Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Terex earthmoving equipment parts
| 001 001 29544785 FILTER ASSY KIT-SUCTION 002 001 29537066 .GASKET 003 001 29543067 .FILTER & SEAL ASSY 004 001 29542991 ..SEAL-FACE 005 003 11515316 .BOLT-FLANGE HD 006 001 29544674 HARNESS-INTERNAL 007 001 29542084 .SEAL 008 001 12092195 .SEALRING 009 001 12129691 .SENSOR-TEMP 010 001 12047662 .CONNECTOR 011 001 12047767 .TERMINAL 012 001 12047767 .TERMINAL 013 001 12047664 .LOCK 014 001 12047783 .LOCK 015 003 12047767 .TERMINAL 016 001 12064758 .CONNECTOR 017 001 12124639 .TERMINAL 018 001 12124639 .TERMINAL 019 001 29541590 .CONNECTOR 020 001 29543019 .PLATE 021 001 29544184 .CONNECTOR ASSY 022 001 29544184 .CONNECTOR ASSY 023 001 29544184 .CONNECTOR ASSY 024 001 12066337 .TERMINAL-PIN 025 001 12066337 .TERMINAL-PIN 026 001 12110139 .CONNECTOR 027 001 29544184 .CONNECTOR ASSY 028 001 29544184 .CONNECTOR ASSY 029 001 29544184 .CONNECTOR ASSY 030 003 29536564 BOLT 031 001 29542946 BRACKET-SOLENOID 032 002 11516059 BOLT-FLANGE HD 033 003 23046376 SEAL-FACE 034 002 08678805 SPRING-ACCUM 035 002 29536230 PLUG-ACCUM 036 002 29536230 PLUG-ACCUM 037 002 08678805 SPRING-ACCUM 038 001 29542944 SWITCH ASSY-PRESS 039 001 29542945 .BRACKET-SOL 040 012 11515310 BOLT-FLANGE HD |
041 001 29542935 BODY ASSY-SOL VALVE 042 001 29542822 .BODY-SOL VALVE 043 003 29542954 .PIN-DOWEL 044 001 29544297 SOLENOID 045 001 29542976 .O RING 046 001 29542975 .O RING 047 001 29542937 VALVE-TCC 048 001 29542938 SPRING-TCC 049 001 29541897 SOLENOID 050 001 29542976 .O RING 051 001 29542975 .O RING 052 001 29542939 VALVE-PCS1 053 001 29542936 SPRING-PCS1 054 001 29541897 SOLENOID 055 001 29542976 .O RING 056 001 29542975 .O RING 057 001 29542939 VALVE-PCS1 058 001 29542936 SPRING-PCS1 059 001 29531022 CLIP 060 001 29542940 VALVE-DIAGNOSTIC 061 001 29542941 SPRING-DIAGNOSTIC 062 001 29544297 SOLENOID 063 001 29542975 .O RING 064 001 29542976 .O RING 065 001 29542939 VALVE-PCS1 066 001 29542936 SPRING-PCS1 067 001 29544297 SOLENOID 068 001 29542975 .O RING 069 001 29542976 .O RING 070 001 29542939 VALVE-PCS1 071 001 29542936 SPRING-PCS1 072 001 29544297 SOLENOID 073 001 29542975 .O RING 074 001 29542976 .O RING 075 001 29542933 PLATE 076 002 11515309 BOLT-FLANGE HD 077 001 23049345 PIN 078 001 23049315 VALVE 079 001 23049326 SPRING 080 001 23049337 STOP-VALVE |
| FROM SERIAL NO. T8771011 | |
| SER.NO. SER.NO. NC REF QTY PART NO. DESCRIPTION FROM TO |
| 12 | 109084 | HUT |
| 13 | 9197104 | ELBOW |
| ENGINE LUBRICATION LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 118753 | ELBOW |
| 2 | 116453 | ELBOW |
| 3 | 116436 | CONNECTOR |
| 4 | 2369508 | STUD-CLAMPING |
| ENGINE FLYWHEEL COVER GROUP PTO | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15229408 | POWER TAKE OFF |
| 2 | 15229409 | HOUSING ASSY |
| 3 | 784079 | PIN |
