Terex earthmoving equipment parts
DOUBLE RELIEF VALVE
NC NO. QTY PART NO. DESCRIPTION
001 001 09019313 VALVE BODY
002 004 09034132 ·RING-BACKUP
003 002 09034130 ·O RING
004 002 09034129 ·O RING
005 002 09034131 ·RING-BACKUP
006 002 09034135 ·SPRING
007 002 09034133 ·SCREW
008 002 09025789 ·GASKET
008 002 09039882 ·CAP
010 002 00444698 ·PLUG
3-1 CABLES AND HARNESSES
NC NO. QTY PART NO. DESCRIPTION
001 001 15043284 INSTRUMENT HARNESSES
002 001 20018526 CAB HARNESSES
003 001 20019425 FRAME HARNESSES
004 001 15043285 HEADLIGHT HARNESSES
005 001 15040405 TAILLIGHT HARNESSES
006 001 20018530 ENGINE HARNESSES
007 001 15041698 BATTERY NEGTIVE CABLE
008 001 09350197 BATTERY SERIES CABLE
009 001 20018532 BATTERY POSITIVE CABLE
010 001 20019421 ATEC HARNESSES
011 001 15043288 POWER CABLE
012 001 15318108 POSITIVE CABLE
013 002 09384487 EARTH CABLE
014 001 20018529 ELECTRIC CONTROL ENGINE
HARNESSES
001 001 20009436 INCHING SWITCH
002 001 15047524 AIR FILTER SWITCH
003 001 02460404 BRAKING SWITCH
004
005
006 001 15300119 PRESSURE SENSOR
007 001 00125620 TRANSITION SWITCH
008 001 15043265 PRESSURE SENSOR
009 001 15003859 PRESSURE SWITCH
010 001 00119930 TRANSITION CONNECTION
011 001 15230575 PRESSURE SWITCH
012 001 20023154 INSTRUMENT CONTROLLER
| 1 | 15311848 | TRANS COOLER ASSY |
| STEERING LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15251951 | TEE |
| 2 | 15251938 | ADAPTOR |
| 3 | 15251937 | ADAPTOR |
| 4 | 15251939 | ADAPTOR |
| 5 | 15253340 | ADAPTOR |
| 6 | 15301808 | HOSE ASSY |
| 7 | 15252902 | TEE |
| 8 | 15253094 | ADAPTOR |
| 9 | 15251945 | ELBOW |
| 10 | 15253129 | ELBOW |
| 11 | 15253219 | ELBOW |
| 12 | 15252681 | ELBOW |
| 13 | 7150815 | WASHER |
| 14 | 15254978 | ELBOW |
| 15 | 15253040 | ADAPTOR |
| 16 | 15252977 | TEE |
| 17 | 15253220 | ADAPTOR |
| 18 | 15252696 | ADAPTOR |
| 19 | 15254988 | BRACKET |
| 20 | 15254921 | CLAMP |
| 21 | 15254991 | BRACKET |
| 22 | 15301623 | HOSE ASSY-16HP(ORFS) |
| 23 | 15301624 | HOSE ASSY-16HP(ORFS) |
| 24 | 15301625 | HOSE ASSY-12HPHT(ORFS) |
| 25 | 15301626 | HOSE ASSY-12HPHT(ORFS) |
| 26 | 15301809 | HOSE ASSY |
| 27 | 15254949 | HOSE ASSY |
| 28 | 15254950 | HOSE ASSY |
| 29 | 15254951 | HOSE ASSY |
| 30 | 15254952 | HOSE ASSY |
| 31 | 15254953 | HOSE ASSY |
| 32 | 15254954 | HOSE ASSY |
| 33 | 15254955 | HOSE ASSY (C) .75HPHT |
| 34 | 15254957 | HOSE ASSY |
| 35 | 15254958 | HOSE ASSY |
| 36 | 15255148 | HOSE ASSY |
| 37 | 15255612 | HOSE ASSY |
| 38 | 15255316 | HOSE ASSY |
| 39 | 15255113 | HOSE ASSY |
| 40 | 15255123 | TUBE ASSY |
| 41 | 15301524 | TUBE CLAMP DIA.32-DOUB |
| 42 | 15001429 | CLAMP |
| 43 | 15001428 | NUT-STACKING |
| 44 | 15001427 | ADAPTOR-THREAD |
