Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
WhatsApp : 008618264966991
Terex earthmoving equipment parts
| 000 001 15252682 PTO ASSY 001 001 09060235 .HOUSING ASSY 002 002 00784079 ..PIN 003 002 00179826 ..BOLT 004 002 00103320 ..LOCKWASHER 005 001 09004541 .SEAL 006 004 00444637 .PLUG 007 017 00179826 .BOLT 008 015 00103320 .LOCKWASHER 009 001 09004540 .SEAL 010 002 00954528 .BEARING 011 002 00907696 .BEARING 012 001 09274893 .GEAR-DRIVEN 013 001 00444692 .PLUG 014 001 09195847 .GEAR-DRIVE 015 001 15252439 .SHAFT-DRIVE PTO 016 001 00144218 .BUSHING 017 002 09414895 .RING-SNAP 018 001 09195842 .GASKET 019 001 00187396 .COUPLING 020 001 15247042 .BREATHER ASSY 021 001 06750967 .CAP-BREATHER 022 001 00444698 .PLUG 023 001 15252646 SPACER-PTO 024 006 00179874 BOLT 025 010 00103328 LOCKWASHER 026 004 09415092 BOLT 027 001 15300845 YOKE-PTO 028 001 09071870 WASHER-HARDENED 029 001 09269703 LOCKNUT |
| SWITCHES AND INSTRUMENTS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15256433 | SPEEDOMETER |
| 2 | 15256026 | TACHOMETER |
| 3 | 15258289 | GAUGE ENG. 0IL PRESS |
| 4 | 15258291 | GAUGE ENG WATER TEMP E. |
| 5 | 15258288 | GAUGE TRANS OIL TEMP E. |
| 6 | 15300413 | GAUGE-FUEL LEVEL |
| 7 | 15300128 | GAUGE-TRANS OIL PRES |
| 8 | 15258795 | SWITCH-HAZARDS |
| 9 | 15258798 | SWITCH-LIGHTS |
| 10 | 15258796 | SWITCH-TEST |
| 11 | 15237165 | LENS-HAZARD LIGHTS |
| 12 | 15237163 | LENS-LIGHTS |
| 13 | 15265325 | BULB-SWITCHES |
| 14 | 15300563 | LENS；TRANSMISSION CHECK |
| 15 | 15237161 | SWITCH-COLUMN |
| 16 | 15300587 | MODULE,WARNING LIGHTS |
| 17 | 15271204 | BULB AND SOCKET-MODULE |
| 18 | 15300588 | MODULE,WARNING LIGHTS |
| 19 | 15300589 | MODULE,WARNING LIGHTS |
| 20 | 9079062 | DIODE-BLOCK |
| 21 | 15227360 | BUZZER |
| 22 | 15256444 | RELAY |
| 23 | 15244724 | FLASHER UNIT |
| 24 | 15247615 | FUSE-3 AMP |
| 25 | 15247614 | FUSE-5 AMP |
| 26 | 15247612 | FUSE-10 AMP |
| 27 | 15247611 | FUSE-15 AMP |
| 28 | 15248347 | FUSE-25 AMP |
| 29 | 15302871 | TIMER RELAY |
| 30 | 15300658 | SWITCH,-PUSH/TWIST |
| 31 | 15257770 | KEYSWITCH |
| 32 | 15271326 | KEY-IGNITION |
| 33 | 15301699 | SWITCH-PUSH/TWIST |
| 34 | 15258797 | SWITCH |
| 35 | 15301692 | LENS-RETARDER |
| 36 | 15229156 | LENS-TEST SWITCH |
| 37 | 15273771 | BULB-VDO GAUGES |
| 38 | 15256924 | SCREW |
| SEAT-DRIVER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15302059 | SEAT ASSY-HIGH BACK |
| 2 | 15269020 | KIT-HT RISER SPRING |
| 3 | 15503341 | KIT-DAMPER(NEW) |
| 4 | 15269028 | KIT-24V COMP/VALVE |
| 5 | 7161230 | LOCKWASHER |
| 6 | 6350830 | BOLT |
| 7 | 7150815 | WASHER |
| 8 | 7160830 | LOCKWASHER |
| 9 | 6430801 | NUT |
| SEAT-INSTRUCTOR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6350825 | BOLT |
| 2 | 7160830 | LOCKWASHER |
| 3 | 6351020 | BOLT |
| 4 | 7161030 | LOCKWASHER |
| 5 | 103340 | WASHER |
| 6 | 274209 | LOCKNUT |