| 4 | 179826 | BOLT |
| 5 | 103320 | LOCK WASHER |
| 6 | 9004541 | SEAL |
| 7 | 444637 | PLUG (0.75IN) |
| 8 | 179826 | BOLT |
| 9 | 15229404 | GEAR-DRIVEN |
| 10 | 954528 | BEARING |
| 11 | 907696 | BEARING |
| 12 | 9274893 | GEAR-DRIVEN |
| 13 | 9004540 | SEAL |
| 14 | 9195847 | GEAR-DRIVE |
| 15 | 15245600 | SHAFT-DRIVE PTO |
| 16 | 9269703 | LOCK NUT |
| 17 | 9414895 | RING-SNAP |
| 18 | 9195842 | GASKET |
| 19 | 15249496 | WASHER-HARDENED |
| 20 | 9232989 | BREATHER |
| 21 | 6769936 | CAP-BREATHER |
| 22 | 9193182 | YOKE |
| 23 | 433142 | BOLT |
| 24 | 273469 | PLUG |
| 25 | 179860 | BOLT |
| 26 | 103328 | LOCK WASHER |
| TRANSMISSION MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9072457 | YOKE |
| 2 | 15017155 | TRUNNION |
| 3 | 9354243 | LOCK NUT |
| 4 | 9191596 | WASHER |
| 5 | 271563 | BOLT |
| 6 | 103320 | LOCK WASHER |
| 7 | 9272246 | TUBE |
| 8 | 9272248 | DIPSTICK-OIL |
| 9 | 106263 | WASHER |
| 10 | 108580 | LOCK WASHER |
| 11 | 102635 | NUT |
| 12 | 23011919 | YOKE |
| 13 | 271621 | BOLT |
| 14 | 9250715 | WASHER-HARDENED |
| 15 | 9355771 | NUT |
| 16 | 271612 | BOLT |
| 17 | 103332 | LOCK WASHER |
| 18 | 179838 | BOLT |
| 19 | 179818 | BOLT |
| 20 | 444613 | PLUG |
| 21 | 187396 | COUPLING |
| 22 | 9015715 | CLAMP |
| 23 | 9268885 | LOCK |
| 24 | 6771144 | NUT |
| 25 | 6771612 | RETAINER |
| 26 | 9416389 | NUT |
| 27 | 15229327 | PLATE |
| 28 | 9066008 | RING |
| TRANSMISSION SHIFT CONTROL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103319 | LOCK WASHER |
| 2 | 9250757 | CABLE ASSY |
| 3 | 103024 | NUT |
| 4 | 108580 | LOCK WASHER |
| 5 | 179845 | BOLT |
| 6 | 179839 | BOLT |
| 7 | 106263 | WASHER |
| 8 | 102635 | NUT |
| 9 | 179818 | BOLT |
| 10 | 103320 | LOCK WASHER |
| 11 | 179843 | BOLT |
| 12 | 9049109 | CABLE ASSY |
| 13 | 179795 | BOLT |
| 14 | 191474 | JOINT BALL |
| TRANSMISSION FILTER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23018846 | SWITCH |
| 2 | 1196599 | SEAL OIL FILTER |
| 3 | 15270495 | ELEMENT |
| 1 | 1300653 | BOWL-OIL FILTER |
| TRANSMISSION OIL LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9264303 | O RING |
| 2 | 9409985 | FLANGE-SPLIT |
| 3 | 103329 | LOCK WASHER |
| 4 | 179885 | BOLT |
| 5 | 9015533 | HOSE ASSY |
| 6 | 9012209 | ELBOW |
| 7 | 2369508 | STUD-CLAMPING |
| 8 | 116453 | ELBOW |
| 9 | 127887 | ELBOW |
| 10 | 9256512 | TEE |
| 11 | 103331 | LOCK WASHER |
| 12 | 9410286 | ELBOW |
| 13 | 118753 | ELBOW |
| 14 | 9183228 | CONNECTOR |
| 15 | 15003563 | ELBOW |
| 16 | 9067390 | HOSE ASSY |
| 17 | 179883 | BOLT |
| 18 | 271563 | BOLT |
| TRANSMISSION TORQUE BRAKE LINKAGE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103340 | WASHER |
| 2 | 9184755 | CLEVIS |
| 3 | 179843 | BOLT |
| 4 | 274208 | LOCK NUT |
| 5 | 9250756 | CABLE |
| 6 | 103385 | PIN-COTTER |
| 7 | 103331 | LOCK WASHER |
