| FRAME &UPRIGHTS | |||
| Item | Part No | Description | Qty |
| 1 | FRAME,MAIN(1) | 1 | |
| 2 | UPRIGHT-RH(1) | 1 | |
| 3 | UPRIGHT-LH(1) | 1 | |
| 4 | VN9188 | CAPSCREW-5/8"-11NCX61/2" | 8 |
| 5 | C1525 | NUT-5/8"-11NC | 8 |
| 6 | ED6340 | SUPPORT,DECK-RH | 1 |
| 7 | TUBE,ROPS(1) | 1 | |
| 8 | ED6863 | PLATE,MOUNT-LEFT INNER | 1 |
| 9 | C1667 | CAPSCREW-1"-8NCX21/2" | 16 |
| 10 | WA0364 | FLAT WASHER-1" | 16 |
| 11 | MM0109 | CAPSCREW-M20×2.50×90 | 8 |
| 12 | MM0707 | FLAT WASHER-M20 | 8 |
| 13 | ED6335 | SUPPORT,DECK-LH | 1 |
| 14 | ED6857 | PLATE-RH | 1 |
| 15 | ED6856 | PLATE-LH | |
| 16 | ED6858 | BACKER | 4 |
| 17 | ED6862 | PLATE,MOUNT-LEFT OUTER | |
| 18 | EK9278 | SUPPORT | 1 |
| 19 | ED6872 | BACKER-LH | 2 |
| 20 | ED6873 | BACKER-RH | 2 |
| 21 | ED6859 | PLATE,MOUNT-RIGHT OUTER | 1 |
| 22 | ED6860 | PLATE,MOUNT-RIGHT INNER | 1 |
| NS | NOTE:NS=NOT SHOWN | ||
| NS | 58E-00-00400 | KIT,TOW BUMPER(2) | 1 |
| NS | NOTE:(1)ORDER FROM FACTORY. | ||
| NS | (2)OPTIONAL WELD-ON COMPONENT. | ||
