| Item | Part No | Description | Qty | Ref |
| 1 PC3159 WHEEL,MOTORIZED DRIVE (SEE INDEX) 2 43156 2 VN3270 CAPSCREW-11/4"-7NCX5"(1) 96 3 WA0366 FLATWASHER-11/4”(1) 96 NS AK9484 NOTE:(1)INCLUDED INAK9484 WHEEL MOTOR INSTALLATION KIT. |
||||
| Item | Part No | Description | Qty | |
| 1 | EC4617 | BAR,SWAY | 1 | |
| 2 | 58E-22-00130 | AXLE HOUSING ASSEMBLY | 1 | |
| 58E-22-00140 | AXLE HOUSING | 1 | ||
| 3 | TX8110 | SLEEVE(1) | 6 | |
| 4 | PB0027 | BEARING,SPHERICAL(1) | 2 | |
| 5 | VN9351 | RING,RETAINER(1) | 4 | |
| 6 | TY2734 | SPACER(1) | 4 | |
| 7 | VN9952 | LOCKNUT-5/8"-11NC(1) | 2 | |
| 8 | WA0361 | FLAT WASHER-5/8”(1) | 2 | |
| 9 | EK1326 | PIN,BEARING(1) | 2 | |
| 10 | EM8115 | SHOULDER BOLT-5/8"-11NCX7.41"(1) | 2 | |
| 11 | CE2510 | CAPSCREW-5/8"-11NCX3/4" | 2 | |
| 12 | C1541 | LOCKWASHER-5/8" | 1 | |
| NS | AK5665 | NOTE:(1)INCLUDED INAK5665 PIN KIT.(SERVICES ONE PIN) | ||
| Item | Part No | Description | Qty | |
| 1 | 58E-22-00130 | AXLE HOUSING ASSEMBLY | 1 | |
| 58E-22-00140 | AXLE HOUSING | 1 | ||
| TX8110 | SLEEVE | 6 | ||
| 2 | XB2447 | PIVOT EYEASSEMBLY | 1 | |
| XB2446 | EYE,PIVOT | 1 | ||
| 3 | WB1154 | CAPSCREW-3/4"-10NC×6"(12 PT)(1) | 8 | |
| 4 | TY1344 | RETAINER,BEARING(1) | 2 | |
| 5 | PC1291 | BEARING(1) | 1 | |
| 6 | EG3026 | CARRIER,BEARING(1) | 1 | |
| 7 | VL2993 | LOCKNUT-3/4"-10NC(1) | 8 | |
| 8 | EG3033 | PIN,PIVOT(1) | 1 | |
| 9 | EG3028 | SPACER(1) | 2 | |
| 10 | VN9106 | CAPSCREW-11/4"-7NC×3" | 24 | |
| 11 | WA0366 | FLAT WASHER-11/4" | 28 | |
| 12 | EG3027 | PLATE,LOCKING(1) | 1 | |
| 13 | C1633 | CAPSCREW-5/8"-11NCX23/4"(1) | 3 | |
| 14 | C1541 | LOCKWASHER-5/8"(1) | 3 | |
| 15 | WB1059 | CAPSCREW-11/4"-7NCX41/2"(12 PT)(1) | 4 | |
| 16 | MM0603 | CAPSCREW-M10×1.50×16 | 1 | |
| 17 | MM0471 | LOCKWASHER-M10 | 2 | |
| 18 | XB2497 | WIRE,GROUND | 1 | |
| 19 | MM0178 | NUT-M10×1.50 | 1 | |
| NS | AK4952 | NOTE:(1)INCLUDED IN AK4952 NOSE CONE PIN KIT. | ||
| Item | Part No | Description | Qty | |
| 1 | EL3572 | ARM,STEERING-LH | 1 | |
| EL3571 | ARM,STEERING-RH | 1 | ||
| 2 | WA4817 | CAPSCREW-11/4"-12NFX5"(12 PT) | 62 | |
| 3 | TY2228 | PLATE,RETAINER | 2 | |
| 4 | TY2149 | FLAT WASHER-11/4" | 24 | |
