5 | 15300086 | SWITCH-PRESSURE |
| 6 | 15300087 | SWITCH-TEMPERATURE |