| 45 | 179839 | BOLT |
| 46 | 15001430 | CLAMP |
| 47 | 15004748 | NUT-STACKING |
| 48 | 179889 | BOLT |
| 49 | 15014977 | BUSHING-SPLIT |
| 50 | 9410971 | O RING |
| 51 | 179885 | BOLT |
| 52 | 9409985 | FLANGE-SPLIT |
| 53 | 103329 | LOCKWASHER |
| 54 | 9409982 | FLANGE-SPLIT |
| 55 | 9410968 | O RING |
| 56 | 179841 | BOLT |
| 57 | 108580 | LOCKWASHER |
| 58 | 15255216 | HOSE ASSY |
| 59 | 15255218 | HOSE ASSY |
| 60 | 6351020 | BOLT |
| 61 | 102635 | BOLT |
| 62 | 179837 | BOLT |
| 63 | 15004748 | NUT-STACKING |
| 64 | 15004712 | CLAMP |
| 65 | 15015251 | BUSHING-SPLIT |
| 66 | 15251819 | NIPPLE-DIAGNOSTIC |
| 67 | 9052234 | PLUG |
| 68 | 186285 | BOLT .38*4.00 |
| 69 | 15255345 | HOSE ASSY |
| 70 | 271565 | BOLT |
| 71 | 15301628 | STACKING SCREW |
| 72 | 15253060 | ELBOW |
| 73 | 15255611 | REDUCER |
| 74 | 15244893 | NUT-STACKING |
| 75 | 15305414 | HOSE ASSY |
| 76 | 15255890 | ELBOW |
| 77 | 15001403 | CLAMP |
| 78 | 15244830 | ELBOW |
| 79 | 106263 | WASHER |
| 80 | 15301627 | BENT-PLATE |
| PUMP-STEERING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15256582 | STEERING PUMP |
| 2 | 15270819 | PLATE-VALVE |
| 3 | 15270818 | KIT-ROTATING GROUP |
| 4 | 15270821 | SHAFT |
| PUMP AND ACCUMULATOR MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9016036 | STRAP |
| 2 | 9417713 | NUT |
| 3 | 106263 | WASHER |
| 4 | 15230188 | GUARD |
| 5 | 179881 | BOLT |
| 6 | 103329 | LOCKWASHER |
| 7 | 9156021 | GASKET |
| 8 | 9179585 | STUD |
| 9 | 103028 | NUT |
| 10 | 9267949 | WASHER-HARDENED |
| 11 | 179883 | BOLT |
| 12 | 15251035 | COVER PLUG-ACCUM |
| 13 | 179885 | BOLT |
| 14 | 15004932 | ADAPTOR-PUMP MTG |
| 15 | 9206866 | GASKET |
| 16 | 15244763 | COUPLING-SPLIEND |
| 17 | 9172766 | O RING |
| ACCUMULATOR-STEERING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6525035 | VALVE ASSY-RECHARGE |
| 2 | 274253 | O RING |
| 3 | 223453 | BOLT |
| 4 | 9036867 | RING-BACKUP |
| 5 | 9169669 | O RING |
| 6 | 9018820 | SEAL |
| 7 | 9018813 | PISTON |
| 8 | 9018819 | RING-WEAR |
| STEERING VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 457151 | BEARING |
| RELIEF VALVE-STEERING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15265078 | CARTRIDGE |
| STEERING CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9014528 | CYLINDER-STEERING |
| 2 | 9014535 | TUBE |
| 3 | 9167506 | BEARING-SPHERICAL |
| 4 | 9425517 | RING-SNAP |
| 5 | 9014542 | ROD |
| 6 | 9256601 | WIPER |
| 7 | 9014532 | SEAL AND RING-BACKUP |
| 8 | 271565 | BOLT |
| 9 | 9256136 | RING-BACKUP |
| 10 | 9141862 | O RING |
| 11 | 9256074 | RING-PISTON |
| 12 | 274191 | LOCKNUT |
| 13 | 179883 | BOLT |
| 14 | 103329 | LOCKWASHER |
