Terex earthmoving equipment parts
| REAR AXLE DIFFERENTIAL | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103393 | PIN-COTTER |
| 2 | 9227330 | NUT |
| 3 | 9233425 | YOKE ASSY |
| 4 | 9232899 | SLEEVE |
| 5 | 9219080 | GASKET |
| 6 | 15228172 | DIFFERENTIAL-3.15:1 |
| 7 | 9227257 | RETAINER |
| 8 | 15244338 | SEAL |
| 9 | 271560 | BOLT |
| 10 | 179841 | BOLT |
| 11 | 108580 | LOCK WASHER |
| 12 | 9227258 | CAGE |
| 13 | 9192605 | SHIM |
| 14 | 9192606 | SHIM 0.03 |
| 15 | 9192607 | SHIM 0.01 |
| 16 | 9226270 | CARRIER ASSY |
| 17 | 274199 | BOLT |
| 18 | 9192618 | DOWEL-BUSHING |
| 19 | 9113457 | LOCK WIRE |
| 20 | 9226262 | PIN |
| 21 | 9141911 | O RING |
| 22 | 9423356 | BEARING |
| 23 | 102615 | SCREW |
| 24 | 9228704 | GEAR SET |
| 25 | 7451617 | BEARING |
| 26 | 103331 | LOCK WASHER |
| 27 | 9063982 | WASHER |
| 28 | 9005259 | PINION |
| 29 | 219305 | PLUG-PIPE |
| 30 | 9005267 | SPIDER |
| 31 | 9247386 | GEAR |
| 32 | 9005581 | WASHER |
| 33 | 9394277 | CASE ASSY |
| 34 | 454754 | NUT |
| 35 | 9005582 | BOLT |
| 36 | 9192619 | ADJUSTER |
| 37 | 9219084 | PIN-DOWEL |
| 38 | 456470 | CONE-BEARING |
| 39 | 456471 | CUP-BEARING |
| 40 | 9419496 | NUT |
| 41 | 223771 | BOLT |
| 42 | 9170517 | BOLT |
| 43 | 9214341 | LOCK |
| 44 | 9114897 | SCREW |
| 45 | 139230 | SCREW |
| 46 | 15234244 | SEAL-CORD |
| 47 | 9419493 | LOCK NUT |
