Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Terex earthmoving equipment parts
NC NO. QTY PART NO. DESCRIPTION
001 09256203 REAR BRAKE PUMP
A 001 008 00120368 ·NUT
002 008 00103320 ·LOCKWASHER
003 001 NSSASSY ·BODY
004 001 09033730 ·TAG
005 008 09034481 ·GASKET
006 001 09033736 ·DUST PROOF SHIELD
007 008 09428735 ·BOLT
008 001 09049316 ·FIXED DISK
009 001 09023218 ·FIXED DISK
010 001 09049312 ·CUP RING
011 001 09049311 ·GUIDE SLEEVE
012 001 09049317 ·SHAFT
013 008 00103319 ·LOCKWASHER
A 014 008 00120367 ·NUT
015 001 02466109 ·SEAT RING
016 001 09049315 ·SPRING-RETURN
017 001 02466115 ·BEARING
018 008 00120221 ·SCREW
019 008 00121801 ·LOCKWASHER
020 001 02466113 ·COVER
NC NO. QTY PART NO. DESCRIPTION
021 001 02466114 ·O RING
022 001 02466117 ·O RING
023 001 02466112 ·O RING
024 001 09049314 ·SHELL
025 002 02466126 ·STUD
026 002 00103325 ·LOCKWASHER
027 003 00114498 ·NUT
028 001 02466118 ·PISTON
029 008 02466120 ·ROLLER
030 001 02466119 ·LOCK SLEEVE
031 001 02466121 ·WASHER
032 001 02466122 ·SPRING
033 001 02466106 ·CAP
034 001 02466116 ·FELT PAD
035 001 02466125 ·DISK
036 001 03858065 ·CIRCLIP
037 001 09049313 ·PISTON
038 001 02466107 ·CLEVIS ASSY
039 001 0903551l ·PIN
040 001 00103398 ·COTTER PIN
A NOTE IF COARSE THREAD NECESSARY USE EIGHT PIECES OF
120376 NUT 5 16—18 AND EIGHT PIECES OF 120375 NUT l 4—20.
| 22 | 9193182 | YOKE |
| 23 | 433142 | BOLT |
| 24 | 273469 | PLUG |
| 25 | 179860 | BOLT |
| 26 | 103328 | LOCK WASHER |
| TRANSMISSION MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9072457 | YOKE |
| 2 | 15017155 | TRUNNION |
| 3 | 9354243 | LOCK NUT |
| 4 | 9191596 | WASHER |
| 5 | 271563 | BOLT |
| 6 | 103320 | LOCK WASHER |
| 7 | 9272246 | TUBE |
| 8 | 9272248 | DIPSTICK-OIL |
| 9 | 106263 | WASHER |
| 10 | 108580 | LOCK WASHER |
| 11 | 102635 | NUT |
| 12 | 23011919 | YOKE |
| 13 | 271621 | BOLT |
| 14 | 9250715 | WASHER-HARDENED |
| 15 | 9355771 | NUT |
| 16 | 271612 | BOLT |
| 17 | 103332 | LOCK WASHER |
| 18 | 179838 | BOLT |
| 19 | 179818 | BOLT |
| 20 | 444613 | PLUG |
| 21 | 187396 | COUPLING |
| 22 | 9015715 | CLAMP |
| 23 | 9268885 | LOCK |
| 24 | 6771144 | NUT |
| 25 | 6771612 | RETAINER |
| 26 | 9416389 | NUT |
| 27 | 15229327 | PLATE |
| 28 | 9066008 | RING |
| TRANSMISSION SHIFT CONTROL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103319 | LOCK WASHER |
| 2 | 9250757 | CABLE ASSY |
| 3 | 103024 | NUT |
| 4 | 108580 | LOCK WASHER |
| 5 | 179845 | BOLT |
| 6 | 179839 | BOLT |
| 7 | 106263 | WASHER |
| 8 | 102635 | NUT |
| 9 | 179818 | BOLT |
| 10 | 103320 | LOCK WASHER |
| 11 | 179843 | BOLT |
| 12 | 9049109 | CABLE ASSY |
| 13 | 179795 | BOLT |
| 14 | 191474 | JOINT BALL |
| TRANSMISSION FILTER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23018846 | SWITCH |
| 2 | 1196599 | SEAL OIL FILTER |
| 3 | 15270495 | ELEMENT |
| 1 | 1300653 | BOWL-OIL FILTER |
| TRANSMISSION OIL LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9264303 | O RING |
| 2 | 9409985 | FLANGE-SPLIT |
| 3 | 103329 | LOCK WASHER |
| 4 | 179885 | BOLT |
| 5 | 9015533 | HOSE ASSY |
| 6 | 9012209 | ELBOW |
| 7 | 2369508 | STUD-CLAMPING |
| 8 | 116453 | ELBOW |
| 9 | 127887 | ELBOW |
| 10 | 9256512 | TEE |
| 11 | 103331 | LOCK WASHER |
| 12 | 9410286 | ELBOW |
| 13 | 118753 | ELBOW |
| 14 | 9183228 | CONNECTOR |
| 15 | 15003563 | ELBOW |
| 16 | 9067390 | HOSE ASSY |
| 17 | 179883 | BOLT |
| 18 | 271563 | BOLT |
| TRANSMISSION TORQUE BRAKE LINKAGE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103340 | WASHER |
| 2 | 9184755 | CLEVIS |
| 3 | 179843 | BOLT |
| 4 | 274208 | LOCK NUT |
| 5 | 9250756 | CABLE |
| 6 | 103385 | PIN-COTTER |
| 7 | 103331 | LOCK WASHER |
| TRANS. FRONT COVER AND CONVERTER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9416389 | NUT |
| 2 | 6771612 | RETAINER |
| 3 | 6772040 | KIT-SEAL |
| 4 | 23049028 | BEARING |
| 5 | 23016982 | HOUSING |
| 6 | 23018444 | PISTON |
| 7 | 23048511 | PLATE |
| 8 | 23016957 | PLATE |
| 9 | 954528 | BEARING |
| 10 | 6883524 | TURBINE |
| 11 | 181370 | BOLT |
| 12 | 9409037 | BOLT |
| TRANSMISSION CONVERTER HOUSING GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6882326 | GASKET |
| 2 | 103321 | LOCK WASHER |
| 3 | 187238 | BOLT |
| 4 | 103323 | WASHER |
| 5 | 103322 | LOCK WASHER |
| 6 | 179862 | BOLT |
| 7 | 179837 | BOLT |
| TRANSMISSION OIL PUMP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6838843 | PUMP ASSY |
| 2 | 23016947 | SEAL |
| TRANSMISSION LOCK-UP VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 454818 | BOLT |
| TRANSMISSION RETARDER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23048395 | PLATE-RETARDER |
| 2 | 6837657 | ROTOR ASSY |
| 3 | 9422848 | WASHER |
| 4 | 23046658 | GASKET |
| 5 | 9414876 | RING-SNAP |
| 6 | 6834946 | WASHER |
| 7 | 6834456 | PIN |
| 8 | 6839268 | SPRING |
| 9 | 6839010 | VALVE |
| 10 | 6839525 | TUBE |
| 11 | 9409030 | BOLT |
| TRANSMISSION RETARDER CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6833409 | KIT-SEAL |
| 2 | 103321 | LOCK WASHER |
| 3 | 6838525 | PIVOT |
| 4 | 179838 | BOLT |
| 5 | 450517 | BOLT |
| 6 | 186284 | BOLT |
| 7 | 444631 | PLUG(0.50") |
| TRANSMISSION MAIN HOUSING GROUP | ||
