Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
Terex earthmoving equipment parts
| 35 | 9136639 | NIPPLE |
| 36 | 144033 | BUSHING |
| 37 | 116436 | CONNECTOR |
| 38 | 15249532 | HOSE ASSY |
| 39 | 9122167 | CONNECTOR |
| 40 | 9250715 | WASHER |
| PLANETARY GEARING-REAR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9113457 | LOCKWIRE |
| 2 | 15019509 | BOLT DRILL HEAD 0.50 |
| 3 | 9008525 | PLUG-MAGNETIC |
| 4 | 273469 | PLUG |
| 5 | 15009631 | CARRIER-PLANETARY |
| 6 | 15019510 | PINION-PLANETARY |
| 7 | 15233267 | RETAINER |
| 8 | 15232937 | PLATE-THRUST |
| 9 | 15233274 | RETAINER |
| 10 | 9074668 | SPACER |
| 11 | 15238327 | BEARING |
| 12 | 15238323 | SPACER-BEARING |
| 13 | 454910 | BOLT |
| 14 | 15233266 | PIN-PLANETARY |
| 15 | 15019502 | BOLT DRILL HEAD 0.38 |
| 16 | 9074670 | SPACER |
| 17 | 15238317 | PLANET PINION-FIRS |
| 18 | 15019484 | PINION-SUN |
| 19 | 15019492 | PLATE-RETAINER |
| 20 | 15236593 | CARRIER-PLANTRY M/CD |
| 21 | 15238322 | SPACER-THRUST |
| 22 | 15233271 | COVER-PLANTRY M/CD |
| 23 | 15019519 | WASHER-THRUST |
| 24 | 15238319 | SUN PINION-FIRST S |
| 25 | 15245290 | WASHER-THRUST |
| 26 | 9125576 | O RING-BULK |
| 27 | 15228596 | RING-GEAR |
| 28 | 15233268 | COVER CARRIER |
| 29 | 9430309 | BOLT |
| 30 | 9250715 | WASHER-HARDENED |
| 31 | 9141863 | O RING |
| 32 | 15233269 | RETAINER |
| 33 | 15019494 | RETAINER |
| 34 | 15019483 | RING-GEAR |
| 35 | 9413420 | RING-SNAP |
| 36 | 15019482 | CARRIER-RING GEAR |
| 37 | 9433576 | NUT |
| 38 | 15246062 | WASHER-THRUST |
| 39 | 15015363 | BEARING |
| 40 | 139230 | SCREW |
| WHEEL RIM AND TYPE-REAR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15021101 | PLATE |
| 2 | 9063017 | SHIM-PACK |
| 3 | 15233384 | CONE-BEARING |
| 4 | 9437224 | CONE-BEARING |
| 5 | 15233385 | CUP-BEARING |
| 6 | 15233302 | WHEEL |
| 7 | 9253468 | STUD |
| 8 | 9255689 | STUD |
| 9 | 9063025 | BOLT |
| 10 | 9113457 | LOCKWIRE |
| 11 | 9209490 | O RING |
| 12 | 15017037 | BASE |
| 13 | 9063834 | FLANGE |
| 14 | 9074982 | BAND-BEAD SEAT |
| 15 | 9074983 | LOCKRING |
| 16 | 15017033 | BAND SPACER |
| 17 | 273469 | PLUG |
| 18 | 15023746 | CLAMP |
| 19 | 9433576 | NUT |
| 20 | 9211054 | VALVE ASSY |
| 21 | 9116292 | CAP |
| 22 | 9142286 | CORE |
| 23 | 15245476 | EXTENSION-VALVE |
| 24 | 9437225 | CUP-DEARING |
| 25 | 179880 | BOLT |
| 26 | 103329 | LOCKWASHER |
| 27 | 9074815 | SPUD |
| 28 | 9051190 | GROMMET |
| 29 | 15017039 | VALVE ASSY-INST |
| BRAKE PARTS-FRONT WHEEL-RIGIDS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15300389 | BRAKE HEAD ASSY |
| 2 | 9058895 | BOLT |
| 3 | 9058896 | WASHER |
| 4 | 15267039 | PLATE-THRUST |
| 5 | 15266825 | KIT-LINING |
| 6 | 9058900 | BOLT |
| 7 | 9058901 | WASHER |
| 8 | 9058905 | PISTON |
| 9 | 15271389 | KIT-SEAL |
| 10 | 9074283 | WASHER-HARDENED |
| 11 | 15300580 | CARRIER-FRONT |
| 12 | 15247360 | DISC-BRAKE |
| 13 | 15248418 | BOLT |
| 14 | 9226983 | BOLT |
| 15 | 15025751 | BOLT |
| 16 | 9008198 | WASHER |
| 17 | 15237514 | SHIM(0.060 IN) |
| 18 | 15237515 | SHIM(0.030 IN) |
| BRAKE PARTS-REAR WHEEL-RIGIDS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15233275 | SEAL HOUSING |
| 2 | 15302757 | O RING |
| 3 | 15302752 | SEAL ASSEMBLY |
| 4 | 15272374 | O RING |
| 5 | 9064938 | BOLT |
| 6 | 223493 | BOLT |
| 7 | 9019631 | WASHER |
| 8 | 15302758 | O RING |
| 9 | 9072627 | BOLT |
| 10 | 15310256 | WASHER-HARDENED |
| 11 | 15307380 | BRAKE ASSY |
| 12 | 223437 | BOLT |
| 13 | 9065332 | WASHER |
| 14 | 15247047 | SPRING HOUSING MACHINED |
| 15 | 9068505 | SCREW |
| 16 | 2276784 | SCREW-BLEED |
| 17 | 15258053 | SEAL-O RING |
| 18 | 784094 | PIN-DOWEL |
| 19 | 784088 | PIN-DOWEL |
| 20 | 9065306 | SPRING |
| 21 | 9065305 | SPRING |
| 22 | 15303608 | SEAL ASSY-PISTON |
| 23 | 15302125 | PARKING PISTON |
| 24 | 15258054 | SEAL-O RING |
| 25 | 15302126 | DISC HOUSING |
| 26 | 9183205 | PLUG |
| 27 | 274248 | O RING |
