Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
WhatsApp : 008618264966991
Terex earthmoving equipment parts
PEDAL BRAKE VALVE
NC NO. QTY PART NO. DESCRIPTION
001 001 15304544 PEDAL BRAKE VALVE
002 001 15273052 ·PEDAL ASSY
003 001 15500913 ·VALVE BASE ASSY
004 001 15273051 ·PNEUMATIC VALVE ASSY
11-05-027
2-2
FRONT BRAKE PUMP
NC NO. QTY PART NO. DESCRIPTION
001 09255800 FRONT BRAKE PUMP
001 008 00120368 ·NUT
002 008 00103320 ·LOCKWASHER
003 001 09023283 ·BODY
004 001 09033730 ·TAG
005 008 09034481 ·GASKET
006 001 02466124 ·DUST PROOF SHIELD
007 008 09428735 ·BOLT
008 001 09023220 ·FIXED DISK
009 001 09023218 ·FIXED DISK
010 001 09023284 ·CUP RING
011 001 09023285 ·GUIDE SLEEVE
012 001 02466105 ·SHAFT
013 008 00103319 ·LOCKWASHER
014 008 00120367 ·NUT
015 001 02466109 ·SEAT RING
016 001 02466110 ·SPRING-RETURN
017 001 02466115 ·BEARING
018 008 00120221 ·SCREW
019 008 00121801 ·LOCKWASHER
020 001 02466113 ·COVER
2-2
11-06-46
NC NO. QTY PART NO. DESCRIPTION
021 001 02466114 ·O RING
022 001 02466117 ·O RING
023 001 02466112 ·O RING
024 001 09034275 ·SHELL
025 002 02466126 ·STUD
026 002 00103325 ·LOCKWASHER
027 003 00114498 ·NUT
028 001 02466118 ·PISTON
029 008 02466120 ·ROLLER
030 001 02466119 ·LOCK SLEEVE
031 001 02466121 ·WASHER
032 001 02466122 ·SPRING
033 001 02466106 ·CAP
034 001 02466116 ·FELT PAD
035 001 02466125 ·DISK
036 001 03858065 ·RING-SNAP
037 001 02466123 ·PISTON ROD
038 001 02267136 ·CLEVIS ASSY
039 001 09035510 ·PIN
040 001 00103385 ·COTTER PIN
| 1 | 9190520 | MOUNT-ENG ISOLATION |
| 2 | 9190519 | WASHER-HARDENED |
| 3 | 454414 | BOLT |
| 4 | 9419493 | LOCK NUT |
| 5 | 15036004 | NUT |
| 6 | 15228111 | MIRROR ARM |
| 7 | 9077400 | MIRROR |
| CAB DOOR - LEFT HAND | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15042467 | DOOR LOCK-LH |
| 2 | 15036222 | SCREW |
| 3 | 15042462 | HANDLE-DOOR |
| 4 | 15042490 | MOTOR-DOOR LH |
| 5 | 15042507 | SWITCH |
| 6 | 15036004 | NUT |
| CAB DOOR - RIGHT HAND | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15042462 | HANDLE-DOOR |
| 2 | 15042488 | PLATE BENT |
| 3 | 15036222 | SCREW |
| 4 | 15042502 | LATCH LH |
| 5 | 15042503 | LATCH RH |
| WIPER AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15042342 | WIPER ASSY |
| 2 | 15042525 | WIPER MOTOR |
| 3 | 15042344 | ROD |
| 4 | 15042345 | WIPER ARM |
| 5 | 15042519 | WIPER BLADE |
| DASH AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103339 | WASHER |
| 2 | 103319 | LOCK WASHER |
| 3 | 180757 | BOLT |
| 4 | 109084 | HEXAGON NUT |
| SWITCH AND INSTRUMENTS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9381491 | TACHOMETER |
| 2 | 15234334 | GAUGE TRANS OIL TEMP |
| 3 | 15234379 | GAUGE ENG WATER TEMP |
| 4 | 9381492 | SPEEDOMETER |
| 5 | 15235407 | HOURMETER-24V |
| 6 | 15247606 | SWITCH-KEY |
| 7 | 9370176 | LIGHT-BLUE WARNING |
| 8 | 15013428 | SWITCH-MASTER |
| 9 | 15234338 | GAUGE AIR PRESSURE |
| 10 | 9379852 | SWITCH-HORN PUSH/OIP |
| 11 | 110633 | NUT |
| SEAT DRIVER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103340 | WASHER-PLAIN |
