Terex earthmoving equipment parts
| 2 | 15268373 | KIT-SEAL |
| 3 | 15268375 | KIT-SPOOL/SLEEVE |
| RETARDER CONTROL VALVE-BRAKES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15259155 | VALVE |
| 2 | 15268417 | KIT-SEAL |
| BRAKE DUMP VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15256706 | VALVE-DIRECTN CONTL |
| FILTER ASSEMBLY-DISC BRAKE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9066150 | FILTER ASSY |
| 2 | 9055364 | SEAL-CUP |
| 3 | 9066151 | ELEMENT |
| 4 | 444631 | PLUG(0.50") |
| CAB ASSEMBLY | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272038 | WINDSCREEN |
| 2 | 15272039 | GLASS-SIDE LH |
| 3 | 15272040 | GLASS-SIDE RH |
| 4 | 15272041 | COVER-LH |
| 5 | 15272043 | GLASS-REAR |
| 6 | 15272044 | WIPER MOTOR |
| 7 | 15272046 | LINKAGE |
| 8 | 15272047 | WIPER ARM |
| 9 | 15272048 | WIPER BLADE |
| 10 | 15272049 | GROMMET |
| 11 | 9379264 | TIE-CABLE |
| 12 | 15270781 | BOLT |
| 13 | 15250390 | LIGHT-CAB INTERIOR |
| 14 | 15265564 | 24V/5W BULB |
| 15 | 15272058 | SUN VISOR |
| 16 | 15272065 | DASHBOARD |
| 17 | 15270890 | AIR DIFFUSER |
| 18 | 15270896 | PLASTIC HOSE-BULK |
| 19 | 15270794 | FILTER-AIR |
| 20 | 15270796 | SUPPORT-FILTER |
| 21 | 15272067 | HOSE BULK-PLASTIC |
| 22 | 15272068 | RING-PLASTIC |
| 23 | 15272069 | STRIKER |
| 24 | 15272070 | SCREW |
| 25 | 15271185 | WASHER |
| 26 | 15272085 | BUTTON |
| 27 | 15270845 | SCREW |
| 28 | 7150815 | LOCKWASHER |
| 29 | 6430801 | NUT |
| CAB CENTRE CONSOLE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6441020 | BOLT |
| 2 | 15272074 | COVER |
| 3 | 15272076 | ROD |
| 4 | 15272077 | CLIP |
| 5 | 15270896 | HOSE-BULK PLASTIC |
| 6 | 15275135 | SPACER-PLASTIC |
| 7 | 15256924 | SCREW |
| 8 | 7150815 | WASHER |
| 9 | 6350825 | BOLT |
| 10 | 7150615 | LOCKWASHER |
| CAB MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15311433 | MOUNT-ENG ISOLATION |
| 2 | 454414 | BOLT |
| 3 | 9419493 | LOCKNUT |
| 4 | 15250143 | WASHER-HARDENED |
| 5 | 7160830 | LOCKWASHER |
| 6 | 15300236 | FLOORMAT |
| 7 | 15303081 | MIRROR ARM |
| 8 | 9077400 | MIRROR |
| CAB DOOR-LEFT HAND | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272275 | DOOR ASSY-LH |
| 2 | 15272099 | SEAL-BULK |
| 3 | 15272280 | DOOR LOCK-LH |
| 4 | 15272105 | ADDITIVE-LOCK |
| 5 | 15270751 | HANDLE-DOOR |
| 6 | 15272102 | SCREW |
| 7 | 15272871 | ARM-SLIDING |
| 8 | 15272285 | CABLE |
| 9 | 9379264 | TIE-CABLE |
| 10 | 15272289 | SWITCH-SUPPORT |
| 11 | 15272141 | SWITCH-WINDOW LH |
| 12 | 15272271 | HINGE |
| 13 | 15272113 | WASHER |
| 14 | 15272114 | NUT-SAFETY |
| 15 | 15272115 | CAP-NUT |
| 16 | 15272272 | PIN |
| 17 | 15272273 | PIN-SPLIT |
