| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
Skype:nancy-1986.527
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| 2 | 6771005 | RING |
| 3 | 6758543 | PLUG |
| 4 | 6838520 | SPRING |
| 5 | 6770023 | VALVE |
| 6 | 29525044 | PLUG ASSY |
| 7 | 23045876 | GASKET |
| 8 | 23019734 | SOLENOID-12V |
| 9 | 103339 | WASHER |
| 10 | 454815 | BOLT |
| 11 | 23045794 | HARNESS |
| 12 | 23046474 | CONNECTOR-RECEPTACLE |
| 13 | 12059716 | CONNECTOR-BODY |
| 14 | 12052410 | TERMINAL |
| RETARDER GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23019730 | SEAL |
| 2 | 23019649 | SEAL |
| 3 | 6774290 | SEAL |
| 4 | 23019729 | SEAL |
| 5 | 103323 | WASHER |
| 6 | 23014166 | HUB |
| 7 | 179883 | BOLT |
| 8 | 179885 | BOLT |
| 9 | 6779451 | GASKET |
| RETARDER CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 433114 | BOLT |
| 2 | 103321 | LOCK WASHER |
| 3 | 6758381 | GASKET |
| 4 | 29525030 | BODY-RETARDER C/VALVE |
| 5 | 23018483 | VALVE |
| 6 | 6758380 | GASKET |
| 7 | 179839 | BOLT |
| SPLITTER GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23011150 | RING-SNAP |
| 2 | 23019650 | SEAL |
| 3 | 29533089 | HUB |
| 4 | 6832481 | KIT-SEAL |
| 5 | 6770623 | SEAL |
| 6 | 6777908 | PISTON-SPLITTER LOW |
| 7 | 6756042 | SPRING-RETURN |
| 8 | 23041616 | PLATE-INTER SPLINTED |
| 9 | 6776610 | PLATE-REACTION |
| 10 | 23048003 | BEARING |
| 11 | 6772143 | GEAR |
| 12 | 6779801 | CARRIER ASSY |
| 13 | 23015601 | WASHER |
| 14 | 6771316 | PINION-SET |
| 15 | 6884835 | BEARING |
| 16 | 6839418 | SPINDLE |
| 17 | 6758367 | HUB |
| 18 | 6759340 | ANCHOR |
| 19 | 6835742 | SPRING |
| 20 | 23017739 | GUIDE |
| 21 | 6832482 | SEAL |
| 22 | 6832483 | SEAL |
| 23 | 6771690 | KEY |
| MAIN HOUSING GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 444335 | REDUCER |
| 2 | 103323 | WASHER |
| 3 | 179887 | BOLT |
| 4 | 179837 | BOLT |
| 5 | 9414052 | BOLT |
| 6 | 23041458 | BEARING |
| 7 | 6759381 | JUMPER-TUBE |
| 8 | 103325 | WASHER SPRING LOCK |
| 9 | 271560 | BOLT |
| 10 | 6758437 | GASKET |
| 11 | 103319 | LOCK WASHER |
| 12 | 179838 | BOLT |
| 13 | 103321 | LOCK WASHER |
| 14 | 9418964 | BOLT |
| 15 | 187152 | BOLT |
| HIGH RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23019650 | SEAL |
| 2 | 6770623 | SEAL |
| 3 | 6832481 | KIT-SEAL |
| 4 | 6775840 | PISTON |
| 5 | 6756042 | SPRING-RETURN |
| 6 | 23041616 | PLATE-INTER SPLINTED |
| 7 | 6769326 | PLATE-EXTER SPLINTED |
| 8 | 6770848 | PLATE-BACKING |
| INTER RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6758397 | GEAR-INTER RANGE SUN |
| 2 | 6759377 | SPINDLE |
| 3 | 23015601 | WASHER |
| 4 | 6884835 | BEARING |
| 5 | 6771316 | PINION-SET |
| 6 | 23041530 | BEARING |
| 7 | 6769289 | SEAL |
| 8 | 23016615 | BOLT |
| 9 | 23041616 | PLATE-INTER SPLINTED |
| 10 | 6769326 | PLATE-EXTER SPLINTED |
| 11 | 6832484 | SEAL |
| 12 | 6831033 | PISTON |
| 13 | 6832485 | SEAL |
| LOW RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6831151 | SHAFT-SPLITTER |
| 2 | 23047981 | BEARING |
| 3 | 23041007 | WASHER |
| 4 | 23011176 | BEARING |
| 5 | 6832007 | PINION SET |
| 6 | 6758540 | SPINDLE |
| 7 | 9369203 | WASHER |
| 8 | 6768478 | KEY |
| 9 | 23041616 | PLATE-INTER SPLINTED |
| 10 | 6769326 | PLATE-EXTER SPLINTED |
| 11 | 6832484 | SEAL |
| 12 | 6832486 | SEAL |
| REV RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23016615 | BOLT |
| 2 | 6775717 | CARRIER |
| 3 | 6768499 | WASHER |
| 4 | 6769261 | SPACER |
| 5 | 6776022 | PINION SET |
| 6 | 6756275 | ROLLER |
| 7 | 6832487 | SEAL |
| 8 | 23041147 | BEARING |
| 9 | 23041616 | PLATE-INTER SPLINTED |
| 10 | 6769326 | PLATE-EXTER SPLINTED |
| 11 | 6832484 | SEAL |
