Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Terex earthmoving equipment parts
NC N
O. QTY PART NO. DESCRIPTION
001 002 09016367 DRUM-BRAKE
002 032 09011226 WASHER
003 032 00223457 BOLT
004 002 09016363 SPRING-RETURN
005 004 09380214 SHOE ASSY
006 004 15227297 ·ROLLER
007 004 09114428 ·PIN
008 064 09422277 ·NUT
A 009 064 15306850 ·PLUG
010 004 09250561 ·BUSHING
A 011 008 NSS ·SHOE
012 032 15306515 ·SCREW
013 002 09016361 WASHER
NC NO. QTY PART NO. DESCRIPTION
014 006 00274770 RING-SNAP
015 002 09158072 PLATE-CONNECTING
016 012 09016360 OIL SEAL
017 004 09016364 STEADY PIN
018 004 00456264 LOCKWASHER
019 004 00218407 NUT
020 004 09411010 NIPPLE
021 001 09016369 CAM SHAFT-LH
022 001 09016368 CAM SHAFT-RH
023 004 15012280 FENDER
024 020 00179883 BOLT
025 020 09270000 WASHER-HARDENED
026 020 15013577 WASHER
A NOTE 015231967 GASKET MUST BE CONSISTED BY PLUG AND
GASKET.
| 1 | 15020938 | PUMP-HYDRAULIC |
| 2 | 9036076 | SPACER |
| 3 | 9035829 | O RING |
| 4 | 9031475 | SEAL |
| 5 | 9036083 | SEAL-POCKET |
| 6 | 9058893 | PLATE |
| 7 | 9036082 | SEAL-GASKET |
| 8 | 9054807 | GEAR-SET |
| 9 | 9411566 | NUT |
| 10 | 9054024 | PLATE |
| 11 | 9058892 | SEAL |
| 12 | 9156021 | GASKET |
| 13 | 9179585 | STUD |
| 14 | 103028 | NUT |
| CONTROL VALVE-BODY HOIST | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15302549 | VALVE-BODY HOIST |
| 2 | 15272692 | KIT-SEAL |
| CONTROL VALVE MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 223436 | BOLT |
| 2 | 9411566 | NUT |
| 3 | 186689 | BOLT |
| 4 | 15245078 | BOLT |
| 5 | 274766 | NUT |
| JOYSTICK-BODY CONTROL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15302550 | VALVE-BODY CONTROL |
| 2 | 15272027 | GUIDE BUSH ASSY |
| 3 | 15272028 | SEAL KIT |
| KICK-OVER VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15014890 | VALVE KICK OVER |
| 2 | 9034127 | O RING |
| 3 | 9031299 | O RING |
| 4 | 444698 | PLUG |
| 5 | 9034132 | RING-BACKUP |
| 6 | 9034130 | O RING |
| 7 | 9034129 | O RING |
| 8 | 9034135 | SPRING |
| 9 | 9025789 | O RING |
| 10 | 114496 | NUT-JAM |
| 11 | 9036136 | O RING |
| 12 | 444692 | PLUG |
| KICK-OVER VALVE MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 271564 | BOLT |
| 2 | 274208 | LOCK NUT |
| RELIEF VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15228109 | VALVE-RELIEF |
| 2 | 9025789 | O RING |
| 3 | 9034127 | O RING |
| 4 | 9038666 | RING-BACKUP |
| 5 | 9031299 | O RING |
| PILOT SUPPLY VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15301128 | VALVE-PILOT SUPPLY |
| 2 | 15272119 | KIT-SEAL |
| HOIST CYLINDERS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15258006 | LIFT CYLINDER ASSEMBLY |
| 2 | 15232135 | END ASSY |
| 3 | 9014200 | BUSHING |
| 4 | 9014131 | RING-WEAR |
| 5 | 9014633 | RING-PISTON |
| 6 | 9014635 | RING-BACKUP |
| 7 | 9014636 | O RING |
| 8 | 9018420 | RING-WEAR |
| 9 | 9256608 | WIPER |
| 10 | 9270713 | SEAL |
| 11 | 9354243 | LOCK NUT |
| 12 | 15227030 | WIPER |
| 13 | 15227031 | RING-WEAR |
| 14 | 15227032 | SEAL |
| 15 | 15232053 | SEAL-T |
| 16 | 9014362 | RING-BACKUP |
| 17 | 9014593 | O RING |
| 18 | 15245036 | BOLT HEX 0.62-11 UNC |
| 19 | 15257992 | TUBE ASSY |
| 20 | 15258003 | TUBE ASSY |
| 21 | 9014200 | BUSHING |
| 22 | 6944596 | RING-WEAR |
| 23 | 103329 | LOCK WASHER |
| 24 | 108580 | LOCK WASHER |
| 25 | 179883 | BOLT T50 |
| 26 | 187394 | COUPLING |
| 27 | 9015218 | PIN |
| 28 | 9122232 | HOSE ASSY |
| 29 | 9131853 | CLIP |
| 30 | 9217321 | WASHER |
| 31 | 9402823 | ELBOW |
| 32 | 9411010 | FITTING-GREASE |
| 33 | 9411019 | NIPPLE-GREASE |
