| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| CONTROLGROUP | |||||
| ltem | Part No | Description | Qty | uom | Ref |
| 32 VE5016 CAPSCREW-5/16"-18NC×11/8"20 | |||||
| 33 VE4640 CAPSCREW-3/8"-16NCX11/2" 4 | |||||
| CONTROL GROUP | |||
| DIODE/HEAT SINK ASSEMBLY GE0558 | |||
| Item | Part No | Description | Qty |
| 1 | VE4327 | SINK,HEAT | 2 |
| 2 | VE5038 | BAR,SUPPORT | 1 |
| 3 | VE5037 | SHIELD,GLASTIC | 1 |
| 4 | VE5036 | GROMMET | 4 |
| 5 | VE5039 | TUBE | 2 |
| 6 | VE5035 | CLAMP | 1 |
| 7 | VE4328 | RING,MOLDED | 1 |
| 8 | XA2058 | DIODE | 1 |
| CONTACTOR ASSEMBLY-RP GE1843 | |||
| Item | Part No | Description | Qty |
| 1 | XA4237 | COIL-74 VDC | 1 |
| 2 | GE1836 | KIT,CONTACTOR TIP | 1 |
| 3 | GE1072 | ARC CHUTE | 1 |
| 4 | XA4239 | COIL-24 VDC | 1 |
| 5 | 58E-43-00220 | BRACKET,SUPPORT | 1 |
| 6 | 58E-43-00230 | INTERLOCK,MECHANICAL | 1 |
| 7 | 58E-43-00240 | LATCH SPRING,ARC CHUTE | 1 |
| 8 | 58E-43-00250 | LEVER | 1 |
| 9 | 58E-43-00260 | HOLDER,IRON | 1 |
| 10 | 58E-43-00270 | CAPSCREW,SOCKET HEAD-5/16"-18NC×11/2" | 1 |
| 11 | 58E-43-00280 | TERMINAL,PIVOT | 1 |
| 12 | 58E-43-00290 | SPRING,LEAF | 1 |
| 13 | 58E-43-00300 | CAPSCREW,SOCKET HEAD-5/16"-18NCX11/4" | 1 |
| 14 | 58E-43-00310 | PLATE,POLE | 2 |
| 15 | 58E-43-00330 | CORE,MAGNET | 1 |
| 16 | 58E-43-00340 | SHEET,INSULATING | 1 |
| 17 | 58E-43-00350 | SPACER,INSULATING | 1 |
| 18 | 58E-43-00360 | CAPSCREW-5/16"-18NCX41/2" | 1 |
| 19 | 58E-43-00370 | SCREW,FLATHEAD-3/8"-16NCX1" | 1 |
| 20 | 58E-43-00380 | LOCKWASHER,COUNTERSUNK | 1 |
| 21 | 58E-43-00390 | YOKE | 1 |
| ALTERNATOR/BLOWER ASSEMBLY 58E-06-03040 | |||
| Item | Part No | Description | Qty uom |
| 1 | GE0413 | COVER | 1 |
| 2 | TC1234 | CAPSCREW-3/8"-16NC×3/4" | 12 |
| 3 | VE4687 | LOCKWASHER-3/8" | 12 |
| 4 | XA5635 | PLATE,FRONT | 1 |
| 5 | VE4739 | CAPSCREW-3/8"-16NCX1" | 6 |
| 6 | VE4515 | FLAT WASHER-3/8" | 12 |
| 7 | GE0796 | LOCKNUT-3/8"-16NC | 6 |
| 8 | VS7026 | LATCH,COVER | 2 |
| 9 | GE1083 | COVER ASSEMBLY | 2 |
| 10 | GE1173 | GASKET | 2 |
| 11 | VJ2672 | CEMENT(1QUART) | ASREQUIRED |
| (SEE FOLLOWING PAGES FOR BALANCE OF | |||
| ALTERNATOR/BLOWER ASSEMBLY COMPONENT PARTS.) | |||
| ALTERNATOR GROUP | |||||||||
| ALTERNATOR-ENGINE MOUNTY₂ | |||||||||
| ltem | Part No | Description | Qty | uom Ref | |||||
| 1 | XA4446 | ADAPTER | 1 | ||||||
| 2 | VJ1073 | CAPSCREW-5/8"-18NFX21/4" | 15 | ||||||
| 3 | VE5184 | FLAT WASHER-5/8" | 21 | ||||||
| 4 | GE1167 | STATOR REWIND KIT(1) | 1 | ||||||
| 5 | VE1887 | STRAP,CONNECTION(1) | 1 | ||||||
| 6 | VE4342 | BRACKET,INSULATED(1) | 7 | ||||||
| 7 | XA3159 | STATOR ASSEMBLY(SEE INDEX) | 1 | 64196 | |||||