| 18 | 15272077 | CLIP |
| 19 | 15270752 | PIN |
| 20 | 15272873 | BUSH-THREADED |
| 21 | 15270781 | BOLT |
| CAB DOOR-RIGHT HAND | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272096 | DOOR ASSY-COMPLETE |
| 2 | 15272099 | SEAL-BULK |
| 3 | 15270751 | HANDLE-DOOR |
| 4 | 15272102 | SCREW |
| 5 | 15272104 | LOCK |
| 6 | 15272105 | ADDITIVE-LOCK |
| 7 | 15272271 | HINGE |
| 8 | 15272272 | PIN |
| 9 | 15272273 | SPLIT PIN |
| 10 | 15272274 | CLIP |
| 11 | 15272113 | WASHER |
| 12 | 15272114 | NUT-SAFETY |
| 13 | 15272115 | CAP-NUT |
| SWITCHES AND INSTRUMENTS | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15256433 | SPEEDOMETER |
| 2 | 15256026 | TACHOMETER |
| 3 | 15258289 | GAUGE ENG. 0IL PRESS |
| 4 | 15258291 | GAUGE ENG WATER TEMP E. |
| 5 | 15258288 | GAUGE TRANS OIL TEMP E. |
| 6 | 15300413 | GAUGE-FUEL LEVEL |
| 7 | 15300128 | GAUGE-TRANS OIL PRES |
| 8 | 15258795 | SWITCH-HAZARDS |
| 9 | 15258798 | SWITCH-LIGHTS |
| 10 | 15258796 | SWITCH-TEST |
| 11 | 15237165 | LENS-HAZARD LIGHTS |
| 12 | 15237163 | LENS-LIGHTS |
| 13 | 15265325 | BULB-SWITCHES |
| 14 | 15300563 | LENS；TRANSMISSION CHECK |
| 15 | 15237161 | SWITCH-COLUMN |
| 16 | 15300587 | MODULE,WARNING LIGHTS |
| 17 | 15271204 | BULB AND SOCKET-MODULE |
| 18 | 15300588 | MODULE,WARNING LIGHTS |
| 19 | 15300589 | MODULE,WARNING LIGHTS |
| 20 | 9079062 | DIODE-BLOCK |
| 21 | 15227360 | BUZZER |
| 22 | 15256444 | RELAY |
| 23 | 15244724 | FLASHER UNIT |
| 24 | 15247615 | FUSE-3 AMP |
| 25 | 15247614 | FUSE-5 AMP |
| 26 | 15247612 | FUSE-10 AMP |
| 27 | 15247611 | FUSE-15 AMP |
| 28 | 15248347 | FUSE-25 AMP |
| 29 | 15302871 | TIMER RELAY |
| 30 | 15300658 | SWITCH,-PUSH/TWIST |
| 31 | 15257770 | KEYSWITCH |
| 32 | 15271326 | KEY-IGNITION |
| 33 | 15301699 | SWITCH-PUSH/TWIST |
| 34 | 15258797 | SWITCH |
| 35 | 15301692 | LENS-RETARDER |
| 36 | 15229156 | LENS-TEST SWITCH |
| 37 | 15273771 | BULB-VDO GAUGES |
| 38 | 15256924 | SCREW |
| SEAT-DRIVER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15302059 | SEAT ASSY-HIGH BACK |
| 2 | 15269020 | KIT-HT RISER SPRING |
| 3 | 15503341 | KIT-DAMPER(NEW) |
| 4 | 15269028 | KIT-24V COMP/VALVE |
| 5 | 7161230 | LOCKWASHER |
| 6 | 6350830 | BOLT |
| 7 | 7150815 | WASHER |
| 8 | 7160830 | LOCKWASHER |
| 9 | 6430801 | NUT |
| SEAT-INSTRUCTOR | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6350825 | BOLT |
| 2 | 7160830 | LOCKWASHER |
| 3 | 6351020 | BOLT |
| 4 | 7161030 | LOCKWASHER |
| 5 | 103340 | WASHER |
| 6 | 274209 | LOCKNUT |
| 7 | 9068666 | WASHER-HARDENED |
| 8 | 120378 | NUT |
| 9 | 103329 | LOCKWASHER |
| AIR CONDITIONER/HEATER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15272300 | THERMOSTAT |
