Terex earthmoving equipment parts
TABLE NO.
2-2
STEERING GEAR
NC NO. QTY PART NO. DESCRIPTION
001 004 06351230 BOLT
002 004 06471201 LOCKNUT
003 004 07151220 BOTTOM FRONT
004 001 06350830 BOLT
005 001 06470801 NUT
006 002 00103340 BOTTOM FRONT
007 001 15255304 STEERING WHEEL
008 004 00179837 BOLT
009 004 00108580 LOCKWASHER
010 001 15300540 PLATE
011 004 06351030 BOLT
012 004 06431001 NUT
013 004 07151020 WASHER
014 001 20000149 PROTECTING
COVER–STEERING VALVE
015 003 00179881 BOLT
016 003 00103329 SPRING WASHER
017 001 15318692 STEERING COLUMN ASSY
018 001 15275116 .AIR CYLINDER ASSY
019 001 15275117 .BRACKET ASSY
020 001 15275118 .NUT
021 001 15275119 .STEERING COLUMN
ASSY (TOP END)
022 002 06350835 .BOLT
023 002 06470801 .NUT - NYLON
024 002 06351040 .BOLT
025 002 06471001 .NUT - NYLON
026 004 07151020 .WASHER
027 002 15274171 .PILOT SLEEVE
028 001 15275125 .BOLT - SHOULDER
029 001 15312261 .SLIDING JOINT ASSY
030 002 15500256 ..HINGED FITTING ASSY
031 001 15234744 STEERING SHAFT