| 8 | 58E-06-03060 | ROTORASSEMBLY(SEE INDEX) | 一 二 |
64410 | |||||
| 9 | VJ2743 | ROLLPIN | 1 | ||||||
| 10 | XA3160 | STATOR FRAME&CORE ASSEMBLY(1) | 1 | ||||||
| 11 | VE2753 | BRACKET | 7 | ||||||
| 12 | VE4542 | CAPSCREW-1/2"-13NC×1"(1) | 28 | ||||||
| 13 | VE5185 | FLAT WASHER-1/2"(1) | 28 | ||||||
| 14 | GE0328 | CABLE ASSEMBLY(SPEED SENSOR) | 1 | ||||||
| 15 | XA4447 | HOUSING,INLET | 1 | ||||||
| 16 | VE4500 | CAPSCREW-3/8"-16NCX13/4" | 44 | ||||||
| 17 | VE3027 | FLAT WASHER-3/8" | 65 | ||||||
| 18 | TC1233 | NUT-3/8"-16NC | 21 | ||||||
| 19 | GE1081 | HOUSING,OUTLET | 1 | ||||||
| 20 | C1629 | CAPSCREW-5/8"-11NCX13/4" | 6 | ||||||
| 21 | VE4998 | CAPSCREW-1/2"-13NCX41/2" | 12 | ||||||
| 22 | VE5185 | FLAT WASHER-1/2" | 20 | ||||||
| 23 | GE1082 | IMPELLER | 1 | ||||||
| 24 | GE0141 | CAPSCREW-5/8"-11NCX21/4" | 6 | ||||||
| 25 | VE4631 | FLAT WASHER-5/8" | 6 | ||||||
| 26 | GE1172 | PLUG,PIPE-1" | 1 | ||||||
| VJ9656 | LIQUID GASKET | AS | REQUIRED | ||||||
| 27 | GE1079 | HEAD,FRAME | 1 | ||||||
| GE0790 | LUBRIPLATE | AS | REQUIRED | ||||||
| 28 | VG8030 | CAPSCREW-1/2"-13NCX11/2" | 8 | ||||||
| 29 | VE8444 | BRUSH,CARBON(2) | 6 | ||||||
| ALTERNATOR GROUP | |||||||||
| ALTERNATOR GROUP | ||||
| ALTERNATOR-ENGINE MOUNT 2/2 | ||||
| Item | Part No | Description | Qty | uom |
| 1 | VE0688 | PLATE,END(1) | 1 | |
| 2 | VS8253 | WEIGHT,BALANCE-101/2"OD. (1) | ASREQUIRED | |
| 3 | VJ1071 | WEIGHT,BALANCE-11/2"WIDE(1) | AS REQUIRED | |
| 4 | 58E-06-03070 | COIL,ROTOR(1) | 8 | |
| 5 | 58E-06-03080 | PACKING(1)(2) | 8 | |
| 6 | VE7006 | CORE,ROTOR(1) | 1 | |
| 7 | BF1480 | COLLECTOR RING ASSEMBLY(1) | 1 | |
| 8 | GE1823 | BEARING,BALL(1)(2) | ||
| 9 | GE1084 | SHAFT,ROTOR(1) | 1 | |
| 10 | XA4331 | FLINGER | ||
| 11 | GE1103 | HUB | 1 | |
| 12 | GE1155 | PICKUP,MAGNETIC(SPEED SENSOR)(2) | 1 | |
| 13 | XA4329 | HOUSING,BEARING(1) | 1 | |
| 14 | VE4248 | GASKET | 1 | |
| 15 | XA4330 | CAP,BEARING(1) | 1 | |
| 16 | GE1171 | CAPSCREW-5/8"-11NC×31/4" | 6 | |
| 17 | VE5184 | FLAT WASHER-5/8" | 6 | |
| 18 | XA5881 | SEAL(2) | 1 | |
| 19 | XA4332 | SLEEVE | 1 | |
| 20 | VE3620 | PIN,DOWEL | 2 | |
| 21 | GE1165 | HUB | 1 | |
| 22 | XA4511 | SEAL,V-RING(2) | 1 | |
| 23 | VE7209 | SEAL,V-RING(2) | 1 | |
| NS | NOTE:(1)INCLUDED IN ROTOR ASSEMBLY. | |||
| NS | AK9464 | (2)INCLUDED INAK9464 ALTERNATOROVERHAULKIT. | ||
| ALTERNATOR GROUP | ||||
| Item | Part No | Description Qty | uom | Ref |
| 30 | VJ1024 | HOLDER.BRUSH(SEE INDEX) 6 | 64030 | |
| NS | NOTE:(1)INCLUDEDIN STATOR ASSEMBLY. | |||
| NS | AK9464 | (2)INCLUDED INAK9464 ALTERNATOR OVERHAUL KIT. | ||
| NS | (SEE FOLLOWING PAGESFOR DETAILA AND VIEW B-B.) | |||
