Terex earthmoving equipment parts
NC NO. QTY PART NO. DESCRIPTION
001 001 20017480 PUMP ASSY
A 002 001 20021766 ·SHAFT SEAL - FRONT
STEERING LINKAGE
NC NO. QTY PART NO. DESCRIPTION
001 001 09016976 SPINDLE ASSY-LEFT
003 002 09250759 ·BUSHING
004 001 00431715 ·VALVE
005 001 09016972 ·SPACER
006 001 09016977 SPINDLE ASSY-RIGHT
008 002 09250759 ·BUSHING
009 001 00431715 ·VALVE
010 001 09016972 ·SPACER
011 002 00103426 COTTER PIN
012 001 09253993 ARM-LEFT
013 001 09253994 ARM-RIGHT
014 012 00223489 BOLT
015 002 00427667 NUT
016 002 09253557 OIL SEAL
017 002 09253566 BUSHING
018 002 09018310 RING-RETAINER
019 002 09258621 PIN
020 002 09018309 PLATE
021
022
023
024 004 00103415 COTTER PIN
NC NO. QTY PART NO. DESCRIPTION
025
026
027 002 15237698 STEERING TIE-ROD
028
029
030
031 001 09253925 STEERING CRANK
032 002 15230267 WASHER
034 001 09411019 NIPPLE-GREASE
035 002 09253492 PAD
036 004 00179839 BOLT
037 004 00108580 LOCKWASHER
038 002 00131296 PLUG
039 002 15230266 BUSHING
040 001 09384854 PIN
041 001 09014471 PIN-LOCK
042 001 00103332 LOCKWASHER
043 001 00218197 NUT
044 002 00444613 PLUG
045 010 00179841 BOLT
A 046 002 15237869 PIN
A 046 002 09384856 PIN
| 13 | 6440830 | SCREW |
| 14 | 271505 | NUT |
| 15 | 15302065 | PIN |
| 16 | 15302357 | BENT PLATE |
| 17 | 6350840 | SCREW |
| 18 | 7150815 | WASHER |
| 19 | 103339 | WASHER |
| 20 | 9362607 | BRACKET |
| 21 | 15302373 | BENT PLATE |
| 22 | 9056269 | CLIP-RUBBERIZED |
| 23 | 9100399 | SPRING CLIP |
| 24 | 179795 | BOLT |
| 25 | 109084 | NUT |
| RADIATOR ASSEMBLY | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15311874 | RADIATOR ASSY |
| 2 | 15275344 | TANK-TOP |
| 3 | 15268993 | TANK-CENTER |
| 4 | 15275345 | TANK-BOTTOM |
| 5 | 15270492 | FRAME SIDE-LH |
| 6 | 15268998 | STIFFNER-CTRE TANK |
| 7 | 15269000 | ROD-CROSSBRACE |
| 8 | 15275346 | BAR-SUPPORT |
| 9 | 15268709 | BOLT-U |
| 10 | 15268694 | WASHER-SPRING SQR. |
| 11 | 15268710 | PLATE |
| 12 | 15269002 | GASKET-CENTRE TANK |
| 13 | 15268691 | WASHER |
| 14 | 15268991 | WASHER |
| 15 | 15269004 | PLATE-CENTRE TUBE |
| 16 | 15268676 | FERRULE-RUBBER |
| 17 | 15268675 | FERRULE-BRASS |
| 18 | 15275433 | TUBE-JOULE |
| 19 | 15268963 | WASHER |
| 20 | 15268964 | LOCKWASHER |
| 21 | 15268689 | LOCKWASHER |
| 22 | 15268682 | WASHER |
| 23 | 15268688 | SCREW |
| 24 | 15269007 | SCREW |
| 25 | 15269008 | SCREW |
| 26 | 15268693 | SCREW |
| 27 | 15268690 | NUT |
| 28 | 15268681 | NUT |
| 29 | 15268685 | LOCKNUT |
| 30 | 15268686 | NUT |
| 31 | 15268997 | SET-STIFFENER BARS |
| RADIATOR MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103332 | LOCKWASHER |
| 2 | 106263 | WASHER |
| 3 | 179839 | BOLT |
| 4 | 179841 | BOLT |
| 5 | 179843 | BOLT |
| 6 | 223464 | BOLT |
| 7 | 274141 | NUT |
| 8 | 444625 | PLUG(0.38 IN) |
| 9 | 444679 | PLUG |
| 10 | 9139927 | WASHER |
| 11 | 9182221 | MOUNT-FLEXIBLE |
| 12 | 9186377 | MOUNT-FLEXIBLE |
