Product Details:
Payment & Shipping Terms:
|
| STANDARD: | GENUINE TEREX |
|---|
Email : spareparts1986@gmail.com
TEL / WhatsApp : 008618264966991
Web : www.all-genuine.com
| STEERING CYLINDER AND BEARINGS | |||
| ltem | Part No | Description | Qty |
| 0 | EL7952 | STEERING CYLINDER | 1 |
| 1 | PC0585 | PISTON SEAL ASSEMBLY(1) | 1 |
| 2 | EL7953 | ROD | 1 |
| 3 | PB9518 | BEARING(1) | 1 |
| 4 | VL7694 | LOCKNUT,NYLON-134"(1) | 1 |
| 5 | VL7699 | BEARING(1) | 1 |
| 6 | EH5932 | PISTON | 1 |
| 7 | EH5933 | HOUSING | 1 |
| 8 | SL8048 | SEAL,O-RING(1) | 1 |
| 9 | WA1433 | RING,BACKUP(1) | 1 |
| 10 | EC4589 | GLAND | 1 |
| 11 | TD8516 | CAPSCREW-314”-10NCX31/4" | 2 |
| 12 | PC0557 | SEAL,ROD | 1 |
| 13 | PB8937 | WIPER,ROD | 1 |
| 14 | TD7882 | CAPSCREW-3/4”-10NCX13/4" | 4 |
| 15 | C1602 | CAPSCREW-3/8”-16NC×1" | 1 |
| 16 | PC1682 | BEARING,SPHERICAL | 62 |
| 17 | EK3384 | RETAINER,ANTI-ROTATION | 2 |
| 18 | C0312 | LOCKWASHER-3/8" | 1 |
| 19 | VM0313 | PLUG( 2) | 61 |
| NS | AK4370 | NOTE:(1)INCLUDED INAK4370 SEAL KIT. | |
| NS | (2)LOCATION IS DEPENDENT ON SIDE OF MACHINE | ||
| NS | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY) | ||
