| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| VJ2672 | CEMENT(1QUART) | AS REQUIRED | ||
| 7 | XA5827 | RESISTOR GRID | 3 | |
| 8 | XA4523 | RETARDER HOUSING WITH COVERS | 1 | |
| 9 | XA4160 | DIFFUSER ASSEMBLY | 2 | |
| GE0019 | GASKET | 1 | ||
| GE0020 | GASKET | 1 | ||
| VJ2672 | CEMENT(1 QUART) | AS REQUIRED | ||
| RETARDER GRID GROUP | ||||
| RETARDING GRID INSTALLATION 2/2 | ||||
| Item | Part No | Description | Qty | |
| 1 | EL3714 | MOUNT | 1 | |
| 2 | VC8762 | CAPSCREW-3/8"-16NC×11/2" | 2 | |
| 3 | TC1231 | LOCKWASHER-3/8" | 2 | |
| 4 | TR4436 | FLAT WASHER-3/8" | 2 | |
| 5 | TN2590 | SPACER,HOSE | 6 | |
| 6 | EH1785 | CLEAT,CABLE | 6 | |
| 7 | TG5845 | STUD,THREADED-5/8"-11NC | 2 | |
| 8 | TR9082 | FLAT WASHER-5/8" | 3 | |
| 9 | VC1390 | LOCKWASHER-5/8" | 3 | |
| 10 | TV1749 | NUT-5/8"-11NC | 3 | |
| 11 | VN6188 | STUD-5/8”-11NCX71/2" | 1 | |
| 12 | VA0609 | SPACER | 2 | |
| 13 | ED8936 | CLEAT,CABLE | 4 | |
| RETARDER GRID GROUP | ||||
| RETARDING GRID INSTALLATION Y₂ | ||||
| Item | Part No | Description | Qty | Ref |
| 1 58E-06-00921 | GRID,RETARDING(SEE INDEX)1 64341 | |||
| 2 MM0167 | CAPSCREW-M24×3.00X180 8 | |||
| 3 01643-32460 | FLAT WASHER-M24 16 | |||
| 4 MM0476 | LOCKWASHER-M24 8 | |||
| 5 MM0183 | NUT-M24×3.00 8 | |||
| ALTERNATOR GROUP | ||||
| ALTERNATOR-STATOR ASSEMBLY XA3159 | ||||
| Item | Part No | Description | Qty | |
| 1 | XA3160 | STATOR FRAME &CORE ASSEMBLY | 1 | |
| 2 | GE1167 | STATOR REWIND KIT | 1 | |
| 3 | (NOT USED IN THIS APPLICATION) | |||
| 4 | VE1887 | STRAP,CONNECTION | 1 | |
| 5 | VE4342 | BRACKET,INSULATED | 7 | |
| 6 | VE2753 | BRACKET | 7 | |
| 7 | VE4542 | CAPSCREW-1/2"-13NCX1" | 28 | |
| 8 | VE5185 | FLAT WASHER-1/2" | 28 | |
| ALTERNATOR GROUP | ||||
| ALTERNATOR-ROTOR ASSEMBLY 58E-06-03060 | ||||
| Item | Part No | Description | Qty | uom |
| 1 | VJ1063 | STRAP,CONNECTION | 7 | |
| 2 | BF1480 | COLLECTOR RING ASSEMBLY | 1 | |
| 3 | VE4643 | CLAMP,SUPPORT | 4 | |
| 4 | BF4833 | STRIP,BRAZING | 16 | |
| 5 | 58E-06-03070 | COIL,ROTOR | 8 | |
| 6 | VE7006 | CORE,ROTOR | 1 | |
| 7 | BF3105 | RING,TIE | 1 | |
| 8 | BF1007 | TAPE,GLASS | AS REQUIRED | |
| 9 | VE1001 | STRIP,SLIPPER | 32 | |
| 10 | GE1084 | SHAFT,ROTOR | 1 | |
| 11 | VJ1069 | WEDGE | 8 | |
| 12 | VJ1068 | WEDGE | 8 | |
| (ALSO SEE FIGURE 64409 FOR BALANCE OF | ||||
| ROTOR ASSEMBLYCOMPONENTPARTS.) | ||||
