| 5GE776Wheel Motor | |||
| Item | GE# | Description | QTY |
| 1 | 84E901933G1 | Frame | 1 |
| 2 | 84C620980P1 | shaft | 3 |
| 3 | 84D730317P1 | Torque tube | 1 |
| 4 | 84D730172P1 | 聽 | 1 |
| 5 | 41D735184G1 | Hub-wheel | 1 |
| 6 | 8864961P12 | Bearing-roller | 3 |
| 7 | 8864951P206 | Bearing-roller | 3 |
| 8 | 41A239885P1 | sleeve | 3 |
| 9 | 41C635889G1 | Cap-bearing | 3 |
| 10 | 8864959P15 | Nut-retaining | 3 |
| 11 | 8864959P115 | Lockwasher | 3 |
| 12 | 41A330517P1 | Collar | 3 |
| 13 | 41C635891P3 | Cap-bearing | 3 |
| 14 | 8864953P119 | Bearing-roller | 1 |
| 15 | 8864953P120 | Bearing-roller | 1 |
| 16 | 41C636477P2 | Seal ring | 1 |
| 17 | 41B537454P1 | Ring | 1 |
| 18 | 41A238995P2 | Seal-oil | 2 |
| 19 | 41A238997P2 | Band-wear | 3 |
| 20 | 41B537563P1 | Cap-bearing | 1 |
| 21 | 41C635893P1 | Ring-thrust | 1 |
| 22 | 41B535930G1 | Set of shims | 1 |
| 23 | 41B535930P1 | Shim | 20 |
| 24 | 41B535930P2 | Shim | 16 |
| 25 | 41B535930P3 | Shim | 20 |
| 26 | 41B535930P5 | Shim | 5 |
| 27 | 41B535930P6 | Shim | 4 |
| 28 | 41B535930P7 | Shim | 5 |
| 29 | 41C635863G1 | Seal housing | 1 |
| 30 | 41C636652P2 | Seal ring | 1 |
| 31 | 41C636651P1 | Flinger | 1 |
| 32 | 41A239857P1 | Clamp | 36 |
| 33 | N22P29020B13 | Capscrew | 36 |
| 34 | 2703900P1 | Washer | 144 |
| 35 | 41A238994P1 | Seal-oil | 1 |
| 36 | 41A238996P1 | Packing-felt | 1 |
| 37 | 41A238997P1 | Band-wear | 1 |
| 38 | N5700P21 | Pipe plug | 16 |
| 39 | 41A330184P2 | O-ring | 1 |
| 40 | 41A232900P1 | Pin-torque tube | 1 |
| 41 | 499A910AAP4 | Clamp-hose | 4 |
| 42 | 41B538753P1 | Coupling-oil return | 2 |
| 43 | 41A238941P2 | Ring | 3 |
| 44 | 84D730217G1 | Planet gear cover | 1 |
| 45 | 84A204762P1 | Oil hose | 2 |
| 46 | 84A204762P2 | Hose | 1 |
| 47 | 41A235215P1 | Clamp,hose worm | 6 |
| 48 | 84D730829G1 | Brake line assembly | 1 |
| 49 | 41B538253P1 | Filler cap | 1 |
| 50 | 41A235893P1 | Plug | 2 |
| 51 | N5700P81 | Plug,Pipe | 3 |
| 52 | 41A232942G1 | Plug,magnetic | 1 |
| 53 | 499A904CEP4 | Cap,pipe | 1 |
| 54 | 41C633216P4 | Strap-terminal connection | 3 |
| 55 | 41B537912G | Insulator with stud | 1 |
| 56 | N258P25B13 | nut | 6 |
| 57 | N402P43B13 | Flatwasher | 6 |
| 58 | N405P43B13 | Lockwasher | 6 |
| 59 | 41A235717P2 | Bolt-special | 55 |
| 60 | 41B538385P42 | Capscrew | 45 |
| 61 | 41B537660P21 | Flatwasher | 45 |
| 62 | N22P35040B13 | Capscrew | 24 |
| 63 | 41B537660P14 | Flatwasher | 24 |
| 64 | N22P25028B13 | Capscrew | 12 |
| 65 | 41B537660P1 | Flatwasher | 12 |
| 66 | N170P33024 | Capscrew | 10 |
| 67 | N22P29036B13 | Capscrew | 16 |
| 68 | 41B537660P6 | Flatwasher | 58 |
| 69 | N14P29020B13 | Bolt | 6 |
| 70 | 41A330596P1 | Bolt,P.G.Bearing cap | 18 |
| 71 | N14P29018B13 | Capscrew | 18 |
| 72 | 497A806P60 | Sealer,RTV | ar |
| 73 | 497A806P9 | Cement | ar |
