| RADIATOR INSTALLATION RADIATOR &SHROUD ASSEMBLY PC2616 |
||||
| Item | Part No | Description | Qty | Ref |
| 1 | XA3514 | RADIATOR,JACKET WATER(HTC)(SEE FIG41814) | 1 | 41814 |
| 2 | XA3515 | RADIATOR.AFTERCOOLER(LTC)(SEE FIG41814) | 1 | 41814 |
| 3 | BF5349 | TANK,SURGE | 1 | |
| 4 | XA4888 | SHROUDFAN | 1 | |
| 5 | XA2832 | COOLER.FUEL(SEE FIG 41833) | 1 | 41833 |
| 6 | XA3516 | RING,FAN | 1 | |
| 7 | (NOT USED IN THISAPPLICATION) | |||
| 8 | C1614 | CAPSCREW-1/2"-13NCX11/2" | 20 | |
| 9 | C1540 | LOCKWASHER-1/2" | 14 | |
| 10 | VE3460 | CAPSCREW,HEX HEAD(HEAVY-DUTY) | 6 | |
| 11 | C1602 | CAPSCREW-3/8”-16NC×1" | 43 | |
| 12 | C0312 | LOCKWASHER-3/8" | 26 | |
| 13 | C1521 | NUT-3/8”-16NC | 40 | |
| 14 | BF3625 | GAUGE,SIGHT | 1 | |
| 15 | XA3517 | HOSE,OVERFLOW | 1 | |
| 16 | VE1474 | CAP-14 PSI | 1 | |
| 17 | VE4441 | ELBOW | 2 | |
| 18 | BF4463 | ADAPTER | 3 | |
| 19 | BF4461 | ELBOW | 3 | |
| 20 | BF4460 | HOSE | 3 | |
| 21 | BF4462 | SWIVEL | 6 | |
| 22 | VE4440 | WASHER | 20 | |
| 23 | VE3461 | NUT,HEXHEAD | 14 | |
| 24 | VE1223 | CLIP | 9 | |
| 25 | E3735 | FLAT WASHER-5/16" | 52 | |
| 26 | VE8326 | BUSHING,REDUCER-HEX | 2 | |
| 27 | BF4464 | FITTING | 2 | |
| 28 | 58B-03-00190 | LOCKWASHER-3/8" | 5 | |
| COOLING SYSTEM | ||||
| RADIATOR INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | BF5349 | TANK,SURGE(INCLUDED IN RADIATOR ASSEMBLY) | 1 | |
| 2 | PC2616 | RADIATOR AND SHROUDASSEMBLY(SEE INDEX) | 1 | 43385 |
| 3 | E3909 | CAPSCREW-1"-8NC×31/4" | 2 | |
| 4 | VH8186 | LOCKNUT-1"-8NC | 4 | |
| 5 | C1532 | NUT,HEX | 10 | |
| 6 | PB6831 | END,ROD | 2 | |
| 7 | TY5096 | ROD,THREADED | 2 | |
| 8 | C1667 | CAPSCREW-1"-8NC×21/2" | 2 | |
| 9 | MM0038 | CAPSCREW-M16×2.00×35 | 8 | |
| 10 | MM0706 | FLAT WASHER-M16 | 8 | |
| 11 | 58E-80-20400 | SUPPORT,RADIATOR | 2 | |
| 12 | 58E-80-20300 | SUPPORT,RADIATOR(RH) | 1 | |
| 58E-80-20310 | SUPPORT,RADIATOR(LH) | 1 | ||
| 13 | ED9895 | FLAT WASHER | 8 | |
| 14 | PC0780 | MOUNT,RUBBER-TWO PIECE | 4 | |
| 15 | C1648 | CAPSCREW-3/4"-10NC×3" | 8 | |
| 16 | WA0362 | FLAT WASHER-3/4" | 8 | |
| 17 | C1542 | LOCKWASHER-3/4" | 8 | |
| 18 | C1527 | NUT-3/4"-10NC | 8 | |
