| 12 | 15269002 | GASKET-CENTRE TANK |
| 13 | 15268691 | WASHER |
| 14 | 15268991 | WASHER |
| 15 | 15269004 | PLATE-CENTRE TUBE |
| 16 | 15268676 | FERRULE-RUBBER |
| 17 | 15268675 | FERRULE-BRASS |
| 18 | 15275433 | TUBE-JOULE |
| 19 | 15268963 | WASHER |
| 20 | 15268964 | LOCKWASHER |
| 21 | 15268689 | LOCKWASHER |
| 22 | 15268682 | WASHER |
| 23 | 15268688 | SCREW |
| 24 | 15269007 | SCREW |
| 25 | 15269008 | SCREW |
| 26 | 15268693 | SCREW |
| 27 | 15268690 | NUT |
| 28 | 15268681 | NUT |
| 29 | 15268685 | LOCKNUT |
| 30 | 15268686 | NUT |
| 31 | 15268997 | SET-STIFFENER BARS |
| RADIATOR MOUNTING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 103332 | LOCKWASHER |
| 2 | 106263 | WASHER |
| 3 | 179839 | BOLT |
| 4 | 179841 | BOLT |
| 5 | 179843 | BOLT |
| 6 | 223464 | BOLT |
| 7 | 274141 | NUT |
| 8 | 444625 | PLUG(0.38 IN) |
| 9 | 444679 | PLUG |
| 10 | 9139927 | WASHER |
| 11 | 9182221 | MOUNT-FLEXIBLE |
| 12 | 9186377 | MOUNT-FLEXIBLE |
| 13 | 9187694 | WASHER |
| 14 | 15254781 | PLATE-ANTIRECIRC`N |
| 15 | 274208 | LOCKNUT |
| 16 | 9419493 | LOCKNUT |
| 17 | 15238144 | RING-SHROUD |
| 18 | 15238145 | SCREEN LH |
| 19 | 15238146 | SCREEN RH |
| 20 | 15247519 | ROD-RADIATOR |
| 21 | 15254459 | SHROUD ASSY |
| 22 | 103341 | WASHER |
| 23 | 179833 | BOLT |
| 24 | 15256620 | PLATE-ANTIRECIRC`N |
| RADIATOR PIPING | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 9214526 | CLAMP |
| 2 | 9257169 | TIE-CABLE |
| 3 | 15304383 | SILICONE HOSE |
| 4 | 9267949 | WASHER |
| 5 | 179887 | BOLT |
| 6 | 103339 | WASHER |
| 7 | 103319 | LOCKWASHER |
| 8 | 15323236 | CLAMP |
| RADIATOR HEADER TANK AND HOSES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 15254778 | REMOTE HEADER TANK |
| 2 | 15230178 | NUT-WINDOW |
| 3 | 15255877 | HOSE ASSY |
| 4 | 15255879 | HOSE ASSY |
| 5 | 15255880 | HOSE ASSY |
| 6 | 9228659 | HOSE-BULK |
| 7 | 9402826 | ELBOW |
| 8 | 9402708 | CONNECTOR |
| 9 | 9152893 | CLIP |
| 10 | 179837 | BOLT |
| 11 | 179838 | BOLT |
| 12 | 179883 | BOLT |
| 13 | 102635 | NUT |
| 14 | 444698 | PLUG |
| 15 | 103319 | LOCKWASHER |
| 16 | 108580 | LOCKWASHER |
| 17 | 109084 | NUT |
| 18 | 9267949 | WASHER-HARDENED |
| 19 | 9066282 | CAP |
| 20 | 9024628 | GASKET |
| 21 | 15236152 | SWITCH-LEVEL FLOAT |
| 22 | 9030744 | TUBING |
| 23 | 179839 | BOLT |
