Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| 15 | 23011235 | PLATE |
| 16 | 6834327 | GEAR |
| TRANS. LOW RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23047771 | PLATE |
| 2 | 23041786 | PLATE |
| 3 | 6838558 | GEAR-REVERSE |
| 4 | 6836661 | RING-RETAINER |
| 5 | 6836659 | PISTON |
| 6 | 23011453 | SEAL-INTERNAL |
| 7 | 6881979 | HOUSING ASSY |
| 8 | 6883708 | PLUG |
| 9 | 6835369 | SEAL |
| TRANS. REVERSE RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23047771 | PLATE |
| 2 | 23041786 | PLATE |
| 3 | 6838558 | GEAR-REVERSE |
| 4 | 903017 | BEARING |
| TRANS. FORWARD RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23017215 | CLUTCH-INPUT |
| 2 | 6833980 | SEAL |
| 3 | 6836799 | SEAL |
| 4 | 23016569 | PISTON-LETTER Z |
| 5 | 23016568 | PISTON-LETTER Y |
| 6 | 6883192 | RETAINER-SPRING |
| 7 | 6831704 | RING-SNAP |
| 8 | 6839021 | HUB |
| 9 | 6834679 | PLATE-CLUTCH |
| 10 | 23042199 | PLATE |
| 11 | 6835605 | CLUTCH-HUB DRIVING |
| 12 | 6777231 | RING-SNAP |
| 13 | 6838695 | RING-SNAP |
| TRANSMISSION REAR COVER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 29505795 | BOLT |
| 2 | 103329 | LOCK WASHER |
| 3 | 191268 | BOLT |
| 4 | 6750924 | RING-SNAP |
| 5 | 6773311 | SEAL |
| FRONT DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9013987 | DRIVELINE ASSY |
| 2 | 9053746 | CROSS ASSY |
| 3 | 695456 | BOLT |
| 4 | 2366106 | STRAP |
| 5 | 9411010 | FITTING-GREASE |
| REAR DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9273082 | DRIVELINE ASSY |
| 2 | 15233277 | CROSS ASSY |
| 3 | 2366106 | STRAP |
| 4 | 695456 | BOLT |
| 5 | 9411010 | FITTING-GREASE |
| REAR AXLE DIFFERENTIAL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103393 | PIN-COTTER |
| 2 | 9192613 | NUT |
| 3 | 9003683 | GASKET |
| 4 | 9265937 | YOKE ASSY |
| 5 | 9232899 | SLEEVE |
| 6 | 9250409 | DIFFERENTIAL-2.50:1 |
| 7 | 15244338 | SEAL |
| 8 | 9003785 | SEAL-RETAINER |
| 9 | 9424975 | BEARING |
| 10 | 9250389 | GEAR SET |
| 11 | 7451617 | BEARING |
| 12 | 9216692 | BOLT |
| 13 | 9192618 | DOWEL-BUSHING |
| 14 | 9412692 | CUP |
| 15 | 9424974 | CONE |
| 16 | 9219084 | PIN-DOWEL |
| 17 | 9008341 | WASHER-THRUST |
| 18 | 9008357 | GEAR |
| 19 | 9008365 | WASHER-THRUST |
| 20 | 9008364 | PINION ASSY |
| 21 | 9008382 | SPIDER |
| 22 | 9113457 | LOCK WIRE |
| 23 | 9170517 | BOLT |
| 24 | 9114897 | SCREW |
| 25 | 179887 | BOLT |
| 26 | 139230 | SCREW |
| 27 | 15234244 | SEAL-CORD |
