Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Terex earthmoving equipment parts
NC NO. QTY PART NO. DESCRIPTION
001 20011793 PUMP
HOIST CYLINDER
NC NO. QTY PART NO. DESCRIPTION
001 15248543 HOIST CYLINDER
001 001 09019955 ·TUBE-OUTSIDE CYLINDER
002 001 15232135 ·END ASSY
A 003 001 09014200 ·BUSHING
A 004 001 09014362 ·RING-BACKUP
A 005 001 09014593 ·O RING
A 006 001 09256605 ·WIPER
A 007 001 09014129 ·WEARING RING
A 008 001 09270712 ·SEAR RING
009 012 00274821 ·LOCKNUT
C 010 002 15232053 ·T SEAL RING
011 001 15232134 ·TUBE-INNER CASING
B 012 001 09431967 ·PLUG
013 001 15248528 ·TUBE
A 014 002 09014301 ·RING-PISTON
A 015 001 09014132 ·WEARING RING
A 016 001 09256603 ·WIPER
A 017 002 09014130 ·WEARING RING
A 018 001 09272943 ·SEAL RING
019 002 15248536 ·TUBE-CYLINDER
A 020 001 09014131 ·WEARING RING
A 021 001 09132790 ·O RING
A 022 001 09014363 ·RING-BACKUP
023 001 09015489 ·BASE ASSY
024 001 09014200 ·BUSHING
NC NO. QTY PART NO. DESCRIPTION
025 012 00271568 ·BOLT
A NOTE CONTAIN IN 09394720 REPAIR KIT.
B NOTE SEE REPORT B520.
C NOTE SEE REPORT B715.
| 1 | 9376798 | INCHING SWITCH |
| 2 | 15047524 | AIR FILTER SWITCH |
| 3 | 2460404 | BRAKING SWITCH |
| 4 | 15043267 | SENSOR WATER TEMP |
| 5 | 15043281 | SENSOR PRESSURE OIL |
| 6 | 454096 | ELBOW |
| 7 | 15303318 | PRESSURE SWITCH |
| 8 | 15043271 | PRESSURE SENSOR |
| 9 | 125620 | TRANSITION CONNECTION |
| 10 | 15043265 | PRESSURE SENSOR |
| 11 | 15003859 | PRESSURE SWITCH |
| 12 | 119930 | TRANSITION CONNECTION |
| 13 | 15043269 | SENSOR TEMP |
| 14 | 15047525 | TRANSITION CONNECTION |
| 15 | 15230575 | PRESSURE SWITCH |
| ELECTRIC HORN | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15303068 | HORN |
| 2 | 15303069 | HORN |
| HOIST MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179841 | BOLT |
| 2 | 108580 | LOCK WASHER |
| 3 | 9409981 | FLANGE-SPLIT |
| 4 | 9410967 | O RING |
| 5 | 179839 | BOLT |
| 6 | 103329 | WASHER |
| 7 | 179883 | BOLT |
| 8 | 9067616 | TEE |
| 9 | 9037136 | ADAPTOR |
| 10 | 9016048 | CONNECTOR |
| 11 | 9016468 | ELBOW |
| 12 | 9183250 | TEE |
| 13 | 15004025 | HOSE ASSY |
| 14 | 15004007 | HOSE ASSY |
| 15 | 15004134 | HOSE ASSY |
| 16 | 15004008 | HOSE ASSY |
| 17 | 179860 | BOLT |
| 18 | 103328 | LOCK WASHER |
| 19 | 9410969 | O RING |
| 20 | 9409983 | FLANGE-SPLIT |
| 21 | 179885 | BOLT |
| 22 | 9410971 | O RING |
| 23 | 9409985 | FLANGE-SPLIT |
| 24 | 15253156 | CONNECTOR |
| 25 | 15251937 | CONNECTOR |
| 26 | 15251944 | ELBOW |
| 27 | 15244830 | ELBOW |
| 28 | 20002939 | HOSE ASSY |
| 29 | 15252870 | CONNECTOR |
| 30 | 15049933 | HOSE ASSY |
| 31 | 15049934 | HOSE ASSY |
| 32 | 15049935 | HOSE ASSY |
| 33 | 15049936 | HOSE ASSY |
| 34 | 179843 | BOLT |
| 35 | 9409982 | FLANGE-SPLIT |
| 36 | 9410968 | O RING |
| 37 | 15014975 | RUBBER SLEEVE |
| 38 | 15014977 | RUBBER SLEEVE |
| 39 | 15014979 | RUBBER SLEEVE |
| 40 | 15001430 | CLAMP |
| 41 | 15001427 | STUD |
| 42 | 15001428 | LONG NUT |
| HYDRAULIC TANK | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15228827 | TANK ASSEMBLY |
| 2 | 179838 | BOLT |
| 3 | 444619 | PLUG |
| 4 | 219303 | PLUG |
| 5 | 9246992 | CAP |
| 6 | 274209 | LOCK NUT |
| 7 | 2389616 | WING NUT |
| 8 | 9188290 | BOLT |
| 9 | 179885 | BOLT |
| 10 | 179887 | BOLT |
| 11 | 9038953 | KIT ELEMENT |
| 12 | 179839 | BOLT |
| 13 | 108585 | LOCK WASHER |
| 14 | 15230178 | WINDOW NUT STEEL |
| HYDRAULIC PUMP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9253503 | PUMP |
| 2 | 9034907 | LIP SEAL |
| 3 | 9034911 | COVER |
| 4 | 9036241 | SEAL |
| 5 | 9034503 | ROLLER BEARING |
| 6 | 9039962 | THRUST PLATE |
| 7 | 9034914 | SEAL STRIP |
| 8 | 9039963 | GEAR SET |
| 9 | 9034913 | GASKET SEAL |
| HOIST CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15232133 | HOIST CYLINDER |
| 2 | 9019955 | TUBE |
| 3 | 15232135 | END ASSY |
| 4 | 9014200 | BUSHING |
| 5 | 9014362 | RING-BACKUP |
| 6 | 9014593 | O RING |
| 7 | 9256605 | WIPER |
| 8 | 9014129 | WEARING RING |
| 9 | 9270712 | SEAR RING |
| 10 | 274821 | LOCKNUT |
| 11 | 15232053 | T SEAL RING |
| 12 | 15232134 | TUBE-INNER CASING |
| 13 | 9431967 | PLUG |
| 14 | 15232128 | TUBE |
| 15 | 9014301 | RING-PISTON |
| 16 | 9014132 | WEARING RING |
| 17 | 9256603 | WIPER |
| 18 | 9014130 | WEARING RING |
| 19 | 9272943 | SEAL RING |
| 20 | 9019958 | TUBE |
| 21 | 9014131 | WEARING RING |
| 22 | 9132790 | O RING |
| 23 | 9014363 | RING-BACKUP |
| 24 | 9015489 | BASE ASSY |
| 25 | 271568 | BOLT |
| 26 | 9411010 | REPAIR KIT |
| HYDRAULIC CONTROL VALVE | ||
