Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| REAR AXLE GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9014145 | RETAINER |
| 2 | 9354243 | LOCK NUT |
| 3 | 9003687 | WASHER |
| 4 | 9003682 | CUP-SPLIT |
| 5 | 9019464 | SPACER |
| 6 | 9411017 | FITTING-GREASE |
| 7 | 9016684 | BEARING |
| 8 | 9014762 | PIN |
| 9 | 9014763 | BOLT |
| 10 | 9014146 | RETAINER |
| 11 | 223444 | BOLT |
| 12 | 118753 | ELBOW |
| 13 | 9018562 | A FRAME ASSEMBLY |
| 14 | 15246949 | BREATHER |
| 15 | 9062448 | ROD-STABILIZER |
| 16 | 9015038 | PIN ASSEMBLY |
| 17 | 9129626 | HOSE ASSY |
| 18 | 187394 | COUPLING |
| 19 | 9015217 | SPACER |
| 20 | 9015216 | BEARING |
| 21 | 9015218 | PIN |
| 22 | 9217321 | WASHER |
| 23 | 103329 | LOCK WASHER |
| 24 | 179883 | BOLT |
| 25 | 9018946 | BUSHING |
| 26 | 9273826 | SPACER |
| 27 | 9121931 | STUD.62-11 UNC*3 |
| 28 | 9005585 | STUD.62-11 UNC*4 |
| 29 | 9121930 | STUD.62-11 UNC*2 |
| 30 | 9264677 | SHAFT-HEAT TREATED |
| 31 | 454754 | NUT |
| 32 | 271613 | BOLT |
| 33 | 120350 | LOCK WASHER |
| 34 | 9117927 | PLUG-MAGNETIC |
| 35 | 219303 | PLUG |
| 36 | 9015036 | SPACER |
| 37 | 9411010 | FITTING-GREASE |
| 38 | 9136639 | NIPPLE |
| 39 | 144033 | BUSHING |
| 40 | 116436 | CONNECTOR |
| 41 | 9122167 | ELBOW |
| REAR AXLE PLANETARY GEARING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9006548 | GEAR-INTERNAL |
| 2 | 15229009 | RING |
| 3 | 9113457 | LOCK WIRE |
| 4 | 273870 | BOLT DRILL HEAD 0.38 |
| 5 | 9179960 | WASHER-THRUST |
| 6 | 9169302 | RING-SNAP |
| 7 | 9203350 | GEAR-SUN |
| 8 | 9207911 | GEAR-PINION |
| 9 | 9418724 | BEARING |
| 10 | 9001461 | PIN |
| 11 | 9125576 | O RING-BULK |
| 12 | 9253340 | CARRIER |
| 13 | 139230 | SCREW |
| 14 | 220101 | BOLT |
| 15 | 9174020 | GASKET |
| 16 | 9199882 | COVER |
| 17 | 9056740 | NUT |
| 18 | 9008525 | PLUG-MAGNETIC |
| 19 | 9013007 | STUD |
| REAR WHEEL,RIM AND TYPE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9017095 | SEAL ASSY |
| 2 | 9250686 | RING |
| 3 | 9017094 | WASHER |
| 4 | 9432367 | CONE |
| 5 | 9432368 | CUP |
| 6 | 9263531 | WHEEL |
| 7 | 9208424 | NUT |
| 8 | 9379407 | KEY |
| 9 | 9417832 | BOLT |
| 10 | 9113457 | LOCK WIRE |
| 11 | 9178785 | O RING |
| 12 | 9015172 | BASE-RIM |
| 13 | 15229542 | BASE-RIM |
| 14 | 9130352 | FLANGE |
| 15 | 15229543 | FLANGE |
| 16 | 9015052 | BAND-BEAD SEAT |
| 17 | 15229545 | BAND-BEAD SEAT |
| 18 | 9227575 | LOCK RING |
| 19 | 15229544 | LOCK RING |
| 20 | 9123307 | SPACER-BAND |
| 21 | 9015045 | WEDGE-BAND |
