| 220-0050-7881 PUMP-STEERING |
| FROM SERIAL NO. T7881001 |
| SER.NO. SER.NO. |
| NC REF QTY PART NO. DESCRIPTION FROM TO |
| 000 001 15229403 STEERING PUMP |
| 001 008 09058044 .SCREW |
| 002 002 09058045 .COVER |
| A 003 001 09058106 .KIT-SHIM |
| B 004 002 09028466 .O RING |
| 005 002 09058046 .SPACER |
| 006 002 NSS .BEARING |
| 007 001 02340310 .RING-RETAINER |
| B 008 001 09058048 .SEAL |
| 009 001 NSS .HOUSING |
| 010 006 09058069 .SCREW |
| B 011 001 NSS .GASKET |
| 012 001 09058075 .BEARING |
| 013 001 09058072 .SPRING |
| 014 001 09058073 .SEAT |
| 015 001 09058074 .SEAT |
| 016 001 09417456 .PIN-ROLL |
| 017 001 09058076 .YOKE |
| 018 001 09058077 .RETAINER |
| 019 001 09399072 .BLOCK |
| 020 001 09399069 .SHAFT |
| C 021 009 NSS .PIST & SH |
| C 022 001 NSS .PISTON |
| 023 001 NSS .ROD |
| B 024 001 NSS .O RING |
| C 025 001 NSS .PLATE |
| C 026 001 NSS .WASHER |
| C 027 001 NSS .PIN RETAI |
| C 028 003 NSS .PIN |
| C 029 001 NSS .CYL BLOCK |
| C 030 001 NSS .WASHER |
| C 031 001 NSS .SPRING |
| 032 001 NSS .WASHER |
| 033 001 09058105 .BEARING |
| C 034 001 09059082 .SUPERCEDED MATERIAL |
| 035 001 09398181 .PLATE-WAFER |
| 036 001 09058094 .BEARING |
| 037 002 09058095 .PIN-ROLLER |
| 038 001 09058096 .PIN-DOWEL |
| 039 001 00444854 .SUPERCEDED MATERIAL |
| B 040 001 09399071 .O RING |
| 041 001 09058097 .PLUG |
| 042 001 09058098 .SEAT |
| 043 001 09058099 .VALVE |
| 044 001 09058100 .SPRING |
| 045 001 09053287 .KIT-COMPENSATOR |
| 046 001 09050169 ..RETAINER |
| B 047 001 09050239 ..GASKET |
| B 048 001 NSS ..O RING |
| 049 001 09399073 ..PLUG |
| 050 004 09399074 ..SCREW |
| 051 001 09050202 ..BODY COMPENSATOR |
| 052 001 09050219 ..SPOOL |
| 053 001 09050191 ..SEAT |
| 054 001 09050194 ..SPRING |
| B 055 001 NSS ..O RING |
| B 056 001 09044413 ..SEAL |
| 057 001 09050218 ..PLUG |
| 058 001 09113457 ..LOCKWIRE |
| NOTES: |
| A ONE SHIM KIT FOR BOTH YOKE BEARINGS |
| B PARTS IN 9058104 SEAL KIT |
| C PARTS IN 9058110 ROTATING GROUP |
| 6 | 23018444 | PISTON |
| 7 | 23048511 | PLATE |
| 8 | 23016957 | PLATE |
| 9 | 954528 | BEARING |
| 10 | 6883524 | TURBINE |
| 11 | 181370 | BOLT |
| 12 | 9409037 | BOLT |
| TRANSMISSION CONVERTER HOUSING GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6882326 | GASKET |
| 2 | 103321 | LOCK WASHER |
| 3 | 187238 | BOLT |
| 4 | 103323 | WASHER |
| 5 | 103322 | LOCK WASHER |
| 6 | 179862 | BOLT |
| 7 | 179837 | BOLT |
| TRANSMISSION OIL PUMP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6838843 | PUMP ASSY |
| 2 | 23016947 | SEAL |
| TRANSMISSION LOCK-UP VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 454818 | BOLT |
| TRANSMISSION RETARDER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23048395 | PLATE-RETARDER |
| 2 | 6837657 | ROTOR ASSY |
| 3 | 9422848 | WASHER |
| 4 | 23046658 | GASKET |
| 5 | 9414876 | RING-SNAP |
| 6 | 6834946 | WASHER |
| 7 | 6834456 | PIN |
| 8 | 6839268 | SPRING |
| 9 | 6839010 | VALVE |
| 10 | 6839525 | TUBE |
| 11 | 9409030 | BOLT |
| TRANSMISSION RETARDER CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6833409 | KIT-SEAL |
| 2 | 103321 | LOCK WASHER |
| 3 | 6838525 | PIVOT |
| 4 | 179838 | BOLT |
| 5 | 450517 | BOLT |
| 6 | 186284 | BOLT |
| 7 | 444631 | PLUG(0.50") |
| TRANSMISSION MAIN HOUSING GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 187238 | BOLT |
| 2 | 103323 | WASHER |
| 3 | 454815 | BOLT |
| 4 | 103339 | WASHER |
| 5 | 273340 | BOLT |
