| 000 001 15229403 PUMP-STEERING 001 008 09058044 .SCREW 002 002 09058045 .COVER A 003 001 09058106 .KIT-SHIM B 004 002 09028466 .O RING 005 002 09058046 .SPACER 006 002 NSS .BEARING 007 001 02340310 .RING-RETAINER B 008 001 09058048 .SEAL 009 001 NSS .HOUSING 010 006 09058069 .SCREW B 011 001 NSS .GASKET 012 001 09058075 .BEARING 013 001 09058072 .SPRING 014 001 09058073 .SEAT 015 001 09058074 .SEAT 016 001 09417456 .PIN-ROLL 017 001 09058076 .YOKE 018 001 09058077 .RETAINER 019 001 09399072 .BLOCK 020 001 09399069 .SHAFT C 021 009 NSS .PIST & SH C 022 001 NSS .PISTON 023 001 NSS .ROD B 024 001 NSS .O RING C 025 001 NSS .PLATE C 026 001 NSS .WASHER C 027 001 NSS .PIN RETAI C 028 003 NSS .PIN C 029 001 NSS .CYL BLOCK C 030 001 NSS .WASHER C 031 001 NSS .SPRING 032 001 NSS .WASHER 033 001 09058105 .BEARING C 034 001 09059082 .SUPERCEDED MATERIAL 035 001 09398181 .PLATE-WAFER 036 001 09058094 .BEARING 037 002 09058095 .PIN-ROLLER 038 001 09058096 .PIN-DOWEL 039 001 00444854 .SUPERCEDED MATERIAL |
B 040 001 09399071 .O RING 041 001 09058097 .PLUG 042 001 09058098 .SEAT 043 001 09058099 .VALVE 044 001 09058100 .SPRING 045 001 09053287 .KIT-COMPENSATOR 046 001 09050169 ..RETAINER B 047 001 09050239 ..GASKET B 048 001 NSS ..O RING 049 001 09399073 ..PLUG 050 004 09399074 ..SCREW 051 001 09050202 ..BODY COMPENSATOR 052 001 09050219 ..SPOOL 053 001 09050191 ..SEAT 054 001 09050194 ..SPRING B 055 001 NSS ..O RING B 056 001 09044413 ..SEAL 057 001 09050218 ..PLUG 058 001 09113457 ..LOCKWIRE NOTES: A ONE SHIM KIT FOR BOTH YOKE BEARINGS B PARTS IN 9058104 SEAL KIT C PARTS IN 9058110 ROTATING GROUP |
| 25 | 179887 | BOLT |
| 26 | 139230 | SCREW |
| 27 | 15234244 | SEAL-CORD |
| REAR AXLE GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9014145 | RETAINER |
| 2 | 9354243 | LOCK NUT |
| 3 | 9003687 | WASHER |
| 4 | 9003682 | CUP-SPLIT |
| 5 | 9019464 | SPACER |
| 6 | 9411017 | FITTING-GREASE |
| 7 | 9016684 | BEARING |
| 8 | 9014762 | PIN |
| 9 | 9014763 | BOLT |
| 10 | 9014146 | RETAINER |
| 11 | 223444 | BOLT |
| 12 | 118753 | ELBOW |
| 13 | 9018562 | A FRAME ASSEMBLY |
| 14 | 15246949 | BREATHER |
| 15 | 9062448 | ROD-STABILIZER |
| 16 | 9015038 | PIN ASSEMBLY |
| 17 | 9129626 | HOSE ASSY |
| 18 | 187394 | COUPLING |
| 19 | 9015217 | SPACER |
| 20 | 9015216 | BEARING |
| 21 | 9015218 | PIN |
| 22 | 9217321 | WASHER |
| 23 | 103329 | LOCK WASHER |
| 24 | 179883 | BOLT |
| 25 | 9018946 | BUSHING |
| 26 | 9273826 | SPACER |
| 27 | 9121931 | STUD.62-11 UNC*3 |
| 28 | 9005585 | STUD.62-11 UNC*4 |
| 29 | 9121930 | STUD.62-11 UNC*2 |
| 30 | 9264677 | SHAFT-HEAT TREATED |
| 31 | 454754 | NUT |
| 32 | 271613 | BOLT |
| 33 | 120350 | LOCK WASHER |
| 34 | 9117927 | PLUG-MAGNETIC |
| 35 | 219303 | PLUG |
| 36 | 9015036 | SPACER |
| 37 | 9411010 | FITTING-GREASE |
| 38 | 9136639 | NIPPLE |
| 39 | 144033 | BUSHING |
| 40 | 116436 | CONNECTOR |
| 41 | 9122167 | ELBOW |
| REAR AXLE PLANETARY GEARING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9006548 | GEAR-INTERNAL |
| 2 | 15229009 | RING |
| 3 | 9113457 | LOCK WIRE |
| 4 | 273870 | BOLT DRILL HEAD 0.38 |
| 5 | 9179960 | WASHER-THRUST |
| 6 | 9169302 | RING-SNAP |
| 7 | 9203350 | GEAR-SUN |
| 8 | 9207911 | GEAR-PINION |
| 9 | 9418724 | BEARING |
| 10 | 9001461 | PIN |
| 11 | 9125576 | O RING-BULK |
