| DECK MUD FLAPS | |||
| Item | Part No | Description | Qty |
| 1 | TZ4998 | BAR | 1 |
| 2 | TZ1459 | BAR | 1 |
| 3 | C1603 | CAPSCREW-3/8"-16NCX11/4" | 8 |
| 4 | C0312 | LOCKWASHER -3/8" | 8 |
| 5 | XB6007 | FLAP,MUD | 1 |
| 6 | EL9271 | BRACKET | 1 |
| 7 | MM0047 | CAPSCREW-M10X1.50×30 | 18 |
| 8 | MM0471 | LOCKWASHER -M10 | 18 |
| 9 | XB6008 | FLAP,RUBBER | 1 |
| 10 | EL9273 | ANGLE,MOUNTING | 1 |
| 11 | EL9832 | FLAP,RUBBER | |
| 12 | EL9833 | RETAINER | 1 |
| 13 | MM0067 | CAPSCREW-M10X1.50×50 | 7 |
| 14 | MM0461 | FLAT WASHER -M10 | 14 |
| 15 | MM0693 | LOCKNUT-M10×1.50 | 7 |
| FRAME &DECK GROUP | |||
| LH LADDER &PLATFORM | |||
| Item | Part No | Description | Qty |
| 1 | MM0620 | CAPSCREW-M12X1.75×40 | 4 |
| 2 | MM0714 | FLAT WASHER-M12 | 48 |
| 3 | MM0472 | LOCKWASHER-M12 | 4 |
| 4 | MM0694 | LOCKNUT-M12×1.75 | 18 |
| 5 | EM1480 | PLATE,BENT | 2 |
| 6 | MM0617 | CAPSCREW-M12×1.75×25 | 4 |
| 7 | TV1748 | CAPSCREW-5/8"-11NCX11/2" | 6 |
| 8 | WA4729 | FLAT WASHER-5/8" | 6 |
| 9 | MM0619 | CAPSCREW-M12×1.75X35 | 8 |
| 10 | MM0462 | FLAT WASHER-M12 | 4 |
| 11 | MM0179 | NUT-M12X1.75 | 2 |
| 12 | EM1221 | STEP,LH PLATFORM | 1 |
| 13 | XB1056 | PLATFORM,LH | 1 |
| 14 | EJ7292 | SHIM | 10 |
| 15 | XB3989 | LADDER | 1 |
| 16 | MM0624 | CAPSCREW-M12×1.75X70 | 8 |
| 17 | EL0828 | FLAT | 10 |
| 18 | MM0623 | CAPSCREW-M12×1.75×60 | 4 |
| 19 | MM0620 | CAPSCREW-M12×1.75×40 | 4 |
| 20 | EM1205 | STRAP,RUBBER | 2 |
| 21 | EL0827 | STEP | 2 |
| 22 | EM1204 | STRAP,RUBBER | 2 |
| 23 | MM0028 | CAPSCREW-M14×2.00×35 | 4 |
| 24 | MM0463 | FLAT WASHER-M14 | 4 |
| 25 | MM0473 | LOCKWASHER-M14 | 4 |
| 26 | EM9230 | COVER | 1 |
| 27 | MM0606 | CAPSCREW-M10×1.50×30 | 4 |
| 28 | MM0471 | LOCKWASHER-M10 | 4 |
| 29 | MM0461 | FLAT WASHER-M10 | 4 |
| FRAME&DECK GROUP | |||
| ENGINE ACCESS LADDERS | |||
| Item | Part No | Description | Qty |
| 1 | EM4955 | HANDRAIL-LH | 1 |
| EM4961 | HANDRAIL-RH | 1 | |
| 2 | EM4699 | HANDRAIL-LH | 1 |
| XB4880 | HANDRAIL-RH | 1 | |
| 3 | MM0619 | CAPSCREW-M12X1.75×35 | 16 |
| 4 | MM0462 | FLAT WASHER-M12 | 32 |
| 5 | MM0694 | LOCKNUT-M12X1.75 | 16 |
| 6 | MM0012 | CAPSCREW-M16×2.00×25 | 12 |
| 7 | MM0706 | FLAT WASHER-M16 | 12 |
| 8 | EM1489 | SUPPORT,HANDRAIL | 1 |
| 9 | MM0620 | CAPSCREW-M12X1.75×40 | 8 |
| 10 | MM0714 | FLAT WASHER-M12 | 24 |
| 11 | MM0472 | LOCKWASHER-M12 | 12 |
| 12 | MM0179 | NUT-M12X1.75 | 12 |
| 13 | EM4957 | HANDRAIL-LH | 1 |
| EM4958 | HANDRAIL-RH | 1 | |
| 14 | XC2036 | LADDER,LH ENGINE ACCESS | |
| XC2037 | LADDER,RH ENGINE ACCESS | ||
| 15 | XC2038 | LADDER,LH ENGINE ACCESS | |
