| 33 | 15019494 | RETAINER |
| 34 | 15019483 | RING-GEAR |
| 35 | 9413420 | RING-SNAP |
| 36 | 15019482 | CARRIER-RING GEAR |
| 37 | 9433576 | NUT |
| 38 | 15246062 | WASHER-THRUST |
| 39 | 15015363 | BEARING |
| 40 | 139230 | SCREW |
| WHEEL RIM AND TYPE-REAR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15021101 | PLATE |
| 2 | 9063017 | SHIM-PACK |
| 3 | 15233384 | CONE-BEARING |
| 4 | 9437224 | CONE-BEARING |
| 5 | 15233385 | CUP-BEARING |
| 6 | 15233302 | WHEEL |
| 7 | 9253468 | STUD |
| 8 | 9255689 | STUD |
| 9 | 9063025 | BOLT |
| 10 | 9113457 | LOCKWIRE |
| 11 | 9209490 | O RING |
| 12 | 15017037 | BASE |
| 13 | 9063834 | FLANGE |
| 14 | 9074982 | BAND-BEAD SEAT |
| 15 | 9074983 | LOCKRING |
| 16 | 15017033 | BAND SPACER |
| 17 | 273469 | PLUG |
| 18 | 15023746 | CLAMP |
| 19 | 9433576 | NUT |
| 20 | 9211054 | VALVE ASSY |
| 21 | 9116292 | CAP |
| 22 | 9142286 | CORE |
| 23 | 15245476 | EXTENSION-VALVE |
| 24 | 9437225 | CUP-DEARING |
| 25 | 179880 | BOLT |
| 26 | 103329 | LOCKWASHER |
| 27 | 9074815 | SPUD |
| 28 | 9051190 | GROMMET |
| 29 | 15017039 | VALVE ASSY-INST |
| BRAKE PARTS-FRONT WHEEL-RIGIDS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15300389 | BRAKE HEAD ASSY |
| 2 | 9058895 | BOLT |
| 3 | 9058896 | WASHER |
| 4 | 15267039 | PLATE-THRUST |
| 5 | 15266825 | KIT-LINING |
| 6 | 9058900 | BOLT |
| 7 | 9058901 | WASHER |
| 8 | 9058905 | PISTON |
| 9 | 15271389 | KIT-SEAL |
| 10 | 9074283 | WASHER-HARDENED |
| 11 | 15300580 | CARRIER-FRONT |
| 12 | 15247360 | DISC-BRAKE |
| 13 | 15248418 | BOLT |
| 14 | 9226983 | BOLT |
| 15 | 15025751 | BOLT |
| 16 | 9008198 | WASHER |
| 17 | 15237514 | SHIM(0.060 IN) |
| 18 | 15237515 | SHIM(0.030 IN) |
| BRAKE PARTS-REAR WHEEL-RIGIDS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15233275 | SEAL HOUSING |
| 2 | 15302757 | O RING |
| 3 | 15302752 | SEAL ASSEMBLY |
| 4 | 15272374 | O RING |
| 5 | 9064938 | BOLT |
| 6 | 223493 | BOLT |
| 7 | 9019631 | WASHER |
| 8 | 15302758 | O RING |
| 9 | 9072627 | BOLT |
| 10 | 15310256 | WASHER-HARDENED |
| 11 | 15307380 | BRAKE ASSY |
| 12 | 223437 | BOLT |
| 13 | 9065332 | WASHER |
| 14 | 15247047 | SPRING HOUSING MACHINED |
| 15 | 9068505 | SCREW |
| 16 | 2276784 | SCREW-BLEED |
| 17 | 15258053 | SEAL-O RING |
| 18 | 784094 | PIN-DOWEL |
| 19 | 784088 | PIN-DOWEL |
| 20 | 9065306 | SPRING |
| 21 | 9065305 | SPRING |
| 22 | 15303608 | SEAL ASSY-PISTON |
| 23 | 15302125 | PARKING PISTON |
| 24 | 15258054 | SEAL-O RING |
| 25 | 15302126 | DISC HOUSING |
| 26 | 9183205 | PLUG |
| 27 | 274248 | O RING |
| 28 | 15302798 | DAMPER ASSY |
| 29 | 15302796 | DISC FRICTION |
| 30 | 15302797 | PLATE-SPLINTED |
| 31 | 15231497 | SERVICE PISTON MACHINED |
| 32 | 936559 | PIN |
| 33 | 179814 | BOLT |
| 34 | 9064810 | PLATE-RETAINER |
| 35 | 9064750 | PIN-RETAINING |
| 36 | 9065315 | SPRING |
| 37 | 444692 | PLUG |
| 38 | 15258051 | SEAL-D RING |
| 39 | 15258038 | SEAL-D RING |
| 40 | 15307381 | PISTON HOUSING ASSY |
| 41 | 15303368 | STUD |
| 42 | 15249911 | DUST CAP |
| 43 | 15303609 | GUIDE RING-PISTON |
| 44 | 15303611 | GUIDE RING-ROD |
| 45 | 15303610 | SEAL ASSY-ROD |
| 46 | 15256201 | DISC DRIVER |
| 47 | 9113457 | LOCK WIRE |
