Terex earthmoving equipment parts
NC NO. QTY PART NO. DESCRIPTION
001 001 20017480 PUMP ASSY
A 002 001 20021766 ·SHAFT SEAL - FRONT
STEERING LINKAGE
NC NO. QTY PART NO. DESCRIPTION
001 001 09016976 SPINDLE ASSY-LEFT
003 002 09250759 ·BUSHING
004 001 00431715 ·VALVE
005 001 09016972 ·SPACER
006 001 09016977 SPINDLE ASSY-RIGHT
008 002 09250759 ·BUSHING
009 001 00431715 ·VALVE
010 001 09016972 ·SPACER
011 002 00103426 COTTER PIN
012 001 09253993 ARM-LEFT
013 001 09253994 ARM-RIGHT
014 012 00223489 BOLT
015 002 00427667 NUT
016 002 09253557 OIL SEAL
017 002 09253566 BUSHING
018 002 09018310 RING-RETAINER
019 002 09258621 PIN
020 002 09018309 PLATE
021
022
023
024 004 00103415 COTTER PIN
NC NO. QTY PART NO. DESCRIPTION
025
026
027 002 15237698 STEERING TIE-ROD
028
029
030
031 001 09253925 STEERING CRANK
032 002 15230267 WASHER
034 001 09411019 NIPPLE-GREASE
035 002 09253492 PAD
036 004 00179839 BOLT
037 004 00108580 LOCKWASHER
038 002 00131296 PLUG
039 002 15230266 BUSHING
040 001 09384854 PIN
041 001 09014471 PIN-LOCK
042 001 00103332 LOCKWASHER
043 001 00218197 NUT
044 002 00444613 PLUG
045 010 00179841 BOLT
A 046 002 15237869 PIN
A 046 002 09384856 PIN
| RADIATOR GUARD AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15254571 | GRILLE-BOTTOM |
| 2 | 15254572 | GRILLE-TOP |
| 3 | 271605 | BOLT |
| 4 | 179889 | BOLT |
| 5 | 9270000 | WASHER-HARDENED |
| 6 | 179883 | BOLT |
| 7 | 9176228 | WASHER-HARDENED |
| MUDGUARDS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15309981 | MUDFLAP |
| 2 | 15302966 | PLATE-CLAMPING |
| 3 | 15309991 | PLATE-BACKING |
| 4 | 179883 | BOLT |
| 5 | 179885 | BOLT |
| 6 | 103329 | LOCKWASHER |
| 7 | 120378 | NUT |
| 8 | 9267949 | WASHER-HARDENED |
| 9 | 15246422 | MUDFLAP-LH |
| 10 | 15302964 | BRACKET-LH |
| 11 | 15312422 | MUD FLAP |
| 12 | 15313089 | PLATE-CLAMPING |
| 13 | 15313088 | MUD FLAP-LH |
| 14 | 15302963 | MUD FLAP-RH |
| 15 | 15309984 | MUDFLAP LH REAR |
| 16 | 179881 | BOLT |
| 17 | 179890 | BOLT |
| 18 | 15309985 | PLATE-BACKING |
| 19 | 15312421 | PLATE-BACKING |
| ENGINE AND MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15267514 | FILTER-LUBE BYPASS |
| 2 | 15267633 | FILTER-FUEL |
| 3 | 15266845 | FILTER WF-15DCA4 |
| 4 | 15267513 | FILTER-LUBE OIL |
| 5 | 15273590 | FAN BELT |
| 6 | 223464 | BOLT |
| 7 | 15020053 | WASHER |
| 8 | 9269110 | MOUNTING-SHOCK |
| 9 | 223458 | BOLT |
| 10 | 9176228 | WASHER-HARDENED |
| 11 | 9250715 | WASHER-HARDENED |
| 12 | 9419493 | LOCKNUT |
| 13 | 223452 | BOLT |
| 14 | 9068286 | BRACKET-ENG MTG REAR |
| 15 | 15246912 | FLANGE-COUPLING |
| 16 | 9409907 | BOLT |
| 17 | 9423067 | BOLT |
| 18 | 9060202 | WASHER-HARDENED |
| 19 | 15228210 | COUPLING-DRIVE |
| 20 | 179885 | BOLT |
| 21 | 186729 | BOLT |
| 22 | 15245965 | TUBE ASSY |
| 23 | 15245968 | TUBE ASSY |
| 24 | 142269 | BUSHING-REDUCER |
| 25 | 144218 | BUSHING |
| 26 | 271619 | BOLT |
| 27 | 15019632 | SUPPORT |
