Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
Tel / WhatsApp : 008618264966991
Terex earthmoving equipment parts
2-1
TABLE NO.
2-2
FRONT BRAKE
NC NO. QTY PART NO. DESCRIPTION
001 002 09016367 DRUM-BRAKE
002 032 09011226 WASHER
003 032 00223457 BOLT
004 002 09016363 SPRING-RETURN
005 004 09380214 SHOE ASSY
006 004 15227297 ·ROLLER
007 004 09114428 ·PIN
008 064 09422277 ·NUT
A 009 064 15306850 ·PLUG
010 004 09250561 ·BUSHING
A 011 008 NSS ·SHOE
012 032 15306515 ·SCREW
013 002 09016361 WASHER
2-2
9-04-116
NC NO. QTY PART NO. DESCRIPTION
014 006 00274770 RING-SNAP
015 002 09158072 PLATE-CONNECTING
016 012 09016360 OIL SEAL
017 004 09016364 STEADY PIN
018 004 00456264 LOCKWASHER
019 004 00218407 NUT
020 004 09411010 NIPPLE
021 001 09016369 CAM SHAFT-LH
022 001 09016368 CAM SHAFT-RH
023 004 15012280 FENDER
024 020 00179883 BOLT
025 020 09270000 WASHER-HARDENED
026 020 15013577 WASHER
A NOTE 015231967 GASKET MUST BE CONSISTED BY PLUG AND
GASKET.
| BRAKE LINES-HYDRAULIC | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15301033 | PLATE-PEDAL ASSY |
| 2 | 15253055 | ELBOW |
| 3 | 15253039 | ADAPTOR-BULKHEAD |
| 4 | 15252977 | TEE |
| 5 | 15251951 | TEE |
| 6 | 15252983 | ELBOW |
| 7 | 15253043 | ADAPTOR |
| 8 | 15251938 | ADAPTOR |
| 9 | 15253182 | ELBOW |
| 10 | 15253042 | ADAPTOR |
| 11 | 15253040 | ADAPTOR |
| 12 | 179838 | BOLT |
| 13 | 15251979 | ADAPTOR |
| 14 | 15253064 | ADAPTOR |
| 15 | 15301184 | HOSE ASSY |
| 16 | 15253128 | TEE |
| 17 | 15253157 | ELBOW-BULKHEAD |
| 18 | 15253181 | ELBOW |
| 19 | 15252849 | ADAPTOR |
| 20 | 15251982 | ADAPTOR |
| 21 | 15253239 | ADAPTOR |
| 22 | 15253242 | ELBOW |
| 23 | 15251979 | ADAPTOR |
| 24 | 15252696 | ADAPTOR |
| 25 | 15254346 | ADAPTOR |
| 26 | 15254646 | ELBOW |
| 27 | 138252 | SCREW |
| 28 | 9417713 | NUT |
| 29 | 6525035 | VALVE ASSY-RECHARGE |
| 30 | 15251819 | NIPPLE-DIAGNOSTIC |
| 31 | 15253087 | HOSE ASSY |
| 32 | 15253130 | HOSE ASSY |
| 33 | 15256461 | HOSE ASSY |
| 34 | 15253200 | HOSE ASSY |
| 35 | 15254647 | HOSE ASSY |
| 36 | 15255184 | HOSE ASSY |
| 37 | 15300296 | HOSE ASSY |
| 38 | 15253480 | HOSE ASSY |
| 39 | 15253153 | REDUCER |
| 40 | 15253098 | NUT-SWIVEL |
| 41 | 15253318 | HOSE ASSY |
| 42 | 15251939 | ADAPTOR |
| 43 | 15253869 | CLAMP-PIPE |
| 44 | 15253870 | CLAMP-PIPE |
| 45 | 15300425 | PLATE |
| 46 | 7552191 | PAD |
| 47 | 15300825 | PLATE |
| 48 | 15253875 | CLAMP-PIPE |
| 49 | 109084 | NUT |
| 50 | 110633 | NUT |
| 51 | 7150815 | WASHER |
| 52 | 103329 | LOCK WASHER |
| 53 | 103340 | WASHER |
| 54 | 108580 | LOCK WASHER |
| 55 | 9267949 | WASHER-HARDENED |
| 56 | 147114 | SCREW |
| 57 | 179883 | BOLT |
| 58 | 102635 | NUT |
| 59 | 15252902 | TEE |
| 60 | 15258027 | HOSE ASSY(C)50HP X |
| 61 | 15001403 | CLAMP |
| 62 | 15001420 | BUSHING-SPLIT |
| 63 | 179850 | BOLT |
| 64 | 6350825 | BOLT |
| 65 | 179883 | BOLT |
| 66 | 9270000 | WASHER-HARDENED |
| 67 | 15300442 | U-BOLT |
| 68 | 15301185 | HOSE ASSY |
| 69 | 7161030 | LOCK WASHER |
| 70 | 7160630 | WASHER |
| 71 | 6350825 | BOLT |
| 72 | 15253061 | ADAPTOR |
| BRAKE ACCUMULATOR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15231753 | ACCUMULATOR-BRAKE LH |
| 2 | 103321 | LOCKWAHSER |
| 3 | 9055409 | PISTON |
| 4 | 9055408 | WASHER-BACKUP |
| 5 | 9055407 | RING |
| 6 | 9055401 | RING-PISTON |
| 7 | 9055397 | O RING |
| 8 | 7552191 | PAD |
| TREADLE VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15248653 | VALVE-TREADLE |
| 2 | 15268373 | KIT-SEAL |
| RETARDER CONTROL VALVE-BRAKES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15259155 | VALVE |
| 2 | 15268417 | KIT-SEAL |
| FILTER ASSEMBLY-DISC BRAKE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9055363 | BAFFLE ASSY |
| 2 | 9055364 | SEAL-CUP |
| 3 | 9066151 | ELEMENT |
| 4 | 444631 | PLUG (0.50") |
| CAB ASSEMBLY | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272038 | WINDSCREEN |
| 2 | 15272039 | GLASS-SIDE LH |
| 3 | 15272040 | GLASS-SIDE RH |
| 4 | 15272041 | COVER-LH |
| 5 | 15272042 | COVER-RH |
| 6 | 15272043 | GLASS-GEAR |
| 7 | 15272044 | WIPER MOTOR |
| 8 | 15272046 | LINKAGE |
| 9 | 15272047 | WIPER ARM |
| 10 | 15272048 | WIPER BLADE |
| 11 | 15272049 | GROMMET |
| 12 | 9379264 | TIE-CABLE |
| 13 | 15270781 | BOLT |
| 14 | 15250390 | LIGHT-CAB INTERIOR |
| 15 | 15265564 | BULB |
| 16 | 15272058 | SUN VISOR |
| 17 | 15271185 | WASHER |
| 18 | 15272065 | DASHBOARD |
| 19 | 15270890 | AIR DIFFUSER |
| 20 | 15270896 | HOSE-BULK PLASTIC |
| 21 | 15270794 | FILTER-AIR |
| 22 | 15270796 | SUPPORT-FILTER |
| 23 | 15272067 | HOSE BULK-PLASTIC |
| 24 | 15272068 | RING-PLASTIC |
| 25 | 15272069 | STRIKER |
| 26 | 15272070 | SCREW |
