Terex earthmoving equipment parts
STEERING LINKAGE
NC NO. QTY PART NO. DESCRIPTION
047 002 15237801 TERMINAL ASSY-LEFT TIE-ROD
048 005 00179839 ·BOLT
049 005 00108580 ·WASHER
050 001 15228998 ·TIE-ROD HEAD-LEFT
052 001 09018309 ·PLATE-COVER
053 001 00444571 ·PLUG
054 001 09018310 ·BAFFLE RING
055 001 09105216 ·BEARING
056 001 09372594 ·DOUBLE-SCREW BOLT
057 004 15317485 SEAL RING
058 008 00271563 BOLT
059 008 09354243 NUT
060 002 15237800 TERMINAL ASSY-RIGHT TIE-ROD
061 005 00179839 ·BOLT
062 005 00108580 ·WASHER
063 001 15228999 ·TIE-ROD HEAD-RIGHT
065 001 09018309 ·PLATE-COVER
066 001 00444571 ·PLUG
067 001 09018310 ·BAFFLE RING
068 001 09105216 ·BEARING
069 001 09372594 ·DOUBLE-SCREW BOLT
A NOTE SERIAL NO. LOWER THAN T2281037 (DETROIT) AND
T351001 (CUMMINS) NEED TO USE 9384856 PIN, FROM ABOVE TWO
SERIAL NO. NEED TO USE 15237869 PIN.
2-2
ACCUMULATOR
NC NO. QTY PART NO. DESCRIPTION
A 001 15007340 ACCUMULATOR ASSY
001 001 15245482 ·TUBE ASSY
002 001 15021812 ·PISTON
003 002 15021811 ·SEAL
004 001 15007338 ·CAP-END
005 001 09190980 ·O RING
006 001 09220661 ·RING-BACKUP
007 001 15002608 ·SHIELD
008 001 06525035 ·RECHARGE VALVE
009 006 0022347l ·BOLT
010 001 00274253 ·O RING
011 006 15007339 ·WASHER-HARDENED
A NOTE SUPER ACCUMULATOR ASSY IS 15002604
MULTIPLEX SAFETY VALVE
NC NO. QTY PART NO. DESCRIPTION
A 001 001 15247593 BODY-VALVE
002 001 15265078 ·PLUG
003 001 09038865 ·O RING
NOTE
A 15265696 VALVE SEAL UNIT.
| 9 | 9072627 | BOLT |
| 10 | 15310256 | WASHER-HARDENED |
| 11 | 15307380 | BRAKE ASSY |
| 12 | 223437 | BOLT |
| 13 | 9065332 | WASHER |
| 14 | 15247047 | SPRING HOUSING MACHINED |
| 15 | 9068505 | SCREW |
| 16 | 2276784 | SCREW-BLEED |
| 17 | 15258053 | SEAL-O RING |
| 18 | 784094 | PIN-DOWEL |
| 19 | 784088 | PIN-DOWEL |
| 20 | 9065306 | SPRING |
| 21 | 9065305 | SPRING |
| 22 | 15303608 | SEAL ASSY-PISTON |
| 23 | 15302125 | PARKING PISTON |
| 24 | 15258054 | SEAL-O RING |
| 25 | 15302126 | DISC HOUSING |
| 26 | 9183205 | PLUG |
| 27 | 274248 | O RING |
| 28 | 15302798 | DAMPER ASSY |
| 29 | 15302796 | DISC FRICTION |
| 30 | 15302797 | PLATE-SPLINTED |
| 31 | 15231497 | SERVICE PISTON MACHINED |
| 32 | 936559 | PIN |
| 33 | 179814 | BOLT |
| 34 | 9064810 | PLATE-RETAINER |
| 35 | 9064750 | PIN-RETAINING |
| 36 | 9065315 | SPRING |
| 37 | 444692 | PLUG |
| 38 | 15258051 | SEAL-D RING |
| 39 | 15258038 | SEAL-D RING |
| 40 | 15307381 | PISTON HOUSING ASSY |
| 41 | 15303368 | STUD |
| 42 | 15249911 | DUST CAP |
| 43 | 15303609 | GUIDE RING-PISTON |
| 44 | 15303611 | GUIDE RING-ROD |
| 45 | 15303610 | SEAL ASSY-ROD |
| 46 | 15256201 | DISC DRIVER |
| 47 | 9113457 | LOCK WIRE |
| 48 | 15247046 | HOUSING-SEAL |
| 49 | 15302759 | O RING |
| 50 | 9419497 | NUT-NYLON INSERT |
| 51 | 15247216 | SEAL ASSY |
| 52 | 15247433 | O RING |
| 53 | 15231422 | WASHER |
| FRONT RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15250974 | FRONT RIDE CYL ASSEM |
| 2 | 9384099 | CAP-END |
| 3 | 9411010 | FITTING-GREASE |
| 4 | 9013688 | VALVE-CHECK |
| 5 | 444613 | PLUG |
| 6 | 15016161 | O RING |
| 7 | 9069472 | RING-BACKUP |