| 2 | 15272303 | EVAPORATOR MATRIX |
| 3 | 15271344 | O RING |
| 4 | 15271334 | O RING |
| 5 | 15270348 | VALVE-EXPANSION |
| 6 | 15271338 | O RING |
| 7 | 15272304 | ADAPTOR NO 6 |
| 8 | 15272305 | ADAPTOR NO 10 |
| 9 | 15270360 | CONDENSER |
| 10 | 15270374 | CLIP |
| 11 | 15270361 | RECEIVER |
| 12 | 15270363 | SWITCH-TRINERY |
| 13 | 15270358 | COMPRESSOR 134A |
| HEATER LINES AND WIRING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 109084 | NUT |
| 2 | 144034 | BUSHING |
| 3 | 179795 | BOLT |
| 4 | 454111 | ELBOW |
| 5 | 9379664 | CLAMP |
| 6 | 7551826 | HOSE-BULK |
| 7 | 9014950 | CONNECTOR |
| 8 | 15230961 | VALVE-BALL SHUT OFF |
| 9 | 9181284 | CLIP |
| 10 | 102635 | NUT |
| 11 | 9136387 | NIPPLE |
| 12 | 9131874 | CLAMP |
| 13 | 15001405 | CLAMP |
| 14 | 108580 | WASHER |
| 15 | 179839 | BOLT |
| AIR CONDITIONER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15271338 | O RING |
| 2 | 15271334 | O RING |
| 3 | 15271349 | HOSE ASSY |
| 4 | 15271351 | HOSE ASSY |
| 5 | 15271350 | HOSE ASSY |
| 6 | 15270352 | HOSE ASSY |
| 7 | 15271344 | O RING |
| 8 | 15271352 | GUARD-BELT |
| 9 | 15271353 | BELT-DRIVE |
| 10 | 15270369 | BRACKET |
| 11 | 179795 | BOLT |
| 12 | 103319 | LOCKWASHER |
| 13 | 109084 | NUT |
| 14 | 103320 | LOCKWASHER |
| 15 | 15245671 | BRACKET-CONDENSER |
| 16 | 15270360 | CONDENSER |
| 17 | 15270374 | CLIP |
| 18 | 15270361 | RECEIVER |
| 19 | 15270363 | SWITCH-TRINERY |
| 20 | 15270358 | COMPRESSOR-134A |
| 21 | 9152893 | P CLIP |
| 22 | 9131865 | P CLIP |
| 23 | 179795 | BOLT |
| 24 | 109084 | NUT |
| WINDSCREEN WASHER | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15256431 | KIT-WASHER BOTTLE |
| 2 | 15271481 | PUMP-24V |
| 3 | 15271482 | RING SEAL |
| 4 | 15271804 | CAP WASHER BOTTLE |
| 5 | 15301565 | BRACKET ASSEMBLY |
| 6 | 179839 | BOLT |
| 7 | 9060202 | WASHER-HARDENED |
| 8 | 6350825 | BOLT |
| 9 | 103340 | WASHER |
| 10 | 103320 | WASHER |
| DECALS-ENGLISH | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9270762 | DECAL-RETARDER |
| 2 | 9270768 | DECAL-HYD CONTROL |
| 3 | 9270769 | DECAL-HYDRAULIC OIL |
| 4 | 9361787 | DECAL-BATTERY EARTH |
| 5 | 15245918 | DECAL-HYDRAULIC OIL |
| 6 | 15301024 | DECAL-BODY SUPPORT |
| 7 | 15301857 | DECAL-PRESSURE TEST |
| 8 | 15301858 | DECAL-PRESSURE TEST |
| 9 | 15301859 | DECAL-PRESSURE TEST |
| LUBRICATION SYSTEM | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15022287 | HOSE |
| 2 | 15022880 | HOSE |
| 3 | 15244891 | HOSE ASSY |
| 4 | 127887 | ELBOW |
| 5 | 443977 | NIPPLE |
| 6 | 118748 | CONNECTOR |
| 7 | 179837 | BOLT |
| 8 | 108580 | LOCKWASHER |
| 9 | 444688 | PLUG |
| 10 | 9411010 | FITTING-GREASE |