| 74 | 497A806P33 | Sealant-gasket | ar |
| 75 | 41A330208P14 | Wire | ar |
| 76 | 84D730204G4 | Stator assembly | 1 |
| 77 | 84D730204G2 | Stator rewind kit | 1 |
| 78 | 84D730204G3 | Stator bus ring kit | 1 |
| 79 | 41A239176P487 | Varnish | ar |
| 80 | 84C620991G7 | Rotor assembly | 1 |
| 81 | 41C637599P1 | Punching-main | 860 |
| 82 | 41C637600P2 | Punching-end | 2 |
| 83 | 41C637602P1 | End plate,rotor | 2 |
| 84 | 84C615787P1 | End ring,rotor | 2 |
| 85 | 84D730316P1 | Shaft,rotor | 1 |
| 86 | 8864959P200 | nut | 1 |
| 87 | 8864959P134 | Lockwasher | 1 |
| 88 | 2766829ADP43 | Weight | ar |
| 89 | 84B517263P1 | Ring | 1 |
| 90 | 84B517262P1 | Baffle | 1 |
| 91 | N22P25016B13 | Capscrew | 8 |
| 92 | 41B637660P1 | Flatwasher | 8 |
| 93 | 41A330161P3 | Collar | 1 |
| 94 | 41A330313P1 | Collar | 1 |
| 95 | 84C602205P1 | Adapter ring | 1 |
| 96 | 84C602212P1 | Frame head | 1 |
| 97 | 41B537999P2 | Housing,bearing | 1 |
| 98 | 8864951P342 | Bearing-pinion end | 1 |
| 99 | 41A238968P1 | Collar-pinion end | 1 |
| 100 | 41A330203P4 | V-sealing ring | 1 |
| 101 | 497A806P60 | Sealer,rtv | ar |
| 102 | N22P29024B13 | Capscrew | 4 |
| 103 | 41B537660P6 | Flatwasher | 4 |
| 104 | 84A203143P2 | Seal-lip | 1 |
| 105 | 41B535916P3 | Cap-bearing | 1 |
| 106 | 84C602206P2 | Frame head | 1 |
| 107 | 84C602201P2 | Sensor,wheel | 1 |
| 108 | 8864950P361 | Ball bearing | 1 |
| 109 | 84C602202P2 | Bearing Cap | 1 |
| 110 | 41A237287P4 | Packing,frame/hd,collar | 1 |
| 111 | N22P29020B13 | Capscrew | 6 |
| 112 | 41B537660P6 | Flatwasher | 6 |
| 113 | 497A806P9 | Cement | ar |
| 114 | 41C637587P1 | Brake hub | 1 |
| 115 | 41A239366P1 | Plate hub | 1 |
| 116 | 41A230085P2 | Washer | 1 |
| 117 | N22P39040 | Capscrew | 1 |
| 118 | 41A330203P3 | V-sealing ring | 1 |
| 119 | 84B517272G1 | Cleat,support | 1 |
| 120 | 84B517270P1 | Cleat,cable | 2 |
| 121 | 84A230046P1 | Plate | 1 |
| 122 | 41A328039EBP4 | Sensor,speed | 1 |
| 123 | 41A328039EBP6 | Cable assembly,wheel speed | 1 |
| 124 | N22P29024B13 | Capscrew | 4 |
| 125 | 41B537660P6 | Washer | 4 |
| 126 | N14P33024B | Capscrew | 10 |
| 127 | 41B537660P9 | Washer | 42 |
| 128 | N170P33032B | Bolt | 20 |
| 129 | N22P33036B13 | Bolt | 12 |
| 130 | N22P25016B13 | Capscrew | 3 |
| 131 | N22P25056B13 | Capscrew | 2 |
| 132 | 41B537660P1 | Washer | 7 |
| 133 | 499A906AAP4 | Nut | 2 |
| 134 | 41D735064P2 | Adapter ring | 1 |
| 135 | 41A235568P2 | Bolt | 9 |
| 136 | 41A230085P2 | Washer | 9 |
| 137 | 84C616772G1 | Cover-sun pinion | 1 |
| 138 | 41A232938P1 | Gasket-sun (pinion)cover | 1 |
| 139 | 41A235717P2 | Bolt | 6 |
| 140 | 41A239786G8 | Sun pinion shaft and ring assembly | 1 |
| 141 | 41B537662P1 | Ring-drive | 1 |
| 142 | N14P29064B13 | Capscrew | 1 |
| 143 | 41B537660P6 | Flatwasher | 1 |
| 144 | N22P29024B13 | Bolt | 3 |
