Terex earthmoving equipment parts
| TRANSMISSION RETARDER CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6758381 | GASKET |
| 2 | 103321 | LOCK WASHER |
| 3 | 433114 | BOLT |
| 4 | 6833409 | KIT-SEAL |
| 5 | 6758381 | GASKET |
| 6 | 179839 | BOLT |
| 7 | 6758380 | GASKET |
| TRANSMISSION SPLITTER GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23019650 | SEAL |
| 2 | 6770623 | SEAL |
| 3 | 6832481 | KIT-SEAL |
| 4 | 6775840 | PISTON |
| 5 | 6756042 | SPRING-RETURN |
| 6 | 23041616 | PLATE-INTER SPLINED |
| 7 | 6769326 | PLATE-EXTER SPLINED |
| 8 | 6770848 | PLATE-BACKING |
| 9 | 23048003 | BEARING |
| 10 | 23017460 | GEAR ASSY |
| 11 | 23017459 | HUB |
| 12 | 6772143 | GEAR |
| 13 | 6779801 | CARRIER ASSY |
| 14 | 6758581 | SPINDLE |
| 15 | 23015601 | WASHER |
| 16 | 6771316 | PINION-SET |
| 17 | 6884835 | BEARING |
| 18 | 6758340 | GEAR-SPLITTER HIGH |
| 19 | 6758367 | HUB |
| 20 | 6832869 | PLATE |
| 21 | 6759340 | ANCHOR |
| 22 | 6835742 | SPRING |
| 23 | 23017739 | GUIDE |
| 24 | 6832482 | SEAL |
| 25 | 6832483 | SEAL |
| 26 | 6771690 | KEY |
| TRANSMISSION MAIN HOUSING GROUP | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 444029 | REDUCER |
| 2 | 7964576 | BREATHER |
| 3 | 179837 | BOLT |
| 4 | 9414052 | BOLT |
| 5 | 103329 | LOCK WASHER |
| 6 | 23041458 | BEARING |
| 7 | 187152 | BOLT |
| 8 | 103323 | WASHER |
| 9 | 179887 | BOLT |
| 10 | 6759381 | JUMPER-TUBE |
| 11 | 271560 | BOLT |
| 12 | 103325 | WASHER SPRING LOCK |
| 13 | 6758437 | GASKET |
| 14 | 6882702 | GASKET |
| 15 | 179838 | BOLT |
| 16 | 103321 | LOCK WASHER |
| 17 | 9418964 | BOLT |
| TRANSMISSION CONTROL VALVE | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6777974 | GASKET |
| 2 | 6835409 | PLATE-OIL TRANSFER |
| 3 | 6830003 | WASHER |
| 4 | 23018739 | BOLT |
| 5 | 9409030 | BOLT |
| 6 | 6839632 | GASKET |
| 7 | 6839633 | GASKET |
| 8 | 9427847 | BOLT |
| 9 | 9433579 | BOLT |
| 10 | 23045756 | HARNESS ASSY |
| 11 | 12052410 | TERMINAL |
| 12 | 12059716 | CONNECTOR-BODY |
| 13 | 103339 | WASHER |
| 14 | 454813 | BOLT |
| 15 | 23019734 | SOLENOID-12V |
| 16 | 23046848 | SEAL |
| 17 | 6833223 | SPRING-OUTER |
| 18 | 6830243 | SPRING-INNER |
| 19 | 6880172 | VALVE |
| 20 | 6880187 | BALL-CHECK |
| 21 | 6759964 | SPRING |
| 22 | 6830014 | SPRING |
| 23 | 6839279 | SPRING-INNER |
| 24 | 6830240 | SPRING-INNER |
| 25 | 6830237 | SPRING-INNER |
| 26 | 6779835 | GASKET |
| 27 | 103321 | LOCK WASHER |
| 28 | 433114 | BOLT |
| 29 | 9418964 | BOLT |
| 30 | 186284 | BOLT |
| 31 | 179851 | BOLT |
| TRANS. HIGH RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 23019650 | SEAL |
| 2 | 6770623 | SEAL |
| 3 | 6832481 | KIT-SEAL |
| 4 | 6775840 | PISTON |
| 5 | 6756042 | SPRING-RETURN |
| 6 | 23041616 | PLATE-INTER SPLINTED |
| 7 | 6769326 | PLATE-EXTER SPLINTED |
| 8 | 6770848 | PLATE-BACKING |
| TRANS. INTER RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6758397 | GEAR-INTER RANGE SUN |
| 2 | 6759377 | SPINDLE |
| 3 | 23015601 | WASHER |
| 4 | 6884835 | BEARING |
| 5 | 6771316 | PINION-SET |
| 6 | 23041530 | BEARING |
| 7 | 6769289 | SEAL |
| 8 | 23016615 | BOLT |
| 9 | 6759340 | ANCHOR |
| 10 | 23041616 | PLATE-INTER SPLINTED |
| 11 | 6769326 | PLATE-EXTER SPLINTED |
| 12 | 6832484 | SEAL |
| 13 | 6832486 | SEAL |
| TRANS. LOW RANGE GEARING AND CLUTCHES | ||
| ITEM | PART NO. | DESCRIPTION |
| 1 | 6831151 | SHAFT-SPLITTER |
| 2 | 23047981 | BEARING |
| 3 | 23041007 | WASHER |
| 4 | 23011176 | BEARING |
| 5 | 6832007 | PINION SET |
| 6 | 6758540 | SPINDLE |
| 7 | 9369203 | WASHER |
| 8 | 6768478 | KEY |
| 9 | 23041616 | PLATE-INTER SPLINTED |
| 10 | 6769326 | PLATE-EXTER SPLINTED |
| 11 | 6832484 | SEAL |
| 12 | 6832486 | SEAL |
