| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| ELECTRIC POWER COMPONENTS &WIRING GROUP | ||||
| BLOWER PRESSURE SWITCH | ||||
| ltem | Part No | Description | Qty | |
| 1 | MM0178 | NUT-M10×1.50 | 2 | |
| 2 | MM0471 | LOCKWASHER-M10 | 2 | |
| 3 | MM0461 | FLAT WASHER-M10 | 2 | |
| 4 | 08193-20012 | CLIP | 1 | |
| 5 | WB3097 | CLAMP,CUSHION-1/2" | 2 | |
| 6 | MM0025 | CAPSCREW-M6×1.00×20 | 4 | |
| 7 | MM0469 | LOCKWASHER-M6 | 4 | |
| 8 | MM0717 | NUT-M6×1.00 | 4 | |
| 9 | EM1179 | BLOWER PRESSURE SWITCHASSEMBLY | ||
| 10 | EL9925 | HARNESS | 1 | |
| PB4673 | PRESSURE SWITCH,BLOWER | 1 | ||
| 11 | TA0603 | FITTING,NYLON | 2 | |
| 12 | TK7603 | TUBE,NYLON | 1 | |
| 13 | XB0591 | HARNESS,BLOWER PRESSURE SWITCH | 1 | |
| FUEL TANK | ||||
| Item | Part No | Description | Qty | |
| 0 | 58E-04-00061 | FUEL TANK ASSEMBLY | 1 | |
| 1 | D5576 | CAP,PIPE | 1 | |
| 2 | R2028 | PLUG,PIPE-3/4" | 1 | |
| 3 | WA3688 | BUSHING,PIPE-11/4"×1/4" | 1 | |
| 4 | HC1851 | DRAIN COCK | 1 | |
| 5 | HC4691 | PLUG,PIPE | 3 | |
| 6 | TA1691 | GASKET | 2 | |
| 7 | TA1683 | COVER | 2 | |
| 8 | TD0791 | CAPSCREW-3/8"-16NCX11/4" | 12 | |
| 9 | TC1231 | LOCKWASHER-3/8" | 12 | |
| FUEL TANK INSTALLATION | ||||
| Item | Part No | Description | Qty | Ref |
| 1 | 58E-04-00061 | FUEL TANK ASSEMBLY(SEE FIG 43531) | 1 | 43531 |
| 2 | C1669 | CAPSCREW-1"-8NCX31/2" | 4 | |
| 3 | WA4733 | FLAT WASHER-1" | 4 | |
| 4 | TY4907 | CAP | 2 | |
| 5 | PC0780 | MOUNT,RUBBER-TWO PIECE | 4 | |
| 6 | ED9895 | FLAT WASHER | 4 | |
| 7 | MM0708 | FLAT WASHER-M24 | 4 | |
| 8 | MM0476 | LOCKWASHER-M24 | 4 | |
| 9 | MM0163 | CAPSCREW-M24×3.00×160 | 4 | |
| ALTERNATOR WIRING 3/3 | ||||
| Item | Part No | Description | Qty | |
| 1 | CH4915 | CABLE(74D) | 1 | |
| 2 | CH4914 | CABLE(71J) | 1 | |
| 3 | TC1233 | NUT-3/8"-16NC | 2 | |
| 4 | TC1231 | LOCKWASHER-3/8" | 2 | |
| 5 | TR4436 | FLAT WASHER-3/8" | 2 | |
| 6 | WB1302 | CLAMP,CUSHION-5/16" | 2 | |
| 7 | MM0178 | NUT-M10×1.50 | 2 | |
| 8 | MM0471 | LOCKWASHER-M10 | 2 | |
| 9 | MM0461 | FLAT WASHER-M10 | 2 | |
| 10 | WB1303 | CLAMP,CUSHIONED-3/4" | 1 | |
| 11 | TY8375 | SPACER | 1 | |
| ALTERNATOR WIRING 2/3 | ||||
| ltem | Part No | Description | Qty | |
| 1 | EK4014 | THREADED STUD-M16×2.00X 305 | 1 | |
| 2 | MM0464 | FLAT WASHER-M16 | 3 | |
| 3 | MM0181 | NUT-M16×2.00 | 3 | |
| 4 | MM0474 | LOCKWASHER-M16 | 3 | |
| 5 | EC1090 | THREADED STUD-M16×2.00×184 | 2 | |
| 6 | EL3705 | BRACKET | 1 | |
| 7 | VC1387 | CAPSCREW-1/2"-13NCX1" | 2 | |
| 8 | TR5445 | LOCKWASHER-1/2" | 2 | |
| 9 | VC7836 | FLAT WASHER-1/2" | 2 | |
| 10 | XB1109 | CLAMP,UHMW | 4 | |
| 11 | VA0609 | SPACER | 2 | |
| 12 | ED8936 | CLEAT,CABLE | 6 | |
| 13 | TN2590 | SPACER,HOSE | 6 | |
| 14 | VN6187 | STUD-5/8"-11NC×5" | 1 | |
| 15 | TR9082 | FLAT WASHER-5/8" | ||
| 16 | VC1390 | LOCKWASHER-5/8" | ||
| 17 | TV1749 | NUT-5/8"-11NC | 1 | |
