| 45 | 444619 | PLUG |
| 46 | 118757 | ELBOW |
| 47 | 9120883 | HOSE ASSY |
| 48 | 273469 | PLUG |
| 49 | 144217 | HUSHING |
| 50 | 454145 | TEE |
| 51 | 9250235 | TEE |
| 52 | 9403101 | TEE |
| 53 | 9252513 | ELBOW |
| 54 | 179764 | BUSHING |
| 55 | 2356564 | VALVE-CHECK |
| 56 | 9248550 | ELBOW |
| 57 | 9120881 | HOSE ASSY |
| 58 | 9253495 | HOSE ASSY |
| 59 | 9402711 | CONNECTOR |
| 60 | 9188752 | HOSE ASSY |
| 61 | 119920 | NIPPLE |
| 62 | 142664 | ELBOW |
| 63 | 9231083 | ELBOW |
| 64 | 15227016 | VALVE-AIR REGULATOR |
| 65 | 9033723 | ADAPTOR |
| 66 | 454106 | ELBOW |
| 67 | 8040339 | ELBOW |
| 68 | 9268487 | HOSE ASSY |
| 69 | 9120879 | CONNECTOR |
| 70 | 9120753 | HOSE ASSY |
| 71 | 9120862 | CONNECTOR |
| 72 | 9120864 | HOSE ASSY |
| 73 | 454136 | TEE |
| 74 | 454134 | TEE |
| 75 | 118752 | CONNECTOR-ELBOW |
| 76 | 444029 | REDUCER |
| 77 | 9402828 | ELBOW |
| 78 | 9233142 | TUBE-NYLON |
| 79 | 187394 | COUPLING |
| 80 | 187395 | COUPLING |
| 81 | 105405 | NIPPLE |
| 82 | 105407 | NIPPLE |
| 83 | 9384875 | ELBOW-ADAPTOR |
| 84 | 9384876 | ELBOW-ADAPTOR |
| 85 | 141621 | ELBOW |
| 86 | 9012095 | VALVE-P/BRAKE |
| 87 | 9015336 | VALVE-TREADLE |
| 88 | 2402041 | VALVE-DRY/SLIP |
| 89 | 2396430 | VALVE ASSY-LIMITING |
| 90 | 9259128 | CHAMBER ASSY - LH |
| 91 | 9259129 | CHAMBER ASSY - RH |
| 92 | 9060281 | VALVE ASSY-SYNCRO |
| 93 | 9374627 | VALVE-QUICK RELEASE |
| 94 | 15248292 | TANK-AIR |
| 95 | 9006527 | VALVE ASSY-CONTROL |
| 96 | 9200096 | CHAMBER ASSY-BRAKE |
| 97 | 9018245 | VALVE-RELAY |
| AIR TANK AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15248292 | TANK-AIR |
| 2 | 9387954 | PLUG (1.25 IN) |
| 3 | 444637 | PLUG (0.75 IN) |
| 4 | 444631 | PLUG (0.50 IN) |
| 5 | 444625 | PLUG (0.38 IN) |
| 6 | 9015824 | STRAP |
| 7 | 108580 | LOCK WASHER |
| 8 | 102635 | NUT |
| 9 | 9250238 | ANGLE |
| 10 | 179841 | BOLT |
| 11 | 106263 | WASHER |
| 12 | 9017395 | STRAP |
| AIR TREADLE VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9015336 | TREADLE VALVE |
| 2 | 9053174 | VALVE ASSY |
| 3 | 2405320 | O RING |
| 4 | 2408933 | VALVE |
| 5 | 2497505 | O RING UPPER |
| 6 | 2425411 | RETAINER |
| 7 | 2497506 | O RING LOWER |
| 8 | 2497501 | SEAT RING |
| 9 | 9392541 | O RING |
| 10 | 2497149 | PISTON ASSY |
| 11 | 103496 | PIN |
| 12 | 444619 | PLUG-1/4 IN |
| FRONT AIR BRAKE CHAMBER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9259128 | CHAMBER ASSY - LH |
| 2 | 9259129 | CHAMBER ASSY - RH |
| 2 | 444619 | PLUG |
| 3 | 9036145 | DIAPHRAGM |
| 4 | 2465113 | SHAFT |
| 5 | 2465132 | SPRING-RETURN |
| 6 | 9411010 | FITTING-GREASE |
| 7 | 3858069 | O RING |
| 8 | 3858070 | PISTON |
| 9 | 3858071 | COLLAR |
| 10 | 2466114 | O RING |
| 11 | 668304 | CAP |
| 12 | 3858065 | RING-RETAINER |
| 13 | 9034991 | ROD |
| 14 | 2465130 | BOOT |
| 15 | 103385 | PIN-COTTER |
| 16 | 114498 | LOCK NUT |
| 17 | 103325 | WASHER SPRING LOCK |
| AIR BRAKE CHAMBER / PRESSURE CONVERTER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9200096 | CHAMBER ASSY - BRAKE |
| 2 | 9023595 | BODY |
| 3 | 103320 | LOCK WASHER |
| 4 | 9034481 | SEAL-WASHER |
| 5 | 9033736 | BOOT |
| 6 | 9428735 | BOLT |
| 7 | 9023596 | CLAMP |
| 8 | 9034550 | CLAMP |
| 9 | 9023280 | DIAPHRAGM |
| 10 | 9023598 | GUIDE |
| 11 | 9033739 | SHAFT |
| 12 | 103319 | LOCK WASHER |
| 13 | 9033732 | SPRING-RETURN |
| 14 | 2466115 | BEARING |
| 15 | 2466113 | COVER |
| 16 | 2466114 | O RING |
| 17 | 2466117 | O RING |
| 18 | 9033874 | O RING |
| 19 | 9033733 | HOUSING |
| 20 | 9033735 | STUD |
| 21 | 103326 | WASHER SPRING LOCK |
| 22 | 2466118 | PISTON |
| 23 | 2466120 | ROLLER |
| 24 | 2466119 | COLLAR |
| 25 | 2466121 | WASHER |
| 26 | 2466122 | SPRING |
| 27 | 2466106 | CAP |
| 28 | 2466116 | FELT PAD |
| 29 | 9033738 | ROD |
| 30 | 9037277 | CLEVIS ASSY |
| 31 | 9023603 | PIN |
| 32 | 103398 | COTTER PIN |
| AIR QUICK RELEASE/LIMITING VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 2396430 | VALVE ASSY-LIMITING |
| 2 | 2400285 | VALVE ASSY |
| AIR HORN LINES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 179820 | BOLT |
| 2 | 102634 | NUT |
| 3 | 103320 | LOCK WASHER |