| 2 | 103320 | LOCK WASHER |
| SEAT PASSENGER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 102635 | NUT |
| 2 | 274209 | LOCK NUT |
| 3 | 9068666 | WASHER-HARDENED |
| 4 | 103329 | LOCK WASHER |
| 5 | 9217321 | WASHER |
| 6 | 179839 | BOLT |
| 7 | 108580 | LOCK WASHER |
| 8 | 103320 | LOCK WASHER |
| 9 | 102634 | NUT |
| BATTERY MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179839 | BOLT |
| 2 | 108580 | LOCK WASHER |
| 3 | 106263 | WASHER-PLAIN |
| 4 | 103332 | LOCK WASHER |
| 5 | 220081 | HEXAGON NUT |
| 6 | 9140612 | PAD BATTERY |
| 7 | 9383885 | CLAMP |
| 8 | 102635 | NUT |
| 9 | 110633 | NUT |
| AIR CONDITIONER/HEATER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15232270 | HEATER ASSY |
| 2 | 9398334 | EVAPORATOR |
| 3 | 9398333 | HEATER COIL |
| 4 | 9398392 | COOL CONTROL |
| 5 | 9398393 | BLOWER MOTOR ASSY |
| 6 | 9398394 | LOUVERS |
| HEATER LINES AND WIRING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 7551826 | HOSE |
| 2 | 117966 | GROMMET |
| 3 | 9014950 | CONNECTOR |
| 4 | 9136638 | NIPPLE |
| 5 | 7551826 | HOSE |
| 6 | 142269 | BUSH |
| 7 | 144034 | CONNECTOR |
| 8 | 2260846 | CLAMP |
| 9 | 9016059 | OUTLET HOOTER |
| 10 | 9131851 | CLAMP |
| 11 | 117966 | GROMMET |
| 12 | 103339 | WASHER-PLAIN |
| 13 | 103319 | LOCK WASHER |
| 14 | 179837 | BOLT |
| 15 | 108580 | LOCK WASHER |
| 16 | 274209 | LOCK NUT |
| 17 | 179818 | BOLT |
| 18 | 102634 | NUT |
| 19 | 179843 | BOLT |
| 20 | 179890 | BOLT |
| 21 | 179889 | BOLT |
| 22 | 179887 | BOLT |
| AIR CONDITIONER LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9016059 | OUTLET |
| 2 | 2260846 | CLAMP |
| 3 | 103320 | LOCK WASHER |
| 4 | 103319 | LOCK WASHER |
| 5 | 15267620 | CONDENSER |
| 6 | 9398401 | DEHYDRATOR |
| 7 | 9398404 | SWITCH-BINARY |
| 8 | 9399107 | HOSE ASSY |
| 9 | 9399108 | HOSE ASSY |
| 10 | 108580 | LOCK WASHER |
| 11 | 102635 | NUT |
| 12 | 179847 | BOLT |
| 13 | 106263 | WASHER |
| REAR VIEW MIRROR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103320 | LOCK WASHER |
| 2 | 9077400 | MIRROR |
| 3 | 179885 | BOLT |
| 4 | 9267949 | WASHER-HARDENED |
| 5 | 274209 | LOCK NUT |
| 6 | 15228111 | BRACKET MIRROR |
| INTERIOR LIGHT - CAB | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9079626 | CAB LIGHT |
| 2 | 9079372 | BULB |
| BODY / BOWL ASSY | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9253732 | BAR RIGHT FRONT |
| 2 | 179885 | BOLT 1/2"-13*1-1/2" |
| 3 | 103329 | LOCK WASHER |
| 4 | 9013849 | PAD |
| 5 | 9069246 | PIN |
| 6 | 9217321 | WASHER |
| 7 | 179883 | BOLT |
| 8 | 9013850 | PIN HINGE |
| 9 | 179880 | BOLT |
| 10 | 108580 | LOCK WASHER |
| 11 | 187394 | COUPLING |
| 12 | 9411019 | FITTING-GREASE |
| 13 | 102639 | HEXAGON NUT |
| 14 | 103331 | LOCK WASHER |
| 15 | 271560 | BOLT |
| 16 | 9411017 | FITTING |
| 17 | 271558 | BOLTS |
| 18 | 9191596 | WASHER |
| 19 | 179885 | BOLT |
| 20 | 274210 | LOCK NUT |
| 21 | 103329 | LOCK WASHER |
| 22 | 9402823 | ELBOW |
| 23 | 442733 | BOLT |
| 24 | 273852 | LOCK NUT |
