| REV RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6776237 | BUSH |
| 2 | 6832249 | HUB |
| 3 | 6777797 | CIRCLIP |
| 4 | 23013833 | CARRIER ASSY-REV |
| 5 | 6776247 | SEAL |
| 6 | 181360 | HEX BOLT |
| 7 | 23011176 | BEARING |
| 8 | 23041007 | WASHER |
| 9 | 6777795 | PLATE |
| 10 | 6777792 | CIRCLIP |
| 11 | 6832138 | PLATE-FRICTION |
| 12 | 6777796 | PLATE-REACTION |
| 13 | 6777766 | GEAR ASM |
| 14 | 6777768 | PISTON |
| 15 | 6777992 | KIT-SEAL |
| 16 | 6777995 | KIT-SEAL |
| REAR COVER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6831992 | GASKET |
| 2 | 6834881 | COVER ASM |
| 3 | 23046162 | GEAR |
| 4 | 6834878 | GEAR |
| 5 | 29502027 | BEARING SUP |
| 6 | 23046430 | SEAL |
| 7 | 6838678 | GASKET |
| 8 | 6778691 | RETAINER |
| 9 | 223435 | BOLT |
| 10 | 103325 | WASHER SPRING LOCK |
| 11 | 6776249 | GEAR-SPEEDO DRIVE |
| 12 | 552868 | GASKET |
| 13 | 103320 | LOCK WASHER |
| 14 | 6835104 | PICKUP-MAGNETIC |
| THROTTLE SENSOR AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15251067 | SENSOR-THROTTLE |
| FRONT DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15300850 | DRIVELINE-FRONT |
| 2 | 15272863 | BOLT |
| 3 | 15272865 | UNIVERSAL JOINT |
| 4 | 15336537 | DRIVELINE-FRONT |
| REAR DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15258114 | DRIVELING 12.5 C-DEAR |
| 2 | 15271476 | UNIVERSAL JOINT |
| 3 | 15271477 | BOLT/NUT SET |
| 4 | 15272031 | BOLT |
| WHEEL,RIM AND TYPE-FRONT | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9262036 | GASKET |
| 2 | 9062605 | SEAL |
| 3 | 9016245 | RING-SNAP |
| 4 | 9062643 | WASHER |
| 5 | 9418488 | CONE |
| 6 | 456513 | CUP |
| 7 | 15236015 | WHEEL-FRONT |
| 8 | 9253468 | STUD |
| 9 | 9062983 | CLAMP |
| 10 | 9209490 | O RING |
| 11 | 9433576 | NUT |
| 12 | 9063834 | FLANGE |
| 13 | 15017037 | BASE |
| 14 | 9074982 | BAND-BEAD SEAT |
| 15 | 9074983 | LOCKRING |
| 16 | 9427249 | CUP-BEARING |
| 17 | 9428203 | CONE-BEARING |
| 18 | 9019828 | SHIM PACK |
| 19 | 9019600 | PLATE |
| 20 | 9256717 | BOLT |
| 21 | 9019601 | CAP |
| 22 | 454989 | BOLT |
| 23 | 103329 | LOCKWASHER |
| 24 | 9113457 | LOCKWIRE |
| 25 | 15302218 | SPINDLE ASSEMBLY-LEF |
| 26 | 9062561 | BUSHING |
| 27 | 454988 | BOLT |
