Terex earthmoving equipment parts
NC NO. QTY PART NO. DESCRIPTION
001 001 20019301 BRACKET ASSY
002 001 20019302 BRACKET ASSY
003 001 20019311 HYDRAULIC TANK WELDING
UNIT
004 008 09191596 WASHER 0.62
005 008 00223436 BOLT 5/8-11×2.00
006 004 00186646 BOLT 1/2-13×1.75
007 008 09267949 GASKET 0.50
008 004 00103329 SPRING GASKET 0.50
009 005 09228441 COVER PLATE
010 030 00179839 BOLT 3/8-16×1.00
011 030 00108580 WASHER 0.38
012 005 09202069 SEALING GASKET
013 001 09038953 ELEMENT KIT
014 001 15230178 OPENING NUT
015 001 15250940 FILTER ASSY
016 001 15265318 ·ELEMENT KIT
017 002 09246992 COVER ASSY
018 002 09247259 ·SEALING GASKET
019 004 00274766 NUT 1/2-13UNC 2B
020 004 00274856 LOCKNUT 0.25-20
021 002 09260647 COVER PLATE
022 002 09260645 SCREEN
023 002 15225962 END CAP
024 002 20005910 BRACKET ASSY
NC NO. QTY PART NO. DESCRIPTION
025 004 00215305 BOLT 0.25-20UNC-5.25
026 002 15230961 BALL VALVE 1/2NPT
027 002 15036694 ADAPTER 1/2NPT
028 001 09368472 RELIEF VALVE ASSY
029 001 09368473 ·FLANGE
030 001 09368474 ·HOLDING BRACKET
031 001 09194725 ·COLUMN PLUG
032 001 09194726 ·SPRING
033 006 09003522 BOLT ROD
034 006 02389616 WING NUT
035 003 00444631 PLUG
036 001 09188288 SEALING GASKET
NC NO. QTY PART NO. DESCRIPTION
001 20011793 PUMP
HOIST CYLINDER
NC NO. QTY PART NO. DESCRIPTION
001 15248543 HOIST CYLINDER
001 001 09019955 ·TUBE-OUTSIDE CYLINDER
002 001 15232135 ·END ASSY
A 003 001 09014200 ·BUSHING
A 004 001 09014362 ·RING-BACKUP
A 005 001 09014593 ·O RING
A 006 001 09256605 ·WIPER
A 007 001 09014129 ·WEARING RING
A 008 001 09270712 ·SEAR RING
009 012 00274821 ·LOCKNUT
C 010 002 15232053 ·T SEAL RING
011 001 15232134 ·TUBE-INNER CASING
B 012 001 09431967 ·PLUG
013 001 15248528 ·TUBE
A 014 002 09014301 ·RING-PISTON
A 015 001 09014132 ·WEARING RING
A 016 001 09256603 ·WIPER
A 017 002 09014130 ·WEARING RING
A 018 001 09272943 ·SEAL RING
019 002 15248536 ·TUBE-CYLINDER
A 020 001 09014131 ·WEARING RING
A 021 001 09132790 ·O RING
A 022 001 09014363 ·RING-BACKUP
023 001 09015489 ·BASE ASSY
024 001 09014200 ·BUSHING
TABLE NO.
NC NO. QTY PART NO. DESCRIPTION
025 012 00271568 ·BOLT
A NOTE CONTAIN IN 09394720 REPAIR KIT.
B NOTE SEE REPORT B520.
C NOTE SEE REPORT B715.
