TEREX 15272790 SEAL KIT NHL RIGID DUMP TRUCK TR35 TR50 TR60 TR100 3305B 3305F 3303 3307 TR45 TR70 MT4400 CUMMINS

Terex earthmoving equipment parts

DOUBLE RELIEF VALVE
NC NO. QTY PART NO. DESCRIPTION
001 001 09019313 VALVE BODY
002 004 09034132 ·RING-BACKUP
003 002 09034130 ·O RING
004 002 09034129 ·O RING
005 002 09034131 ·RING-BACKUP
006 002 09034135 ·SPRING
007 002 09034133 ·SCREW
008 002 09025789 ·GASKET
008 002 09039882 ·CAP
010 002 00444698 ·PLUG
3-1 CABLES AND HARNESSES
NC NO. QTY PART NO. DESCRIPTION
001 001 15043284 INSTRUMENT HARNESSES
002 001 20018526 CAB HARNESSES
003 001 20019425 FRAME HARNESSES
004 001 15043285 HEADLIGHT HARNESSES
005 001 15040405 TAILLIGHT HARNESSES
006 001 20018530 ENGINE HARNESSES
007 001 15041698 BATTERY NEGTIVE CABLE
008 001 09350197 BATTERY SERIES CABLE
009 001 20018532 BATTERY POSITIVE CABLE
010 001 20019421 ATEC HARNESSES
011 001 15043288 POWER CABLE
012 001 15318108 POSITIVE CABLE
013 002 09384487 EARTH CABLE
014 001 20018529 ELECTRIC CONTROL ENGINE
HARNESSES
001 001 20009436 INCHING SWITCH
002 001 15047524 AIR FILTER SWITCH
003 001 02460404 BRAKING SWITCH
004
005
006 001 15300119 PRESSURE SENSOR
007 001 00125620 TRANSITION SWITCH
008 001 15043265 PRESSURE SENSOR
009 001 15003859 PRESSURE SWITCH
010 001 00119930 TRANSITION CONNECTION
011 001 15230575 PRESSURE SWITCH
012 001 20023154 INSTRUMENT CONTROLLER
NC NO. QTY PART NO. DESCRIPTION
001 004 15230426 HEADLAMP
002 004 15265363 BULB
003 004 00102635 NUT
004 002 15258783 STEERING INDICATED LAMP
005 002 15271430 BULB
006 002 15258872 BULB
007 001 09037733 GROMMET
008 008 00103320 LOCKWASHER
009 008 00102634 NUT
010 002 00117965 GROMMET
011 001 09269377 BULB
012 001 00446914 BULB
013 002 15258792 LIGHT-STOP/TAIL/STEERING
014 001 15001878 REVERSE ALARM
015 001 15044102 BRACKET-REAR LIGHT
016 004 09004006 LOCKWASHER
ELECTRICAL ILLUMINATION SYSTEM
NC NO. QTY PART NO. DESCRIPTION
001 004 15230426 HEADLIGHT
002 004 15265363 BULB
003 004 00102635 NUT
004 002 15258783 DIRECTION INDICATOR LIGHT
005 002 15271430 BULB
006 002 15258872 BULB
007 001 09037733 EYESHIELD RING
008 008 00103320 LOCKWASHER
009 008 00102634 NUT
010 002 00117965 EYESHIELD RING
011 001 20018522 LAMP
012 001 00446914 BULB
013 002 15258792 PARKING LIGHT, TAILLIGHT, DIRECTION
INDICATOR LIGHT
014 001 15001878 REVERSE WARNING LIGHT
015 001 15044102 REAR LAMP BRACKET
016 004 09004006 LOCKWASHER
