| REAR AXLE RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9079589 | CYLINDER-RIDE |
| 2 | 9079587 | ROD ASSY |
| 3 | 9167506 | BEARING |
| 4 | 9425517 | RING-SNAP |
| 5 | 9411010 | FITTING-GREASE |
| 6 | 9068666 | WASHER-HARDENED |
| 7 | 9013688 | VALVE-CHECK |
| 8 | 444613 | PLUG |
| 9 | 169162 | BALL |
| 10 | 9256608 | WIPER |
| 11 | 9411019 | NIPPLE-GREASE |
| 12 | 15233757 | SEAL |
| 13 | 9015063 | SEAL-RETAINER |
| 14 | 9015056 | RING-BACKUP |
| 15 | 9154249 | O RING |
| 16 | 9015057 | RING-WEAR PISTON |
| 17 | 9079588 | PISTON |
| 18 | 9068667 | BOLT |
| 19 | 9015066 | TUBE ASSEMBLY |
| 20 | 9167506 | BEARING |
| 21 | 9425517 | RING-SNAP |
| 22 | 6525035 | VALVE ASSY-RECHARGE |
| 23 | 9030336 | RING-LARGE |
| 24 | 9034883 | CORE |
| 25 | 179837 | BOLT |
| 26 | 9078692 | BOOT |
| 27 | 9078136 | PLATE |
| 28 | 9139822 | CLAMP |
| FRONT WHEEL, RIM AND TYPE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9270229 | WHEEL |
| 2 | 9253468 | STUD |
| 3 | 9250686 | RING |
| 4 | 9016971 | WASHER |
| 5 | 9433277 | CONE-INNER BEARING |
| 6 | 9433278 | CUP-INNER BEARING |
| 7 | 15231599 | VALVE EXTENSION |
| 8 | 15004075 | BASE |
| 9 | 9195954 | FLANGE |
| 10 | 9012404 | BAND-BEAD SEAT |
| 11 | 9003669 | LOCK RING |
| 12 | 9003519 | O RING |
| 13 | 15230597 | VALVE STEM |
| 14 | 9142286 | CORE |
| 15 | 9116292 | CAP |
| 16 | 9432641 | CUP-OUTER BEARING |
| 17 | 9432640 | CONE-OUTER BEARING |
| 18 | 9253679 | SHIM .005 |
| 19 | 9253681 | SHIM .020 |
| 20 | 9253680 | SHIM .007 |
| 21 | 9253619 | PLATE |
| 22 | 9253620 | BOLT |
| 23 | 9115806 | CAP-HUB |
| 24 | 179881 | BOLT |
| 25 | 103329 | LOCK WASHER |
| 26 | 9433576 | NUT |
| 27 | 9016973 | SEAL |
| 28 | 15023746 | CLAMP |
| 29 | 9113457 | LOCK WIRE |
| 30 | 9207478 | GASKET |
| FRONT AXLE SLACK ADJUSTER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15014970 | ADJUSTER-SLACK RH |
| 2 | 9039926 | RIVET |
| 3 | 9039910 | COVER |
| 4 | 9039912 | GEAR-WORM |
| 5 | 9024901 | WORM |
| 6 | 9033031 | SHAFT |
| 7 | 9054078 | BUSHING |
| 8 | 9411010 | FITTING-GREASE |
| FRONT RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9079452 | FRONT RIDE CYLINDER |
| 2 | 6525035 | VALVE ASSY-RECHARGE |
| 3 | 9013688 | VALVE-CHECK |
| 4 | 444613 | PLUG |
| 5 | 15019179 | O RING |
| 6 | 9015056 | RING-BACKUP |
| 7 | 9068668 | TUBE |
| 8 | 9068667 | BOLT |
| 9 | 9079450 | PISTON |
| 10 | 9014093 | RING-WEAR |
| 11 | 9169669 | O RING |
| 12 | 9036867 | RING-BACKUP |
| 13 | 9079449 | RETAINER SEAL |
| 14 | 15233756 | SEAL |
| 15 | 9120034 | O RING |
| 16 | 186659 | BOLT |
| 17 | 9411010 | FITTING-GREASE |
| 18 | 9072925 | TUBE ASSEMBLY |
| 19 | 15255936 | RING WEAR |
| 20 | 9014235 | SEAL |
| 21 | 9256606 | WIPER |
| 22 | 9079451 | ROD PISTON |
| 23 | 169162 | BALL |
| 24 | 106671 | FILLING-RELIEF |
| 25 | 274209 | LOCKNUT |
| 26 | 9068666 | WASHER-HARDENED |
| 27 | 9019631 | WASHER-HARDENED |
| 28 | 9430339 | BOLT |
| 29 | 9014267 | DISC (1.00 IN) |
| 30 | 103332 | LOCK WASHER |
| 31 | 271613 | BOLT |
| 32 | 9017345 | KEY-SHEAR |
