Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Terex earthmoving equipment parts
| 001 002 09252445 GASKET 002 002 09016987 SEAL 003 002 09016985 RING-SNAP 004 002 09016986 WASHER 005 002 00456473 CONE 006 002 07450645 CUP 007 002 09253451 WHEEL 008 002 09178785 O RING 009 002 09384210 STEM-VALVE 010 002 09209216 .SPUD 011 002 09116292 .CAP 012 004 15228521 .FLANGE 25"RIM TITAN 013 002 15228566 .BASE-RIM 014 002 15228567 .BAND-BEAD SEAT 015 002 15228532 .LOCKRING 016 002 09433271 CUP-OUTER BEARING 017 002 09433270 CONE-OUTER BEARING 018 002 09016968 WASHER 019 002 09016970 NUT 020 002 00179097 PIN-COTTER 021 002 09015357 COVER 022 008 00179881 BOLT 023 008 00103329 LOCKWASHER 024 024 09433576 .NUT 025 024 09253468 STUD T8771011 T8771075 025 024 15352330 STUD T8771076 026 024 15023746 CLAMP NI ASR 09371048 LOCTITE 648 RET COMPOUND NI ASR 15305445 LOCTITE 7063 CLEANER |
| 6 | 103385 | PIN-COTTER |
| 7 | 103331 | LOCK WASHER |
| TRANS. FRONT COVER AND CONVERTER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9416389 | NUT |
| 2 | 6771612 | RETAINER |
| 3 | 6772040 | KIT-SEAL |
| 4 | 23049028 | BEARING |
| 5 | 23016982 | HOUSING |
| 6 | 23018444 | PISTON |
| 7 | 23048511 | PLATE |
| 8 | 23016957 | PLATE |
| 9 | 954528 | BEARING |
| 10 | 6883524 | TURBINE |
| 11 | 181370 | BOLT |
| 12 | 9409037 | BOLT |
| TRANSMISSION CONVERTER HOUSING GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6882326 | GASKET |
| 2 | 103321 | LOCK WASHER |
| 3 | 187238 | BOLT |
| 4 | 103323 | WASHER |
| 5 | 103322 | LOCK WASHER |
| 6 | 179862 | BOLT |
| 7 | 179837 | BOLT |
| TRANSMISSION OIL PUMP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6838843 | PUMP ASSY |
| 2 | 23016947 | SEAL |
| TRANSMISSION LOCK-UP VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 454818 | BOLT |
| TRANSMISSION RETARDER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23048395 | PLATE-RETARDER |
| 2 | 6837657 | ROTOR ASSY |
| 3 | 9422848 | WASHER |
| 4 | 23046658 | GASKET |
| 5 | 9414876 | RING-SNAP |
| 6 | 6834946 | WASHER |
| 7 | 6834456 | PIN |
| 8 | 6839268 | SPRING |
| 9 | 6839010 | VALVE |
| 10 | 6839525 | TUBE |
| 11 | 9409030 | BOLT |
| TRANSMISSION RETARDER CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6833409 | KIT-SEAL |
| 2 | 103321 | LOCK WASHER |
| 3 | 6838525 | PIVOT |
| 4 | 179838 | BOLT |
| 5 | 450517 | BOLT |
| 6 | 186284 | BOLT |
| 7 | 444631 | PLUG(0.50") |
| TRANSMISSION MAIN HOUSING GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 187238 | BOLT |
| 2 | 103323 | WASHER |
| 3 | 454815 | BOLT |
| 4 | 103339 | WASHER |
| 5 | 273340 | BOLT |
| 6 | 454818 | BOLT |
| 7 | 445968 | BOLT |
| 8 | 23016681 | GASKET |
| 9 | 6774322 | COVER |
| 10 | 179837 | BOLT |
| 11 | 103028 | NUT |
| 12 | 6885148 | KIT-PAN |
| 13 | 7964576 | BREATHER |
| 14 | 179818 | BOLT |
| 15 | 444335 | REDUCER |
| TRANS. HIGH RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23011235 | PLATE |
| 2 | 23042199 | PLATE |
| 3 | 6834679 | PLATE |
| 4 | 6831704 | RING-SNAP |
| 5 | 6883192 | RETAINER-SPRING |
| 6 | 23016569 | PISTON-LETTER Z |
| 7 | 23016568 | PISTON-LETTER Y |
| 8 | 6836799 | SEAL |
| 9 | 6833980 | SEAL |
| TRANS. INTER RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23046099 | SHAFT ASSY - MAIN |
| 2 | 6834333 | DRUM |
| 3 | 29506042 | SHAFT |
| 4 | 6835323 | BUSHING |
| 5 | 6835073 | CARRIER ASSY |
| 6 | 6835074 | CARRIER |
| 7 | 6834575 | RING-SNAP |
| 8 | 6835321 | WASHER |
| 9 | 6835580 | FLANGE AND CARRIER |
| 10 | 6835322 | BUSHING |
| 11 | 23041786 | PLATE |
| 12 | 6836465 | SUPPORT ASSY |
| 13 | 23011453 | SEAL- INTERNAL |
| 14 | 6880079 | SUPPORT-HOUSING |
| 15 | 23011235 | PLATE |
| 16 | 6834327 | GEAR |
