Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| WHEEL MOTOR 1/8 PC3159 | ||||||||||
| Item | Part No | Description | Qty | uom | ||||||
| 1 | XA2849 | FRAME | 1 | |||||||
| 2 | XA3384 | SHAFT,PLANET GEAR | 3 | |||||||
| 3 | XA2851 | TORQUE TUBE | 1 | |||||||
| 4 | VE0653 | BEARING(1) | 3 | |||||||
| 5 | VE4231 | BEARING,ROLLER(1) | 3 | |||||||
| 6 | VE6090 | SLEEVE | 3 | |||||||
| 7 | VE4232 | CAP,BEARING | 3 | |||||||
| 8 | VE4496 | NUT(1) | 3 | |||||||
| 9 | VE4497 | LOCKWASHER(1) | 3 | |||||||
| 10 | VE8234 | COLLAR | 3 | |||||||
| 11 | VE8233 | CAP,BEARING | 3 | |||||||
| 12 | VE0756 | RING | 1 | |||||||
| 13 | VE0517 | SEAL(1) | 2 | |||||||
| 14 | VE0662 | BAND,WEAR(1) | 2 | |||||||
| 15 | VE4239 | HOUSING,SEAL | 1 | |||||||
| 16 | VE4237 | RING,SEAL | 1 | |||||||
| 17 | VE4238 | FLINGER | 1 | |||||||
| 18 | VE4403 | CLAMP(1) | 36 | |||||||
| 19 | VE4489 | CAPSCREW-1/2"-13NCX11/4"(1) | 36 | |||||||
| 20 | VE4243 | WASHER,CONCAVE(1) | AS REQUIRED | |||||||
| 21 | VE4236 | SEAL(1) | 1 | |||||||
| 22 | VE3956 | PACKING(1) | 1 | |||||||
| 23 | VE4235 | WEAR BAND(1) | 1 | |||||||
| 24 | C5768 | PLUG,PIPE-1/8"(1) | 16 | |||||||
| 25 | VE4513 | RING | 3 | |||||||
| 26 | XA4495 | PLANET COVER ASSEMBLY | 1 | |||||||
| 27 | VS9430 | CAPSCREW-3/8"-16NCX3/4"(1) | 53 | |||||||
| 28 | WA0471 | CAPSCREW-1/2"-13NC×214"(1) | 16 | |||||||
| 29 | VE5185 | FLAT WASHER-1/2"(1) | 58 | |||||||
| 30 | BF3900 | CAPSCREW-1/2"-13NCX11/4"(1) | 6 | |||||||
| 31 | VE8879 | CAPSCREW-1/2"-13NCX2"(1) | 18 | |||||||
| 32 | BF1486 | CAPSCREW-1/2"-13NCX11/8"(1) | 18 | |||||||
| 33 | BF3896 | WRE,LOCKING(1) | AS REQUIRED | |||||||
| 34 | BF4453 | COVER,SUN PINION | 1 | |||||||
| 35 | VS8410 | GASKET(1) | 1 | |||||||
| 36 | VS9430 | CAPSCREW-3/8"-16NCX314"(1) | 6 | |||||||
| 37 | XA3382 | SHAFT,SUN PINION ASSEMBLY | 1 | |||||||
| SUN PINION(2) | 1 | |||||||||
| BF3399 | PLATE,RETAINING | 1 | ||||||||
| XA3381 | RING,RETAINING,SUN PINION | 1 | ||||||||
| VE3163 | BAFFLE | 1 | ||||||||
| 38 | VE4548 | RING,DRVE | 1 | |||||||
| 39 | BF3863 | CAPSCREW-1/2"-13NC×4"(1) | 1 | |||||||
| 40 | VE5185 | FLAT WASHER-1/2" | 1 | |||||||
| 41 | VS8411 | PLUG,MAGNETIC(1) | 1 | |||||||
| 42 | VE1273 | RING,SEAL(1) | 1 | |||||||
| 43 | VJ9656 | LIQUID GASKET | AS REQUIRED | |||||||
| 44 | TD8074 | ADHESIVE(1 GALLON) | ASREQUIRED | |||||||
| 45 | VS8999 | CEMENT | AS REQUIRED | |||||||
| 46 | VS8408 | PIN | 1 | |||||||
| NS | AK9363 NOTE:(1)INCLUDED INAK9363 WHEEL MOTOR OVERHAUL KIT. (2)NOT SERVICED SEPARATELY. |
|||||||||
| NS | ||||||||||