| 24 | 9015489 | BASE ASSY |
| 25 | 271568 | BOLT |
| 26 | 9411010 | REPAIR KIT |
| HYDRAULIC CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9264848 | VALVE-CONTROL |
| 2 | 9410967 | O RING |
| CONTROL VALVE LINKAGE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179837 | BOLT |
| 2 | 179843 | BOLT |
| 3 | 108580 | LOCK WASHER |
| 4 | 102635 | NUT |
| 5 | 9060202 | WASHER-HARDENED |
| 6 | 179847 | BOLT |
| 7 | 179891 | BOLT |
| 8 | 103329 | LOCK WASHER |
| 9 | 114496 | NUT |
| 10 | 103498 | PIN |
| 11 | 103385 | COTTER PIN |
| 12 | 9169494 | CLEVIS |
| 13 | 179841 | BOLT |
| REVERSE HOIST INTERLOCK | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9381253 | SWITCH ASSY |
| 2 | 179838 | BOLT |
| 3 | 108580 | LOCK WASHER |
| 4 | 9060202 | WASHER-HARDENED |
| 5 | 110633 | NUT |
| 6 | 15232556 | HARNESS-SEC MODE |
| VALVE-FLOW CONTROL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15014890 | VALVE ASSY |
| 2 | 9034127 | O RING |
| 3 | 9031299 | O RING |
| 4 | 444698 | PLUG |
| 5 | 9034132 | RING BACKUP |
| 6 | 9034130 | O RING |
| 7 | 9034129 | O RING |
| 8 | 9034135 | SPRING |
| 9 | 9025789 | GASKET |
| 10 | 114496 | NUT |
| 11 | 9036136 | O RING |
| 12 | 9058415 | POPPET |
| 13 | 444692 | PIPE PLUG -.25 |
| FUEL TANK AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103332 | LOCK WASHER |
| 2 | 220081 | NUT |
| 3 | 9355771 | NUT |
| 4 | 9251163 | CAP ASSY |
| 5 | 9251092 | GASKET |
| 6 | 9183385 | GASKET |
| 7 | 9160607 | STRAINER |
| 8 | 9027836 | GASKET |
| 9 | 9049192 | DIAL |
| 10 | 103329 | LOCK WASHER |
| 11 | 179883 | BOLT |
| 12 | 9268885 | LOCK |
| 13 | 9141915 | O RING |
| FUEL LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 108686 | ELBOW |
| 2 | 9136638 | NIPPLE |
| 3 | 116487 | CONNECTOR |
| ACCELERATOR LINKAGE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179837 | BOLT |
| 2 | 179818 | BOLT |
| 3 | 103320 | LOCK WASHER |
| 4 | 108580 | LOCK WASHER |
| 5 | 179847 | BOLT |
| 6 | 102635 | NUT |
| 7 | 109084 | HEXAGON NUT |
| 8 | 102634 | NUT |
| 9 | 103340 | WASHER-PLAIN |
| 10 | 9100399 | SPRING |
| 11 | 103319 | LOCK |
| 12 | 106263 | WASHER-PLAIN |
| RADIATOR MOUNTING AND HOSES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179889 | BOLT |
| 2 | 103329 | LOCK WASHER |
| 3 | 116436 | CONNECTOR |
| 4 | 179887 | BOLT |
| 5 | 9267949 | WASHER-HARDENED |
| 6 | 271621 | BOLT |
| 7 | 220081 | HEXAGON NUT |
| 8 | 103332 | LOCK WASHER |
| 9 | 9014683 | ROD |
| 10 | 9187694 | WASHER |
| 11 | 9186377 | MOUNTING PAD-FLEXIBLE |
| 12 | 9182221 | MOUNTING PAD-FLEXIBLE |
| 13 | 179841 | BOLT |
| 14 | 108580 | LOCK WASHER |
| 15 | 102635 | NUT |
| 16 | 274210 | LOCK NUT |
| 17 | 9210713 | CLAMP |
| 18 | 9003506 | HOSE |
| 19 | 9158575 | HOSE |
| 20 | 9160723 | DRAIN COCK |
| 21 | 106263 | WASHER-PLAIN |
| 22 | 179839 | BOLT |
| 23 | 179889 | BOLT |
| 24 | 274208 | LOCK NUT |
| 25 | 179847 | BOLTS |
| RADIATOR ASSY | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15308789 | RADIATOR ASSY |
| 2 | 15275185 | TOP TANK |
| 3 | 15275186 | BOTTOM TANK |
| 4 | 15268705 | FRAME LH SIDE |
| 5 | 15268706 | FRAME RU SIDE |
| 6 | 15268707 | CROSS STUD |
| 7 | 15271380 | CLAMP-CROSS BRACE |
| 8 | 15275187 | CASTELATED STRIP |
| 9 | 15268676 | FERRULE RUBBER |
| 10 | 15275188 | SPACER TUBE STAY |
| 11 | 15268693 | SCREW |
| 12 | 15268682 | FLAT WASHER |
| 13 | 15268694 | LOCK WASHER |
| 14 | 15268681 | NUT |
| 15 | 179839 | BOLT |
| 16 | 9060020 | WASHER |
| 17 | 274208 | NUT |
| 18 | 103331 | LOCK WASHER |
| 19 | 114498 | NUT |