| 48 | 15247046 | HOUSING-SEAL |
| 49 | 15302759 | O RING |
| 50 | 9419497 | NUT-NYLON INSERT |
| 51 | 15247216 | SEAL ASSY |
| 52 | 15247433 | O RING |
| 53 | 15231422 | WASHER |
| FRONT RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15250974 | FRONT RIDE CYL ASSEM |
| 2 | 9384099 | CAP-END |
| 3 | 9411010 | FITTING-GREASE |
| 4 | 9013688 | VALVE-CHECK |
| 5 | 444613 | PLUG |
| 6 | 15016161 | O RING |
| 7 | 9069472 | RING-BACKUP |
| 8 | 9069476 | TUBE |
| 9 | 9269710 | BOLT |
| 10 | 9069475 | PISTON |
| 11 | 9069468 | RING-PISTON |
| 12 | 15250973 | ROD-PISTON |
| 13 | 169162 | BALL |
| 14 | 15233291 | SEAL |
| 15 | 9222091 | O RING |
| 16 | 223457 | BOLT |
| 17 | 9355771 | NUT |
| 18 | 9383858 | TUBE ASSY |
| 19 | 15250986 | RING-WEAR |
| 20 | 6525035 | VALVE ASSY-RECHARGE |
| 21 | 9030336 | RING-LARGE |
| 22 | 9034883 | CORE |
| 23 | 9069467 | SEAL |
| 24 | 9069466 | WIPER |
| 25 | 9068666 | WASHER-HARDENED |
| 26 | 106671 | FITTING-RELIEF |
| 27 | 9069958 | COVER |
| 28 | 271617 | BOLT |
| 29 | 9250715 | WASHER-HARDENED |
| 30 | 9019478 | KEY-SHEAR |
| 31 | 9423349 | BOLT HEX 1.25-7 UNC |
| 32 | 9259718 | WASHER-HARDENED |
| 33 | 15244531 | BOLT |
| REAR RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9079698 | REAR CYL ASSY |
| 2 | 9079696 | ROD |
| 3 | 9010661 | BUSHING |
| 4 | 9010662 | RING-SNAP |
| 5 | 9411010 | FITTING-GREASE |
| 6 | 9068666 | WASHER-HARDENED |
| 7 | 9013688 | VALVE-CHECK |
| 8 | 444613 | PLUG |
| 9 | 169162 | BALL |
| 10 | 9016787 | WIPER |
| 11 | 15237500 | SEAL |
| 12 | 9423349 | BOLT HEX 1.25-7 UNC |
| 13 | 9016784 | RING-BACKUP |
| 14 | 9016783 | O RING |
| 15 | 9016788 | RING-WEAR |
| 16 | 9079697 | PISTON |
| 17 | 9269710 | BOLT |
| 18 | 6525035 | VALVE ASSY-RECHARGE |
| 19 | 9030336 | RING-LARGE |
| 20 | 9034883 | CORE |
| 21 | 9217321 | WASHER-HARDENED |
| 22 | 9411019 | NIPPLE-GREASE |
| 23 | 9384151 | BOOT ASSY |
| 24 | 9139825 | CLAMP |
| 25 | 179837 | BOLT |
| 26 | 179883 | BOLT |
| 27 | 9015397 | SPACER |
| 28 | 15000838 | PIN-RIDE CYLINDER |
| 29 | 15019238 | BOLT |
| 30 | 15000991 | WASHER-HARDENED |
| 31 | 273852 | LOCKNUT |
| 32 | 9015398 | PIN ASSEMBLY |
| 33 | 103329 | LOCK WASHER |
| CABLES/HARNESSES-CAB | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15259091 | HARNESS,DASH |
| 2 | 15259105 | HARNESS,CAB |
| 3 | 15302853 | HARNESS,CONSOLE |
| 4 | 15302870 | TIMER RELAY |
| BATTERY AND CABLES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15305862 | MAGNETIC SWT-START SOL |
| 2 | 15253875 | CLAMP-PIPE |
| 3 | 15302350 | CABLE ASSEMBLY |
| 4 | 15302353 | CABLE ASSEMBLY |
| 5 | 15256097 | CABLE ASSY |
| 6 | 15232468 | CABLE |
| 7 | 15302354 | CABLE ASSEMBLY |
| 8 | 15302355 | CABLE ASSEMBLY |
| 9 | 15256096 | CABLE ASSY |
| 10 | 15256094 | CABLE ASSY |
| 11 | 15258745 | COVER ASSEMBLY |
| 12 | 6350612 | SCREW |
| 13 | 102635 | NUT T50 |
| 14 | 103320 | LOCKWASHER |
| 15 | 179845 | BOLT |
| 16 | 7160630 | WASHER |
| 17 | 108580 | LOCKWASHER |
| 18 | 103319 | LOCKWASHER |
| 19 | 15304322 | CABLE ASSEMBLY |
| 20 | 15258443 | ISOLATOR RELAY |
| 21 | 15310266 | PLATE-MTG |
| 22 | 103340 | WASHER |
| 23 | 103320 | WASHER-LOCK |
| 24 | 179795 | BOLT |
| 25 | 103319 | WASHER |
