Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| 13 | 2466115 | BEARING |
| 14 | 120221 | SCREW |
| 15 | 2466113 | COVER |
| 16 | 2466114 | O RING |
| 17 | 2466117 | O RING |
| 18 | 2466112 | O RING |
| 19 | 103325 | LOCK WASHER |
| 20 | 2466118 | PISTON |
| 21 | 2466120 | ROLLER |
| 22 | 2466119 | LOCK SLEEVE |
| 23 | 2466121 | WASHER |
| 24 | 2466122 | SPRING |
| 25 | 2466106 | CAP |
| 26 | 2466116 | FELT PAD |
| 27 | 2466125 | GUARD |
| 28 | 3858065 | RING-SNAP |
| 29 | 2466123 | PISTON ROD |
| 30 | 2267136 | CLEVIS ASSY |
| 31 | 9035510 | PIN |
| 32 | 103385 | COTTER PIN |
| BRAKE CHAMBER-REAR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9256203 | BRAKE CHAMBER-REAR |
| 2 | 103320 | LOCK WASHER |
| 3 | 9034481 | GASKET |
| 4 | 9033736 | DUST PROOF SHIELD |
| 5 | 9428735 | BOLT |
| 6 | 9049316 | FIXED DISK |
| 7 | 9049312 | CUP RING |
| 8 | 9049317 | SHAFT |
| 9 | 103319 | LOCK WASHER |
| 10 | 2466109 | SEAT RING |
| 11 | 9049315 | SPRING RETURN |
| 12 | 2466115 | BEARING |
| 13 | 120221 | SCREW |
| 14 | 2466113 | COVER |
| 15 | 2466114 | O RING |
| 16 | 2466117 | O RING |
| 17 | 2466112 | O RING |
| 18 | 103325 | LOCK WASHER |
| 19 | 2466118 | PISTON |
| 20 | 2466120 | ROLLER |
| 21 | 2466119 | LOCK SLEEVE |
| 22 | 2466121 | WASHER |
| 23 | 2466122 | SPRING |
| 24 | 2466106 | CAP |
| 25 | 2466116 | FELT PAD |
| 26 | 2466125 | GUARD |
| 27 | 3858065 | RING-SNAP |
| 28 | 9049313 | PISTON ROD |
| 29 | 2466107 | CLEVIS ASSAY |
| 30 | 103398 | COTTER PIN |
| QUICK RELIEF VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 2396430 | QUICK RELIEF VALVE |
| 2 | 2400285 | VALVE ASSY |
| HORN LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179820 | BOLT |
| 2 | 102634 | NUT |
| 3 | 103320 | LOCK WASHER |
| 4 | 103340 | WASHER |
| 5 | 9233142 | TUBING-NYLON |
| AIR HORN | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9060488 | HORN ASSY |
| CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9012095 | HAND BRAKE VALVE |
| 2 | 9023836 | LEVER |
| 3 | 2247608 | O RING |
| 4 | 179795 | BOLT |
| DRY/WET VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 2402041 | DRY/WET VALVE |
| 2 | 2247608 | O RING |
| RELAY VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9018245 | VALVE ASSY |
| 2 | 444625 | PLUG |
| 3 | 15230565 | VALVE MOISTURE EJECT |
| 4 | 9208529 | MAIN CONTROL VALVE |
| 5 | 9249220 | PRESSURE SAFE VALVE |
| SYNCHRO VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9006527 | VALVE ASSY |
| 2 | 9023324 | O RING |
| STEERING VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15011925 | STEERING VALVE STEER |
| 2 | 9055616 | GLAND-BUSHING SEAL |
| 3 | 457151 | BEARING |
| 4 | 104919 | BALL-CHECK |
| STEERING COLUMN LOWER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9211139 | COLUMN |
| 2 | 9418814 | BEARING |
| STEERING COLUMN INTERMEDIATE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15227163 | COLUMN STEERING |
| 2 | 179845 | BOLT |
| 3 | 274208 | LOCK NUT |
| 4 | 179847 | BOLT |
| STEERING COLUMN MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 20000149 | COVER |
| 2 | 179881 | BOLT |
| 3 | 103329 | LOCK WASHER |
| 4 | 114496 | NUT-JAM |
| 5 | 179843 | BOLT |
| 6 | 108580 | LOCK WASHER |
| 7 | 179841 | BOLT |
| 8 | 103319 | LOCK WASHER |
| 9 | 103339 | WASHER |
| 10 | 106263 | WASHER |
| 11 | 102635 | NUT |
| STEERING LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9190982 | STRAP |
| 2 | 108580 | LOCK WASHER |
| 3 | 102635 | NUT |
| 4 | 9183501 | ELBOW ASSY |
| 5 | 274248 | O RING |
| 6 | 15004052 | HOSE ASSY |
| 7 | 125620 | CONNECTOR |
| 8 | 9120288 | HOSE ASSY |
| 9 | 116453 | ELBOW |
| 10 | 2369508 | STUD-CLAMPING |
| 11 | 9234465 | HOSE ASSY |
| 12 | 187396 | COUPLING |
| 13 | 15004050 | HOSE ASSY |
| 14 | 9183205 | PLUG |
| 15 | 274253 | O RING |
| 16 | 274208 | LOCK NUT |
| 17 | 179847 | BOLT |
| 18 | 15229547 | TEE |
| 19 | 274247 | O RING |
| 20 | 15004049 | HOSE ASSY |
| 21 | 9183500 | ELBOW ASSY |
| 22 | 15004044 | HOSE ASSY |
| 23 | 103331 | LOCK WASHER |
| 24 | 9376401 | HOSE ASSY |
