Terex earthmoving equipment parts
2-2
WHEEL, RIM AND TYRE-FRONT
NC NO. QTY PART NO. DESCRIPTION
001 001 09270229 WHEEL-FRONT
002 016 09253468 STUD
003 001 09250686 RING-SNAP
004 001 09016971 WASHER
005 001 09433277 CONE-INNER BEARING
006 001 09433278 CUP-INNER BEARING
A 008 001 20020699 RIM
A 009 002 20020701 RETAINER RING
A 010 001 20020700 RING
A 011 001 20020702 LOCK RING
012 001 09003519 O RING
013 001 15231599 ROD-VALVE
014 001 09142286 ·CORE
015 001 09116292 ·CAP
016 001 09432641 CUP-OUTER BEARING
NC NO. QTY PART NO. DESCRIPTION
017 001 09432640 CONE-OUTER BEARING
018 ASR 09253679 0.005"SHIM
ASR 09253680 0.007"SHIM
ASR 09253681 0.20"SHIM
019 001 09253619 PLATEN
020 006 09253620 BOLT
021 001 09115806 COVER
022 006 00179881 BOLT
023 006 00103329 LOCKWASHER
024 015 09433576 NUT
025 001 09016973 SEAL
026 016 15023746 CLAMP
027 ASR 09113457 LOCKWIRE
028 001 09207478 GASKET
B N1 001 213536E3 TYRE
A NOTE ITEMS 8, 9, 1O AND 11 MARKED BY NHL V046 AND NHL
V048 ARE FROM DIFFERENT MANUFACTURES. NEVER USE
ITEMS 8, 9, 10, 11 WITH DIFFERENT IDENTIFICATIONS ON ONE
TYRE.
B NOTE SELECT SPARE TYRE 21 00R35XHD,SEE 8—02—322
NOTE B
| SEAT-INSTRUCTOR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6350825 | BOLT |
| 2 | 7160830 | LOCKWASHER |
| 3 | 6351020 | BOLT |
| 4 | 7161030 | LOCKWASHER |
| 5 | 103340 | WASHER |
| 6 | 274209 | LOCKNUT |
| 7 | 9068666 | WASHER-HARDENED |
| 8 | 120378 | NUT |
| 9 | 103329 | LOCKWASHER |
| AIR CONDITIONER/HEATER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272300 | THERMOSTAT |
| 2 | 15272303 | EVAPORATOR MATRIX |
| 3 | 15271344 | O RING |
| 4 | 15271334 | O RING |
| 5 | 15270348 | VALVE-EXPANSION |
| 6 | 15271338 | O RING |
| 7 | 15272304 | ADAPTOR NO 6 |
| 8 | 15272305 | ADAPTOR NO 10 |
| 9 | 15270360 | CONDENSER |
| 10 | 15270374 | CLIP |
| 11 | 15270361 | RECEIVER |
| 12 | 15270363 | SWITCH-TRINERY |
| 13 | 15270358 | COMPRESSOR 134A |
| HEATER LINES AND WIRING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 109084 | NUT |
| 2 | 144034 | BUSHING |
| 3 | 179795 | BOLT |
| 4 | 454111 | ELBOW |
| 5 | 9379664 | CLAMP |
| 6 | 7551826 | HOSE-BULK |
| 7 | 9014950 | CONNECTOR |
| 8 | 15230961 | VALVE-BALL SHUT OFF |
| 9 | 9181284 | CLIP |
| 10 | 102635 | NUT |
| 11 | 9136387 | NIPPLE |
| 12 | 9131874 | CLAMP |
| 13 | 15001405 | CLAMP |
| 14 | 108580 | WASHER |
| 15 | 179839 | BOLT |
| AIR CONDITIONER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15271338 | O RING |
| 2 | 15271334 | O RING |
| 3 | 15271349 | HOSE ASSY |
| 4 | 15271351 | HOSE ASSY |
| 5 | 15271350 | HOSE ASSY |
| 6 | 15270352 | HOSE ASSY |
| 7 | 15271344 | O RING |
| 8 | 15271352 | GUARD-BELT |
| 9 | 15271353 | BELT-DRIVE |
| 10 | 15270369 | BRACKET |
| 11 | 179795 | BOLT |
| 12 | 103319 | LOCKWASHER |
| 13 | 109084 | NUT |
| 14 | 103320 | LOCKWASHER |
| 15 | 15245671 | BRACKET-CONDENSER |
| 16 | 15270360 | CONDENSER |
| 17 | 15270374 | CLIP |
| 18 | 15270361 | RECEIVER |
| 19 | 15270363 | SWITCH-TRINERY |
| 20 | 15270358 | COMPRESSOR-134A |
| 21 | 9152893 | P CLIP |
| 22 | 9131865 | P CLIP |
| 23 | 179795 | BOLT |
