Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
WhatsApp : 008618264966991
| 30 | 103329 | LOCKWASHER |
| 31 | 9015397 | SPACER |
| 32 | 15255431 | A-FRAME ASSEMBLY |
| 33 | 9419493 | NUT |
| 34 | 15017032 | SHAFT-AXLE |
| 35 | 9136639 | NIPPLE |
| 36 | 144033 | BUSHING |
| 37 | 116436 | CONNECTOR |
| 38 | 15249532 | HOSE ASSY |
| 39 | 9122167 | CONNECTOR |
| 40 | 9250715 | WASHER |
| PLANETARY GEARING-REAR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9113457 | LOCKWIRE |
| 2 | 15019509 | BOLT DRILL HEAD 0.50 |
| 3 | 9008525 | PLUG-MAGNETIC |
| 4 | 273469 | PLUG |
| 5 | 15009631 | CARRIER-PLANETARY |
| 6 | 15019510 | PINION-PLANETARY |
| 7 | 15233267 | RETAINER |
| 8 | 15232937 | PLATE-THRUST |
| 9 | 15233274 | RETAINER |
| 10 | 9074668 | SPACER |
| 11 | 15238327 | BEARING |
| 12 | 15238323 | SPACER-BEARING |
| 13 | 454910 | BOLT |
| 14 | 15233266 | PIN-PLANETARY |
| 15 | 15019502 | BOLT DRILL HEAD 0.38 |
| 16 | 9074670 | SPACER |
| 17 | 15238317 | PLANET PINION-FIRS |
| 18 | 15019484 | PINION-SUN |
| 19 | 15019492 | PLATE-RETAINER |
| 20 | 15236593 | CARRIER-PLANTRY M/CD |
| 21 | 15238322 | SPACER-THRUST |
| 22 | 15233271 | COVER-PLANTRY M/CD |
| 23 | 15019519 | WASHER-THRUST |
| 24 | 15238319 | SUN PINION-FIRST S |
| 25 | 15245290 | WASHER-THRUST |
| 26 | 9125576 | O RING-BULK |
| 27 | 15228596 | RING-GEAR |
| 28 | 15233268 | COVER CARRIER |
| 29 | 9430309 | BOLT |
| 30 | 9250715 | WASHER-HARDENED |
| 31 | 9141863 | O RING |
| 32 | 15233269 | RETAINER |
| 33 | 15019494 | RETAINER |
| 34 | 15019483 | RING-GEAR |
| 35 | 9413420 | RING-SNAP |
| 36 | 15019482 | CARRIER-RING GEAR |
| 37 | 9433576 | NUT |
| 38 | 15246062 | WASHER-THRUST |
| 39 | 15015363 | BEARING |
| 40 | 139230 | SCREW |
| WHEEL RIM AND TYPE-REAR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15021101 | PLATE |
| 2 | 9063017 | SHIM-PACK |
| 3 | 15233384 | CONE-BEARING |
| 4 | 9437224 | CONE-BEARING |
| 5 | 15233385 | CUP-BEARING |
| 6 | 15233302 | WHEEL |
| 7 | 9253468 | STUD |
| 8 | 9255689 | STUD |
| 9 | 9063025 | BOLT |
| 10 | 9113457 | LOCKWIRE |
| 11 | 9209490 | O RING |
| 12 | 15017037 | BASE |
| 13 | 9063834 | FLANGE |
| 14 | 9074982 | BAND-BEAD SEAT |
| 15 | 9074983 | LOCKRING |
| 16 | 15017033 | BAND SPACER |
| 17 | 273469 | PLUG |
| 18 | 15023746 | CLAMP |
| 19 | 9433576 | NUT |
| 20 | 9211054 | VALVE ASSY |
