| FRONT RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15250974 | FRONT RIDE CYL ASSEM |
| 2 | 9384099 | CAP-END |
| 3 | 9411010 | FITTING-GREASE |
| 4 | 9013688 | VALVE-CHECK |
| 5 | 444613 | PLUG |
| 6 | 15016161 | O RING |
| 7 | 9069472 | RING-BACKUP |
| 8 | 9069476 | TUBE |
| 9 | 9269710 | BOLT |
| 10 | 9069475 | PISTON |
| 11 | 9069468 | RING-PISTON |
| 12 | 15250973 | ROD-PISTON |
| 13 | 169162 | BALL |
| 14 | 15233291 | SEAL |
| 15 | 9222091 | O RING |
| 16 | 223457 | BOLT |
| 17 | 9355771 | NUT |
| 18 | 9383858 | TUBE ASSY |
| 19 | 15250986 | RING-WEAR |
| 20 | 6525035 | VALVE ASSY-RECHARGE |
| 21 | 9030336 | RING-LARGE |
| 22 | 9034883 | CORE |
| 23 | 9069467 | SEAL |
| 24 | 9069466 | WIPER |
| 25 | 9068666 | WASHER-HARDENED |
| 26 | 106671 | FITTING-RELIEF |
| 27 | 9069958 | COVER |
| 28 | 271617 | BOLT |
| 29 | 9250715 | WASHER-HARDENED |
| 30 | 9019478 | KEY-SHEAR |
| 31 | 9423349 | BOLT HEX 1.25-7 UNC |
| 32 | 9259718 | WASHER-HARDENED |
| 33 | 15244531 | BOLT |
| REAR RIDE CYLINDER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9079698 | REAR CYL ASSY |
| 2 | 9079696 | ROD |
| 3 | 9010661 | BUSHING |
| 4 | 9010662 | RING-SNAP |
| 5 | 9411010 | FITTING-GREASE |
| 6 | 9068666 | WASHER-HARDENED |
| 7 | 9013688 | VALVE-CHECK |
| 8 | 444613 | PLUG |
| 9 | 169162 | BALL |
| 10 | 9016787 | WIPER |
| 11 | 15237500 | SEAL |
| 12 | 9423349 | BOLT HEX 1.25-7 UNC |
| 13 | 9016784 | RING-BACKUP |
| 14 | 9016783 | O RING |
| 15 | 9016788 | RING-WEAR |
| 16 | 9079697 | PISTON |
| 17 | 9269710 | BOLT |
| 18 | 6525035 | VALVE ASSY-RECHARGE |
| 19 | 9030336 | RING-LARGE |
| 20 | 9034883 | CORE |
| 21 | 9217321 | WASHER-HARDENED |
| 22 | 9411019 | NIPPLE-GREASE |
| 23 | 9384151 | BOOT ASSY |
| 24 | 9139825 | CLAMP |
| 25 | 179837 | BOLT |
| 26 | 179883 | BOLT |
| 27 | 9015397 | SPACER |
| 28 | 15000838 | PIN-RIDE CYLINDER |
| 29 | 15019238 | BOLT |
| 30 | 15000991 | WASHER-HARDENED |
| 31 | 273852 | LOCKNUT |
| 32 | 9015398 | PIN ASSEMBLY |
| 33 | 103329 | LOCK WASHER |
| CABLES/HARNESSES-CAB | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15259091 | HARNESS,DASH |
| 2 | 15259105 | HARNESS,CAB |
| 3 | 15302853 | HARNESS,CONSOLE |
| 4 | 15302870 | TIMER RELAY |
| BATTERY AND CABLES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15305862 | MAGNETIC SWT-START SOL |
| 2 | 15253875 | CLAMP-PIPE |
| 3 | 15302350 | CABLE ASSEMBLY |
| 4 | 15302353 | CABLE ASSEMBLY |
| 5 | 15256097 | CABLE ASSY |
| 6 | 15232468 | CABLE |
| 7 | 15302354 | CABLE ASSEMBLY |
| 8 | 15302355 | CABLE ASSEMBLY |
| 9 | 15256096 | CABLE ASSY |
| 10 | 15256094 | CABLE ASSY |
| 11 | 15258745 | COVER ASSEMBLY |
| 12 | 6350612 | SCREW |
| 13 | 102635 | NUT T50 |
| 14 | 103320 | LOCKWASHER |
