Terex earthmoving equipment parts
3-3
STEERING LINKAGE
NC NO. QTY PART NO. DESCRIPTION
047 002 15237801 TERMINAL ASSY-LEFT TIE-ROD
048 005 00179839 ·BOLT
049 005 00108580 ·WASHER
050 001 15228998 ·TIE-ROD HEAD-LEFT
052 001 09018309 ·PLATE-COVER
053 001 00444571 ·PLUG
054 001 09018310 ·BAFFLE RING
055 001 09105216 ·BEARING
056 001 09372594 ·DOUBLE-SCREW BOLT
057 004 15317485 SEAL RING
058 008 00271563 BOLT
059 008 09354243 NUT
060 002 15237800 TERMINAL ASSY-RIGHT TIE-ROD
061 005 00179839 ·BOLT
062 005 00108580 ·WASHER
063 001 15228999 ·TIE-ROD HEAD-RIGHT
065 001 09018309 ·PLATE-COVER
066 001 00444571 ·PLUG
067 001 09018310 ·BAFFLE RING
068 001 09105216 ·BEARING
069 001 09372594 ·DOUBLE-SCREW BOLT
12-13-41 R02
A NOTE SERIAL NO. LOWER THAN T2281037 (DETROIT) AND
T351001 (CUMMINS) NEED TO USE 9384856 PIN, FROM ABOVE TWO
SERIAL NO. NEED TO USE 15237869 PIN.