| 145 | N402P15B13 | Flatwasher | 4 |
| 146 | N405P45B13 | Lockwasher | 3 |
| 147 | N213P29B13 | Nut | 3 |
| 148 | 41A230782P3 | Clamp-cable | 1 |
| 149 | 41A239734P1 | Pad | 1 |
| 150 | 84A230055P1 | Pad | 1 |
| 151 | N22P29020B13 | Capscrew | 1 |
| 152 | N44P9008B13 | Screw | 4 |
| 153 | N210P9B13 | Nut | 4 |
| 154 | N405P35B13 | Lockwasher | 4 |
| 155 | N402P5B13 | Washer | 4 |
| 156 | 41A239176P16 | Tape,cloth | ar |
| 157 | 41A239176P487 | Varnish | ar |
| 158 | 497A806P12 | Adhesive | ar |
| 159 | 41B537457P1 | Seal-housing to frame | 1 |
| 160 | 41C637606G1 | Hub cap assembly | 1 |
| 161 | 41A305721P1 | Handle,wheelmotor cover | 2 |
| 162 | 41B538046G1 | Latch assembly | 4 |
| 163 | 41A239375P1 | Screen | 2 |
| 164 | 84C604519G2 | Rotor assembly | ar |
| Terex MT3700 | ||||
| Item | MFG | PN# | Description | QTY |
| 1 | Terex | 2000655 | gear and piston | 3 |
| 2 | Terex | 2000650 | torque tube | 1 |
| 3 | Terex | 901252 | washer | 44 |
| 4 | Terex | 915576 | ring,adapter | 1 |
| 5 | Terex | 2001472 | motor | 1 |
| 6 | Terex | 914486 | bearing | 3 |
| 7 | Terex | 2000651 | bearing cap | 3 |
| 8 | Terex | 914485 | bearing | 3 |
| 9 | Terex | 915553 | flat washer | 40 |
| 10 | Terex | 10035 | capscrew | 16 |
| 11 | Terex | 914483 | nut | 3 |
| 12 | Terex | 914484 | lockwasher | 3 |
| 13 | Terex | 914473 | bearing,inboard | 1 |
| 14 | Terex | 2000769 | hub,wheel | 1 |
| 15 | Terex | 914468 | seal ring | 1 |
| 16 | Terex | 914476 | wear band | 3 |
| 17 | Terex | 914480 | wear band | 1 |
| 18 | Terex | 914481 | oil seal | 1 |
| 19 | Terex | 2000345 | O'ring | 1 |
| 20 | Terex | 914479 | packing | 1 |
| 21 | Terex | 913820 | cement | 1 |
| 22 | Terex | 914837 | seal ring | 1 |
| 23 | Terex | 10330 | plug,pipe | 16 |
| 24 | Terex | 2000704 | flinger | 1 |
| 25 | Terex | 10028 | screw | 36 |
| 26 | Terex | 901188 | seal | ar |
| 27 | Terex | 2000347 | clamp | 36 |
| 28 | Terex | 913476 | sealer | 1 |
| 29 | Terex | 914488 | seal housing | 1 |
| 30 | Terex | 916116 | capscrew | 18 |
| 31 | Terex | 914634 | planet cover | 1 |
| 32 | Terex | 901930 | capscrew | 52 |
| 33 | Terex | 914721 | seal | 2 |
| 34 | Terex | 915300 | ring | 1 |
| 35 | Terex | 2000654 | collar | 3 |
| 36 | Terex | 2001547 | bearing cap | 3 |
| 37 | Terex | 2000653 | ring | 3 |
| 38 | Terex | 2001548 | sleeve | 3 |
| 39 | Terex | 914489 | seal ring | 1 |
| 40 | Terex | 15605 | cement | 1 |
| 41 | Terex | 914508 | pinion&shaft | 1 |
| 42 | Terex | 914440 | sun pinion cover | 1 |
| 43 | Terex | 901260 | plug magnetic | 1 |
| 44 | Terex | 901930 | capscrew | 6 |
| 45 | Terex | 900656 | gasket | 1 |
| 46 | Terex | 914843 | ring | 1 |
| 47 | Terex | 10039 | capscrew | 1 |
| 48 | Terex | 915553 | flat washer | 1 |
| 49 | Terex | 10012 | capscrew | 4 |
| 50 | Terex | 2001064 | tape fiberglass | 1 |