| 6 | 454818 | BOLT |
| 7 | 445968 | BOLT |
| 8 | 23016681 | GASKET |
| 9 | 6774322 | COVER |
| 10 | 179837 | BOLT |
| 11 | 103028 | NUT |
| 12 | 6885148 | KIT-PAN |
| 13 | 7964576 | BREATHER |
| 14 | 179818 | BOLT |
| 15 | 444335 | REDUCER |
| TRANS. HIGH RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23011235 | PLATE |
| 2 | 23042199 | PLATE |
| 3 | 6834679 | PLATE |
| 4 | 6831704 | RING-SNAP |
| 5 | 6883192 | RETAINER-SPRING |
| 6 | 23016569 | PISTON-LETTER Z |
| 7 | 23016568 | PISTON-LETTER Y |
| 8 | 6836799 | SEAL |
| 9 | 6833980 | SEAL |
| TRANS. INTER RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23046099 | SHAFT ASSY - MAIN |
| 2 | 6834333 | DRUM |
| 3 | 29506042 | SHAFT |
| 4 | 6835323 | BUSHING |
| 5 | 6835073 | CARRIER ASSY |
| 6 | 6835074 | CARRIER |
| 7 | 6834575 | RING-SNAP |
| 8 | 6835321 | WASHER |
| 9 | 6835580 | FLANGE AND CARRIER |
| 10 | 6835322 | BUSHING |
| 11 | 23041786 | PLATE |
| 12 | 6836465 | SUPPORT ASSY |
| 13 | 23011453 | SEAL- INTERNAL |
| 14 | 6880079 | SUPPORT-HOUSING |
| 15 | 23011235 | PLATE |
| 16 | 6834327 | GEAR |
| TRANS. LOW RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23047771 | PLATE |
| 2 | 23041786 | PLATE |
| 3 | 6838558 | GEAR-REVERSE |
| 4 | 6836661 | RING-RETAINER |
| 5 | 6836659 | PISTON |
| 6 | 23011453 | SEAL-INTERNAL |
| 7 | 6881979 | HOUSING ASSY |
| 8 | 6883708 | PLUG |
| 9 | 6835369 | SEAL |
| TRANS. REVERSE RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23047771 | PLATE |
| 2 | 23041786 | PLATE |
| 3 | 6838558 | GEAR-REVERSE |
| 4 | 903017 | BEARING |
| TRANS. FORWARD RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23017215 | CLUTCH-INPUT |
| 2 | 6833980 | SEAL |
| 3 | 6836799 | SEAL |
| 4 | 23016569 | PISTON-LETTER Z |
| 5 | 23016568 | PISTON-LETTER Y |
| 6 | 6883192 | RETAINER-SPRING |
| 7 | 6831704 | RING-SNAP |
| 8 | 6839021 | HUB |
| 9 | 6834679 | PLATE-CLUTCH |
| 10 | 23042199 | PLATE |
| 11 | 6835605 | CLUTCH-HUB DRIVING |
| 12 | 6777231 | RING-SNAP |
| 13 | 6838695 | RING-SNAP |
| TRANSMISSION REAR COVER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 29505795 | BOLT |
| 2 | 103329 | LOCK WASHER |
| 3 | 191268 | BOLT |
| 4 | 6750924 | RING-SNAP |
| 5 | 6773311 | SEAL |
| FRONT DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9013987 | DRIVELINE ASSY |
| 2 | 9053746 | CROSS ASSY |
| 3 | 695456 | BOLT |
| 4 | 2366106 | STRAP |
| 5 | 9411010 | FITTING-GREASE |
| REAR DRIVELINE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9273082 | DRIVELINE ASSY |
| 2 | 15233277 | CROSS ASSY |
| 3 | 2366106 | STRAP |
| 4 | 695456 | BOLT |
| 5 | 9411010 | FITTING-GREASE |
| REAR AXLE DIFFERENTIAL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103393 | PIN-COTTER |
| 2 | 9192613 | NUT |
| 3 | 9003683 | GASKET |
| 4 | 9265937 | YOKE ASSY |
| 5 | 9232899 | SLEEVE |
| 6 | 9250409 | DIFFERENTIAL-2.50:1 |
| 7 | 15244338 | SEAL |
| 8 | 9003785 | SEAL-RETAINER |
| 9 | 9424975 | BEARING |
| 10 | 9250389 | GEAR SET |
| 11 | 7451617 | BEARING |
| 12 | 9216692 | BOLT |
| 13 | 9192618 | DOWEL-BUSHING |
| 14 | 9412692 | CUP |
| 15 | 9424974 | CONE |
| 16 | 9219084 | PIN-DOWEL |
| 17 | 9008341 | WASHER-THRUST |
| 18 | 9008357 | GEAR |
| 19 | 9008365 | WASHER-THRUST |
| 20 | 9008364 | PINION ASSY |
| 21 | 9008382 | SPIDER |
| 22 | 9113457 | LOCK WIRE |
| 23 | 9170517 | BOLT |
| 24 | 9114897 | SCREW |
| 25 | 179887 | BOLT |
| 26 | 139230 | SCREW |
| 27 | 15234244 | SEAL-CORD |