| XC2039 | LADDER,RH ENGINE ACCESS | 1 | |
| 16 | TV1748 | CAPSCREW-5/8"-11NCX11/2" | 2 |
| 17 | WA4863 | FLAT WASHER-5/8" | 4 |
| 18 | VN9952 | LOCKNUT-5/8"-11NC | 2 |
| 19 | MM0621 | CAPSCREW-M12X1.75×45 | 2 |
| (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) | |||
| FRAME &DECK GROUP | |||
| RH LADDER &PLATFORM | |||
| Item | Part No | Description | Qty |
| 1 | MM0619 | CAPSCREW-M12×1.75×35 | 12 |
| 2 | MM0462 | FLAT WASHER-M12 | 8 |
| 3 | MM0473 | LOCKWASHER-M14 | 8 |
| 4 | EM4689 | LADDER,RH | 1 |
| 5 | EJ7292 | SHIM | 12 |
| 6 | MM0179 | NUT-M12X1.75 | 2 |
| 7 | MM0714 | FLAT WASHER-M12 | 36 |
| 8 | MM0694 | LOCKNUT-M12X1.75 | 14 |
| 9 | EM1222 | STEP,RH PLATFORM | 1 |
| 10 | TV1748 | CAPSCREW-5/8"-11NC×11/2" | 6 |
| 11 | WA4729 | FLAT WASHER-5/8" | 6 |
| 12 | MM0624 | CAPSCREW-M12X1.75×70 | 4 |
| 13 | EL0828 | FLAT | 10 |
| 14 | MM0623 | CAPSCREW-M12X1.75×60 | 8 |
| 15 | MM0622 | CAPSCREW-M12X1.75×50 | 4 |
| 16 | EM1208 | STRAP,RUBBER | 2 |
| 17 | EL0827 | STEP | 2 |
| 18 | EM1207 | STRAP,RUBBER | 2 |
| 19 | EM9232 | PLATFORM,RH | 1 |
| 20 | MM0461 | FLAT WASHER-M10 | 4 |
| 21 | MM0028 | CAPSCREW-M14×2.00×35 | 4 |
| 22 | MM0463 | FLAT WASHER-M14 | 8 |
| 23 | EM9230 | COVER | 1 |
| 24 | MM0606 | CAPSCREW-M10×1.50×30 | 4 |
| 25 | MM0471 | LOCKWASHER-M10 | 4 |
| 26 | MM0023 | CAPSCREW-M14×2.00×30 | 4 |
| FRAME&DECK GROUP | |||
| LH PLATFORM TREAD PLATE INSTALLATION | |||
| Item | Part No | Description | Qty |
| 1 | XB1050 | PLATE,TREAD | 1 |
| 2 | MM0606 | CAPSCREW-M10×1.50×30 | 4 |
| 3 | MM0713 | FLAT WASHER-M10 | 6 |
| 4 | MM0471 | LOCKWASHER-M10 | 4 |
| 5 | MM0178 | NUT-M10×1.50 | 2 |
| FRAME&DECK GROUP | |||
| DIAGONAL LADDER INSTALLATION | |||
| Item | Part No | Description | Qty |
| 1 | XB9715 | LADDER,DIAGONAL | 1 |
| 2 | MM0619 | CAPSCREW-M12X1.75×35 | 8 |
| 3 | MM0462 | FLAT WASHER-M12 | 8 |
| 4 | EJ6571 | SHIM | 16 |
| 5 | MM0623 | CAPSCREW-M12X1.75×60 | 3 |
| 6 | DA0557 | WASHER | 6 |
| 7 | WA2587 | MOUNT RUBBER | 3 |
| 8 | MM0620 | CAPSCREW-M12X1.75×40 | 3 |
| 9 | MM0694 | LOCKNUT-M12×1.75 | 6 |
| 10 | EJ7499 | WASHER | 6 |
| 11 | EM1350 | PLATE,MOUNTING | 1 |
| FIG. | REF. | ||
| NO. | PART NO. | QTY | DESCRIPTION |
| 146 | N430P3 | 6 | WASHER,HARDENED,3/8 IN |
| 147 | N402P9B13 | AR | WASHER,NO 10(NARROW) |
| 149 | N402P11B13 | 4 | WASHER,1/4 IN(NARROW) |
| 150 | N22P21014B13 | 6 | BOLT,HEX HD,1/4 IN-20,7/8 INLONG |
| 152 | 41A250668P71 | 10 | WASHER,0.406ID |
| 153 | N22P29016B13 | 10 | BOLT,HEX HD,1/2 IN-13,1 INLONG |
| 154 | 41A279870P28 | 2 | STUD,3/8 IN-16,23/4 INLONG |
