Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| SEAT-DRIVER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15302059 | SEAT ASSY-HIGH BACK |
| 2 | 15269020 | KIT-HT RISER SPRING |
| 3 | 15503341 | KIT-DAMPER(NEW) |
| 4 | 15269028 | KIT-24V COMP/VALVE |
| 5 | 7161230 | LOCKWASHER |
| 6 | 6350830 | BOLT |
| 7 | 7150815 | WASHER |
| 8 | 7160830 | LOCKWASHER |
| 9 | 6430801 | NUT |
| SEAT-INSTRUCTOR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6350825 | BOLT |
| 2 | 7160830 | LOCKWASHER |
| 3 | 6351020 | BOLT |
| 4 | 7161030 | LOCKWASHER |
| 5 | 103340 | WASHER |
| 6 | 274209 | LOCKNUT |
| 7 | 9068666 | WASHER-HARDENED |
| 8 | 120378 | NUT |
| 9 | 103329 | LOCKWASHER |
| TRANSMISSION BREAKDOWN | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6777070 | FLANGE-INPUT |
| 2 | 15258084 | FLANGE-TRAMS OUTPUT |
| 3 | 6772182 | NUT |
| 4 | 6776246 | PLATE-RETAINER |
| CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6777974 | GASKET |
| 2 | 6835409 | PLATE-OIL TRANSFER |
| 3 | 6830003 | WASHER |
| 4 | 23018739 | BOLT |
| 5 | 9409030 | BOLT |
| 6 | 6839632 | GASKET |
| 7 | 23012877 | PLATE-SEPARATOR |
| 8 | 6839633 | GASKET |
| 9 | 103339 | WASHER |
| 10 | 9427847 | BOLT |
| 11 | 9433579 | BOLT |
| 12 | 29536510 | HARNESS ASSY |
| 13 | 12052410 | TERMINAL |
| 14 | 12059716 | CONNECTOR-BODY |
| 15 | 454813 | BOLT |
| 16 | 23019734 | SOLENOID-12V |
| 17 | 23046848 | SEAL |
| 18 | 29524652 | SCREW |
| 19 | 6779833 | GASKET |
| 20 | 6833223 | SPRING-OUTER |
| 21 | 6830243 | SPRING-INNER |
| 22 | 6880187 | BALL-CHECK |
| 23 | 29525044 | PLUG ASSY |
| 24 | 6759964 | SPRING |
| 25 | 6769825 | SPRING |
| 26 | 6778593 | SPRING |
| 27 | 6830014 | SPRING |
| 28 | 6830240 | SPRING |
| 29 | 6830237 | SPRING |
| 30 | 6779835 | GASKET |
| 31 | 103339 | WASHER |
| 32 | 9418964 | BOLT |
| 33 | 186284 | BOLT |
| 34 | 179851 | BOLT |
| 35 | 433114 | BOLT |
| 36 | 6838821 | GASKET |
| 37 | 23045751 | COVER ＆ PLATE |
| 38 | 6838904 | GASKET |
| 39 | 23019734 | SOLENOID-12V |
| 40 | 23046848 | SEAL |
| 41 | 6779852 | GASKET |
| 42 | 12059716 | CONNECTOR-BODY |
| 43 | 12052410 | TERMINAL |
| 44 | 6835526 | GASKET |
| 45 | 186290 | BOLT |
| SHIFT CONTROL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15231519 | RELAY |