| 13 | 9187694 | WASHER |
| 14 | 15254781 | PLATE-ANTIRECIRC`N |
| 15 | 274208 | LOCKNUT |
| 16 | 9419493 | LOCKNUT |
| 17 | 15238144 | RING-SHROUD |
| 18 | 15238145 | SCREEN LH |
| 19 | 15238146 | SCREEN RH |
| 20 | 15247519 | ROD-RADIATOR |
| 21 | 15254459 | SHROUD ASSY |
| 22 | 103341 | WASHER |
| 23 | 179833 | BOLT |
| 24 | 15256620 | PLATE-ANTIRECIRC`N |
| RADIATOR PIPING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9214526 | CLAMP |
| 2 | 9257169 | TIE-CABLE |
| 3 | 15304383 | SILICONE HOSE |
| 4 | 9267949 | WASHER |
| 5 | 179887 | BOLT |
| 6 | 103339 | WASHER |
| 7 | 103319 | LOCKWASHER |
| 8 | 15323236 | CLAMP |
| RADIATOR HEADER TANK AND HOSES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15254778 | REMOTE HEADER TANK |
| 2 | 15230178 | NUT-WINDOW |
| 3 | 15255877 | HOSE ASSY |
| 4 | 15255879 | HOSE ASSY |
| 5 | 15255880 | HOSE ASSY |
| 6 | 9228659 | HOSE-BULK |
| 7 | 9402826 | ELBOW |
| 8 | 9402708 | CONNECTOR |
| 9 | 9152893 | CLIP |
| 10 | 179837 | BOLT |
| 11 | 179838 | BOLT |
| 12 | 179883 | BOLT |
| 13 | 102635 | NUT |
| 14 | 444698 | PLUG |
| 15 | 103319 | LOCKWASHER |
| 16 | 108580 | LOCKWASHER |
| 17 | 109084 | NUT |
| 18 | 9267949 | WASHER-HARDENED |
| 19 | 9066282 | CAP |
| 20 | 9024628 | GASKET |
| 21 | 15236152 | SWITCH-LEVEL FLOAT |
| 22 | 9030744 | TUBING |
| 23 | 179839 | BOLT |
| OIL COOLER PIPING-DISC BRAKES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15236505 | TUBE ASSY |
| 2 | 15245374 | TUBE ASSY |
| 3 | 15236511 | TUBE ASSY |
| 4 | 9071313 | TUBE ASSY |
| 5 | 15236508 | TUBE ASSY |
| 6 | 15250497 | TUBE ASSY |
| 7 | 15236509 | TUBE ASSY |
| 8 | 15301594 | PIPE ASSEMBLY |
| 9 | 15258071 | HOSE ASSY |
| 10 | 15248180 | HOSE ASSY |
| 11 | 15250626 | HOSE ASSY |
| 12 | 15258073 | HOSE ASSY |
| 13 | 15300378 | HOSE ASSY |
| 14 | 15245140 | HOSE ASSY |
| 15 | 15245138 | HOSE ASSY |
| 16 | 15245139 | HOSE ASSY |
| 17 | 15245132 | HOSE ASSY |
| 18 | 15257628 | HOSE ASSY |
| 19 | 15245134 | HOSE ASSY |
| 20 | 15245135 | HOSE ASSY |
| 21 | 15245133 | HOSE ASSY |
| 22 | 15245136 | HOSE ASSY |
| 23 | 15300455 | BRACKET |
| 24 | 15300456 | CLAMP |
| 25 | 15250566 | BRACKET ASSY |
| 26 | 9067454 | CLAMP |
| 27 | 15300496 | CLAMP |
| 28 | 15024973 | CLAMP-TUBE |
| 29 | 9072826 | CLAMP |
| 30 | 15004713 | CLAMP |
| 31 | 15004712 | CLAMP |
| 32 | 15001429 | CLAMP |
| 33 | 15004744 | BUSHING-SPLIT |
| 34 | 15015251 | BUSHING-SPLIT |
| 35 | 15015249 | BUSHING-SPLIT |
| 36 | 15004748 | NUT-STACKING |
| 37 | 15001428 | NUT-STACKING |
| 38 | 179883 | BOLT |
| 39 | 179890 | BOLT |
| 40 | 179839 | BOLT |
| 41 | 179841 | BOLT |
| 42 | 9167602 | FLANGE-SPLIT |
| 43 | 9409985 | FLANGE-SPLIT |
| 44 | 9409984 | FLANGE-SPLIT |
| 45 | 15002672 | O RING |
| 46 | 15008262 | O RING |
| 47 | 15008261 | O RING |
| 48 | 179885 | BOLT |
| 49 | 179887 | BOLT |
| 50 | 103329 | LOCKWASHER |
| 51 | 15008260 | O RING |
